Dikey işleme merkezi

Hommel Unverzagt UVA 725

Durumu: onarım gereklidir (kullanılmış), For sale is a UVA 725 Plus from 2011, a compact and extremely robust vertical CNC machining center from the Hommel-Unverzagt Group – equipped with a Heidenhain TNC 620 control and SK40 spindle interface. The machine was in production until recently but currently does not fully boot up due to a control unit (CC) fault. Technical Specifications Travel paths: X-axis: 725 mm Y-axis: 460 mm Z-axis: 460 mm Spindle: Speed: 10,000 rpm Tool holder: SK40 Max. tool diameter: 100 mm Max. tool length: 300 mm Max. tool weight: 7 kg Tool magazine: Capacity: 24 slots Tool change time: approx. 2 s Table: Dimensions: 760 × 420 mm Max. table load: 400 kg Machine dimensions (L×W×H): approx. 2200 × 2100 × 2300 mm Weight: approx. 3600 kg Condition & Fault Description The machine ran smoothly until recently but now displays various axis configuration and CC/PLC errors when powered on: Heidenhain TNC 620 errors include: - “Timeout during command processing of CC” - “The PLC program has been stopped” - “HSCI initialization faulty” - “HSCI Ethernet connection interrupted” - “Configuration of axis X/Y/Z/S faulty” The Command/Control unit (CC) has already been replaced, but the fault persists. The machine is therefore offered as defective / for repair or for parts. Accessories & Scope of Delivery: - Several SK40 tool holders (various sizes, collet chucks, end mill holders etc.) - Chip conveyor (complete unit) - Base frame / chip tray / collecting pans - Hydraulic unit / coolant pump - Machine documentation Documentation: - UVA 725 Plus Parts Manual - Operating Manual Heidenhain TNC 620 - Delivery / Preparation / Installation Guide (UVA 550–1600) - Heidenhain TNC 620 User Manual (large binder) Prodpfx Aexzvnwjf Hed Machine data as per nameplate: Model: UVA 725 Plus Serial number: 71L1261109 Year of manufacture: 2011 Manufacturer: Hommel Unverzagt GmbH Weight: 3800 kg Manufactured for Hommel Unverzagt in Taiwan

Üretim yılı: 2010, Durumu: işlem için hazır (kullanılmış), Travers yolları X/Y/Z: 725mm/460mm/460mm, hız: 10000rpm, takım tutucu: SK40, takım magazini: 24 yer, maks. takım çapı/uzunluğu: 100mm/300mm, maks. takım ağırlığı: 7kg, takım değiştirme süresi: 2s, tabla boyutları X/Y: 760mm/420mm, maks. tabla yükü: 400kg. Boyutlar X/Y/Z: yaklaşık 2200mm/2100mm/2300mm, ağırlık: yaklaşık 3600kg, kumanda: Heidenhain TNC 620. kusurlar: Entegre kontrolörlü ve PLC'li kompakt invertör, kapı anahtarı, her iki çalışma alanı lambası, X ekseni vidalı mil ve makaralı rulmanlar. Talaş konveyörü dahil. Dokümantasyon mevcut. Yerinde inceleme mümkündür. Prodjttmpljpfx Af Hsd
