Üniversal yataklı freze makinesi

Ho Chun U-1000B

- 3-axis position display
- Universal milling head
- Hardened and ground guideways
- Infinitely variable feeds
- Infinitely variable spindle speeds with 2 speed ranges
- Horizontal milling device
- Hydraulic tool clamping
- Drive power: 11 kW
- Automatic central lubrication
- Coolant system
- Table guarding
- CE certification
- Incl. milling tools
- Incl. operating manual and documentation
- Year of manufacture: 2001
- Complete service performed

Technical data

Work table:
- Table clamping surface: 1500 x 360 mm
- Table load capacity: 800 kg
Travel distances:
- X-axis longitudinal: 1000 mm
- Y-axis transverse: 540 mm
- Z-axis vertical: 430 mm
Working area:
- Distance spindle nose / table: 50 - 480 mm
- Distance spindle center / column: 350 mm
Feeds:
- Number of feed rates: infinitely variable
- Feed, longitudinal / transverse: 16 - 1200 mm/min
- Feed, vertical: 8 - 450 mm/min
- Rapid traverse, longitudinal / transverse: 2500 mm/min
- Rapid traverse, vertical: 1000 mm/min
- Feed motors: 3 x 1.5 kW
Main spindle:
- Number of speed steps: 12
- Speed range: 40 - 1750 rpm
- Gradations: 160, 225, 315, 440, 620, 880, 1240, 1750
Blodewkvlkspfx Ad Nsp
- Drive power: 11 kW
- Spindle taper: ISO50 DIN2080
- Milling head overhang: 420 mm
Dimensions and weights:
- Machine space requirement: 3050 x 2150 mm
- Machine dimensions: 2050 x 2210 x 1830 mm
- Machine weight: 2800 kg
