Leg Nailing Machine

Foudila Oy LNM3500

Durum: yeni, Üretim yılı: 2026, Fonksiyonellik: tamamen fonksiyonel, toplam genişlik: 1.000 mm, toplam yükseklik: 1.900 mm, toplam uzunluk: 9.000 mm, Oy Foudila Ab is a company based in Kaskinen, Finland, with over 45 years of experience in wood handling. For the past 15 years, we have also been active in the pallet industry and, over the years, have developed numerous machines for nailing, automatic wood conveying, and stacking. We manufacture both standard machines and customized solutions tailored to customer requirements. The LNM3500 is a flexible, compact, and efficient pneumatic nailing machine for producing legs for pallet manufacturing. It features a user-friendly program, enabling very quick changeovers, and the machine can store settings for over 100 different leg types. The unit is equipped with three Bostitch nail guns with jumbo coil magazines, each fitted with indicator displays. Production of legs with 2–30 blocks per leg is possible. The machine comes with a large board cassette. A protective cover ensures sound insulation and safe operation. Control is via a 10-inch touchscreen. Beckhoff control system. The machine can be optionally equipped with an optimized block cutter as well as an automatic block feeding system for the nailing machine. The block cutter can be mounted at the rear or on the side of the nailing machine. Dimensions for the standard machine: - Boards: Length 600–3500 mm, width 60–125 mm, height 16–28 mm - Blocks: Length 60–150 mm, width 60–125 mm, height 50–100 mm Capacity: - 21 blocks/min Bwedpfx Acoy Izahefow Machine dimensions (without block cutter): - Length 9000 mm, width 1000 mm, height 1900 mm The machine is CE-marked. The leg nailing machine can also be equipped with an automatic stacker for finished legs. Please do not hesitate to contact us for further information, images, or videos.
