NOKTA ÇİZGİSİ MESAFE KARTI

HOMAG

Durumu: mükemmel (kullanılmış), Üretim yılı: 2010, Fonksiyonellik: tamamen fonksiyonel, iş parçası yüksekliği (maks.): 60 mm, kenar kalınlığı (maks.): 20 mm, iş parçası genişliği (maks.): 60 mm, The machine has been serviced and is in excellent condition. It is immediately ready for operation! TECHNICAL DETAILS Glued edge thickness: max. 20 mm Maximum gluing height: 60 mm Maximum roll material thickness: 3 mm Piece width: min. 60 mm Maximum feed speed: up to 25 m/min Feed: continuous Electric height adjustment: available Pressure: top belt pressure Preheating zone: available Granulate glue system: with prefabricated container Glue pot: interchangeable/variable Spraying device: available Pre-milling unit: available Trimming unit: with 2 motors Milling stations: flush/radial/chamfered, 1 available Corner copying unit: with 2 motors Edge scraper: profile and planer Polishing unit: available Strip magazine: available Units: synchronized units with NC axis/axes Machine version: left side Quick-change units: available MACHINE DETAILS Remote control: PowerControl PC 22 Weight: 5,000 kg Machine length: 7,845 mm Standards: CE regulations EQUIPMENT - Special equipment: with nesting - new chains - HOMAG feed device with 2 rollers - HOMAG A 20 glue application unit - HOMAG HL 84 Nksdox Tqgbepfx Acust - HOMAG FK 11 - HOMAG PN 10 profile scraper - HOMAG FA 11 finishing unit

Durumu: işlem için hazır (kullanılmış), Üretim yılı: 2007, Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: 0-201-09-5124, X ekseni hareket mesafesi: 6.000 mm, Y ekseni hareket mesafesi: 1.650 mm, kontrolör modeli: Homatic PC 85 Power Control, TECHNICAL DETAILS Working area X-axis: 6,000 mm Working area Y-axis: 1,650 mm – up to 1,750 mm when milling Max. travel height for edge banding: 60 mm Maximum applicable edge height: 65 mm Minimum internal radius: 30 mm Automatic tool changer: 18 positions Drilling head: 27 spindles (4 kW) Aggregate saw blade diameter max.: 200 mm MACHINE DETAILS Control system: Homatic PC 85 Power Control Software: WoodWop Electrospindle C axis: 11 kW, HSK F63 Edge requirements: roll material, PVC / ABS 0.4 - 3 mm Nkodoydl Nwepfx Acuet EQUIPMENT - 10 adjustable support rails for suction cups - Loading and unloading aid with 8 pneumatic bars - Suction cup positioning via laser system - Edge banding unit with 360° rotation, glue pot and preheater for granulated EVA glue - Rubber-coated pressure roller + rubber-coated pressure roller - Preheating lamp - Edge trimmer and edge scraper - Edge holder magazine - Front and side protection system with carpets - Surround protection grid - Chip extraction with motorized conveyor belt - Air conditioning for machine control - Automatic lubrication system - Vacuum pump

Durumu: işlem için hazır (kullanılmış), Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: 0-200-03-8334, X ekseni ilerleme hızı: 24 m/dak, iş parçası yüksekliği (maks.): 60 mm, kontrolör modeli: Power Control Pc 22, TECHNICAL DETAILS Panel height: 60 mm Solid wood thickness: 20 mm PVC / ABS thickness: 3 mm Feed speed: 24 m/min MACHINE DETAILS Control system: Power Control PC 22 Supply voltage: 480 V Nksdpfx Acsydiymouot Frequency: 60 Hz Phases: 3~ + N Operating current: 51 A Fuse protection: 63 A Phase circuit: 3~ Control voltage: 24 V EQUIPMENT Working height electronically adjustable via CNC Motorized, rubber-coated pressure belt for higher holding force Panel support guide Side roller conveyor with idler rollers for panel support Sanding unit Panel edge heating lamps 6-position coil magazine with automatic edge changeover via CNC Adhesive application unit for EVA hot-melt glue with premelter and glue pot Pressure roller unit for straight profiles with electronically adjustable rollers via CNC End trimming unit with 2 motors and automatic tilt adjustment Overlapping trimming/milling unit with 2 motors Glue/milling station with 2 tilting motors, electronically adjustable via CNC Multifunctional 4-motor corner rounding unit (scraper + rounding) with numerical control, automatic adjustment Provision for additional work station installation Edge scraper unit Oscillating brush unit

