CNC İŞLEME MERKEZİ-4 eksen BIMA KESİM
IMA BIMA Cut 120 (160) / 420

Koşul

Kullanılan

Konum

Roreto

CNC İŞLEME MERKEZİ-4 eksen BIMA KESİM IMA BIMA Cut 120 (160) / 420

Makineye ait bilgiler

Makine tanımı:: CNC İŞLEME MERKEZİ-4 eksen BIMA KESİM

Üretici:: IMA

Modeli:: BIMA Cut 120 (160) / 420

Koşul:: mükemmel (kullanılmış)

Fiyat ve Konum

Konum:: Via Savigliano, 29, 12062 Roreto CN, Italia

Çağrı

Teklif detayları

Liste kimliği:: A184-54896

Referans No.:: O01005

Son güncelleme tarihi:: 24.03.2026

Açıklama

4-axis CNC-controlled MACHINING CENTER

Gantry-type design with ICOS-Open control.
Software: IMAWOP / IMATRONIC – BIMA Fast Cut.
Clamping table with consoles. No. 6 consoles (1400 mm)
Automatic positioning of consoles (X-axis)
Automatic positioning of vacuum pods (Y-axis)
Automatic tool change system
Carousel tool changer – Magazine/ No. 18 tool positions
Maximum working area (X – Y – Z): 4250 x 1600 x 60 mm
Minimum workpiece dimensions (X – Y – Z): 295 x 115 x 14 mm
Maximum workpiece dimensions (X – Y – Z): 4250 x 2200 x 60 mm
Chip conveyor
Supplied with separate electrical and control panel. Total connected load (kW): 28

Ksdpfx Amjvxhnuomelt
WORKING UNITS (TOP):
Vertical main spindle (milling unit) HSK F63 – Power: 14.5 kW (S6) / 7.5 kW (S1)
No. 3 clamps for fixing and moving the panels on the machine’s suction pods
No. 5 air tables for panel parking before processing
Vacuum system with program-controlled suction for lifting panels onto the feed belt
Panel exit system with motorized conveyor belt

Bu ilan otomatik olarak tercüme edildiğinden bazı çeviri hataları oluşmuş olabilir.