Durumu: kullanılmış, makine/araç numarası: 008256, Maksimum işlenebilir genişlik: 800 mm Nkjdpox A Hfvjfx Acust Maksimum işlenebilir uzunluk: 2500 mm Maksimum işlenebilir yükseklik: 1340 mm Maksimum ilerleme hızı: 40 m/dak

Durumu: kullanılmış, Number of machines: 9 units. Wooden Window Production Line for sale on behalf of client. Machines can be inspected while still in operation. Sale includes machines together with tools and programming for the manufactured systems. Includes capabilities for slanted and arched window production. Item 1: Weinig Powermat 500, year 2010, window version ----- - 6 spindles, 5 x PowerLock - 8,000 rpm - Equipped for glazing bead cutting - Large PowerCom control unit - Includes existing Leitz planing and profile tools - Integrated with Maweg single-piece wood sanding machine Saturn Duo, year 1985, and workpiece return conveyor Item 2: SCM Windor 40 R window system, year 2006 ----- - 2 long mortising spindles, CNC controlled - 3 long profiling spindles, CNC controlled, with top and bottom units - Rebate wagon for small sashes - ROTATEN: facility for slanted windows - Includes Leitz window and door tools - Includes separate OKOMA UF 3 rebate machine with tools Item 3: HOMAG CNC machining center BMG310/42/F/K, year 2018 ----- - Portal machine, 5-axis Drive 5C+ with 15 kW - Overhead laser - Working area: 4200 mm length x 1350 mm depth - 32-position disc tool changer - 8-position linear tool changer - Fixed drilling head, 18 spindles V12/H6/S0/90 degrees - 8 consoles - 6 lift rails - Connection for 8 PowerClamp clamps - approx. 30 vacuum clamps - 4 x PowerClamp clamps - WoodWop - Chip conveyor belt - Various small solid wood clamps, used for box windows - Includes Leitz tools for Homag with tooling for arched window production - Includes Barbaric vacuum lifter, year 2015 Item 4: Löwer MZP 1 mini finger joint press ----- - For arched window production Item 5: S+S frame press type Bavaria 200 L, year 2014 ----- - Working size 4000 x 2600 mm - With center pressure beam and cross pressure device - Motorized width adjustment - Basic counter profile equipment - Control system for slanted windows - Pendulum pressure plates + extension for pointed windows - Intermediate pads for small part pressing Nkedpjyclwxsfx Acuet - Various carrier plates for counter profiles and counter profiles Item 6: Striffler sash hardware assembly table ----- - With automatic screw driver and screw feed - Hardware rack - Punch for Roto hardware Item 7: Stegherr KF counter profile milling machine ----- - With existing tools Item 8: Tools ----- All tools belonging to the machines for the wood and wood-aluminum systems IV 72 + 92 mm shown in the PDF - Windows - Lift and slide doors - Arched and slanted windows - Box windows - Front entrance doors in various versions - Putty groove versions - ... Sale of tools as currently available including condition, scope, and accessories. Note regarding window sections, tool drawings, tool system listings: Company Engelfried does not guarantee that the actually available tools match the specified and illustrated systems. (Technical data as per manufacturer, no guarantee!) ----- Total price for item 1 ...

Durumu: kullanılmış, Wooden window production line for sale on behalf of a customer. Machines can be viewed while still in operation. Sale includes all machines, tools, and programs for the produced systems. Incl. production capability for angled and arched windows. Pos. 1: Weinig Powermat 500, year 2010, window version ----- - 6 spindles, 5 of which with PowerLock - 8,000 rpm - Equipped for glass bead cutting - Large PowerCom control system - Includes existing Leitz planing and beading tools - Linked with Maweg single-piece wood sanding machine Saturn Duo, year 1985, plus return conveyor for workpieces Pos. 2: SCM Windor 40 R window line, year 2006 ----- - 2 long slot spindles, CNC-controlled - 3 long profile spindles, CNC-controlled + unit from above and below - Offset wagon for small sashes - ROTATEN: Angled window device - Includes Leitz window and door tooling - Includes separate OKOMA UF 3 offset machine with tools Pos. 3: HOMAG CNC Machining Center BMG310/42/F/K, year 2018 ----- - Gantry machine, 5-axis Drive 5C+ with 15 kW - Ceiling laser - Working dimensions: 4200 mm length, 1350 mm depth - 32-position rotary tool changer - 8-position linear changer - Fixed-position drilling head: 18 spindles V12/H6/S0/90 deg - 8 consoles - 6 lifting rails - Connection for PowerClamp clamps, 8 units - Approx. 30 vacuum clamps - 4 x PowerClamp clamps - WoodWop - Chip conveyor - Several small solid wood clamps, used for box-type windows - Includes Leitz tools for Homag with arch window production - Includes Barbaric vacuum lifter, year 2015 Nkjdpfx Aoyclwlecust Pos. 4: Löwer MZP 1 mini dovetail press ----- - For arch window production Pos. 5: S+S Frame Press Type Bavaria 200 L, year 2014 ----- - Working dimensions: 4000 x 2600 mm - With central pressure beam and cross pressure device - Motorized width adjustment - Basic equipment for counter profiles - Angled window control - Pendulum pressure plates + extension for gable windows - Intermediate support for small-size pressing - Various carrier plates for counter profiles and counter profiles Pos. 6: Striffler sash hardware fitting table ----- - Automatic screwdriver and screw feed - Hardware rack - Punch for Roto hardware Pos. 7: Stegherr KF counter profile router ----- - With existing tooling Pos. 8: Tools ----- All tooling for the machines for the wood and wood-aluminium systems IV 72 + 92 mm shown in the PDF: - Windows - Lift and slide doors - Arched and angled windows - Box-type windows - Front doors in many variants - Putty rebate versions - ... Sale of tools as currently available, in current condition and scope, including accessories. Note regarding window sections, tool drawings, tool system listings: Engelfried GmbH does not guarantee that the actually available tools match the named and drawn systems. (Technical data as provided by manufacturer, without guarantee!) ----- Total price for items 1 - 8 ex-works: Price on request!

Durumu: kullanılmış, Wood window manufacturing line for sale on behalf of a client. Machines can still be inspected while in operation. Sale includes machines, tools, and programming for the systems produced. Incl. equipment for slanted and arched window manufacturing. Item 1: Weinig Powermat 500, year 2010, window version ----- - 6 spindles, including 5 x PowerLock - 8,000 rpm - Equipment for glazing bead cutting - Large PowerCom control - Includes existing Leitz planing and moulding tools - Linked with Maweg single timber sanding machine Saturn Duo, year 1985 as well as return transport system for workpieces Item 2: SCM Windor 40 R window line, year 2006 ----- - 2 long slot spindles, CNC controlled - 3 long profile spindles, CNC controlled + unit from top and bottom - Flap carriage for small sashes - ROTATEN: Slanted window device - Includes Leitz window and door tools - Includes separate OKOMA UF 3 rebate machine with tools Item 3: HOMAG CNC machining center BMG310/42/F/K, year 2018 ----- - Gantry machine, 5-axis Drive 5C+ with 15 kW - Overhead laser - Working dimensions 4200 mm length, depth 1350 mm - 32-position disc changer - 8-position linear changer - Fixed drilling head 18 spindles V12/H6/S0/90 degrees - 8 consoles - 6 lifting rails - Connection for 8 PowerClamp clamping fixtures - Approx. 30 vacuum clamps - 4 x PowerClamp clamps - WoodWop - Chip conveyor - Various small solid wood clamps used for box windows - Includes Leitz tools for Homag incl. arched window manufacturing - Includes Barbaric vacuum lifter, year 2015 Item 4: Löwer MZP 1 mini finger-joint press ----- - For arched window production Item 5: S+S frame press Type Bavaria 200 L, year 2014 ----- - Working size 4000 x 2600 mm - With center pressure beam and cross pressure unit - Motorized width adjustment Nedsyclwfspfx Acuekt - Basic set of counter profiles - Slanted window control - Oscillating pressure plates + extension for pointed windows - Intermediate accessories for small size pressing - Various carrier plates for counter profiles and counter profiles Item 6: Striffler sash fitting table ----- - With automatic screwdriver and screw feed - Hardware rack - Punch for Roto fittings Item 7: Stegherr KF counter milling machine ----- - With existing tools Item 8: Tools ----- All tools belonging to the machines for the IV 72 + 92 mm wood + wood-aluminium systems shown in the PDF - Windows - Lift-slide doors - Arched and slanted windows - Box-type windows - Various house entrance doors - Putty rebate options - ... Sale of tools as is, including current accessories and extent. Note regarding window cross-sections, tool drawings, tool system lists: Fa. Engelfried assumes no warranty that the tools actually present match the described and drawn systems. (Technical data according to manufacturer, no guarantee!) ----- Total price for items 1 - 8 ex site on request! ...

Durumu: kullanılmış, Üretim yılı: 2008, toplam uzunluk: 7.500 mm, toplam yükseklik: 1.800 mm, toplam genişlik: 970 mm, Ağırlık: 5.500 kg - Üretim yılı: 2008 - Dokümantasyon mevcut: Hayır - CE işareti mevcut: Evet - CE sertifikası mevcut: Hayır - Seri numarası: - Ünite sayısı [Adet]: 8 - Voltaj [V]: 400 - Akım tüketimi [A]: 43 - Sigorta [A]: 50 Nkjdpfx Aceychw Ieust - Taşıma ölçüleri: 7500mm x 970mm x 1800mm (u x g x y) - Taşıma ağırlığı [kg]: 5500kg - Taşıma paketleri [Adet]: 3 Finansal Bilgiler KDV: Belirtilen fiyat KDV hariçtir KDV/farklı vergilendirme: KDV şirketler için düşülebilir Endüstri alanındaki tüm ürünler için her zaman teslimat ve takas mümkündür Yorick Diebels

Durumu: işlem için hazır (kullanılmış), Üretim yılı: 2009, Bu HOMAG KAL 330/6/A3/S2 2009 yılında üretilmiştir. EVA sıcak eriyik yapıştırıcı için yapıştırma ünitesi, basınç bölgesi, kesme ünitesi, kopya frezeleme, sıyırıcılar ve parlatma ünitesine sahip kullanılmış bir kenar bantlama makinesi. Bir LIGMATECH iş parçası geri dönüş sistemi içerir. Bu HOMAG KAL 330/6/A3/S2 kenar bantlama makinesini satın alma fırsatını değerlendirin. Daha fazla bilgi için bize ulaşın. Nkedoychdujpfx Acuot

Durumu: iyi (kullanılmış), Üretim yılı: 2009, Brief description of standard equipment: ·   Console table ·   Automatic console positioning ·   Three-stage clamping element ·   Laser positioning aid for vacuum clamps ·   Vacuum clamps Main spindle 15 kW C-axis with aggregate interface Interface for Flex5 aggregate 30-position chain tool changer Tool holder HSKF 63 Drilling head with 13 spindles WoodWop package for AV-PC Rack and pinion drive for X and Y axes Ball screw drive for Z axis Z-axis travel 600 mm Travel speeds: Vector speed 113 m/min X and Y axis 80 m/min Z axis 30 m/min Free-standing electrical cabinet. Homag control Homag Homatic CNC system NC 83 with PLC control Remote diagnostics / telephone modem Technical data: Maximum workpiece length 4000 mm (all aggregates), individual maximum 1375 mm in pendulum operation Tool diameter 25 mm Individual 4175 mm / Pendulum 1550 mm Workpiece width (all aggregates): front 1150 mm, rear 1400 mm Workpiece thickness 40 mm Milling operations with tool diameter 25 mm: front 1220 mm*, rear 1550 mm *Workpiece thickness 40 mm Console table K Console length 1340 mm Side stop rulers Vacuum clamps Maximum workpiece thickness 300 mm with standard clamp Maximum 120 mm with mechanical clamping elements or customer-supplied templates Up to 80 mm with standard clamp Working height 960 mm (underside of workpiece) PM basic equipment Automatic console positioning Three-stage clamping element Main spindle 15 kW (12 kW in S1 operation) Frequency converter Spindle with hybrid bearings C-axis with aggregate interface Interface for Flex5 aggregate High-speed vertical spindles Pneumatically lowerable loading stroke Two-stage clamping element for PM console Clamping device for post edges Three-stage clamping element for PM console Saw aggregate D= 280 mm Drilling/milling aggregate with 4 spindles for tool changer Lock case aggregate 2 Available immediately All information without guarantee. Further technical data on request. Njdpjyb Ndgefx Acuokt For an additional charge, individual tools can also be purchased. The tools shown are NOT included in the base price!
