Durma açısı

INOX

Durumu: yeni, Brand new electric heated stainless steel mixing tank with insulation and propeller agitator, incl. operating manual and CE declaration of conformity. Model: EBB250RWP Also available with alternative agitator types and in other sizes. Dodpfeyngxnox Adtocd Volume: 250 L Dimensions (approx.): Ø 595 mm x cylindrical height 900 mm Total height: 1240 mm plus agitator motor Material: 1.4301 stainless steel (V2A) Surface finish: IIIc / 2B Internal weld seams ground Max. operating temperature: 110°C Operating pressure (tank): ATM - Upright design on castors - Top cover: hinged lid, half screwed, half foldable with stainless steel grate as reach-in protection (removable) - Bottom: flat base with side outlet DN50 DIN11851 and disc valve, seal EPDM - Agitator flange socket on top cover - 2x handles for pushing Propeller agitator Power: 0.37 kW Speed: 1410 rpm Operating voltage: 3PH 400V

Durumu: yeni, Factory-new electrically heated stainless steel agitator tank. Stainless steel agitator vessel with insulation and propeller agitator, including operating manual and CE declaration of conformity. Model: EBB150RWP Alternatively available with other types of agitators and in different sizes. Volume: 152L Approx. dimensions: Ø 660mm x cylindrical height 625mm Total height: 910mm (+ agitator motor) Dedpfx Adoym Uclotscd Material: 1.4301 stainless steel (V2A) Surface finish: IIIc / 2B Weld seams ground Max. operating temperature: 110°C Operating pressure vessel: ATM - Upright design on castors - Top lid: hinged cover, half bolted, half hinged, with stainless steel sheet grate as intrusion protection (removable) - Bottom: flat bottom with lateral outlet DN50 DIN11851 and butterfly valve, gasket EPDM - Agitator flange connection on top cover - 2x push handles - 1x nameplate Agitator: Propeller agitator Power: 0.25 kW Speed: 980 rpm Operating voltage: 3-phase 400V

Durumu: mükemmel (kullanılmış), Üretim yılı: 2014, Fonksiyonellik: tamamen fonksiyonel, toplam yükseklik: 18.000 mm, dış çap: 3.000 mm, su tankı kapasitesi: 70.000 l, 70.000 litre kapasiteli paslanmaz çelikten imal edilmiş tank. Isı yalıtımlı gövde ve baskül hücreleri bulunmaktadır. Hacim Toplam kapasite: 70.000 L Malzeme: Paslanmaz çelik Ekipman konfigürasyonu: Isı yalıtımlı Baskül hücreleri Dcedpfx Adsxlir Dsted Taşıma bilgileri: Uzunluk: 18.000 mm Genişlik: 3.500 mm

Durumu: yeni, - Material: DIN 1.4301 - Internal surface: IIId, weld seams pickled and ground - External surface: jacket ground - SBR - Volume: approx. 1940L Dimensions: - Diameter: approx. 1110 mm Dsdpsym Au Asfx Adtocd - Jacket height: approx. 2000 mm - Ground clearance: approx. 400 mm - Total height with jib: approx. 2900 mm Equipment: - 3 adjustable feet - Rectangular door 420x320 mm - Residue discharge with ball valve NW50, DIN 11851 - Clear discharge with ball valve NW50, DIN 11851 - Level indicator with handwheel - Sample extraction with handwheel - Dip tube sleeve with digital thermometer - Pillow plate - Holder for marking plate - Ladder bracket - Mobile lid with NW50 connection, pump and air hose - Cable winch for lifting the lid

Durumu: yeni, - Malzeme: DIN 1.4301, üst taban ve giriş kapağı DIN 1.4404 - İç yüzey: III d, kaynak dikişleri dekapajlı ve taşlanmış - Dış yüzey: mermer deseni Dcodpfxjym Auie Adtsd - Hacim: yaklaşık 2400L Boyutlar: - Derinlik: yaklaşık 1310 mm - Genişlik: yaklaşık 1080 mm - Soğutma ceketi yüksekliği: yaklaşık 1750 mm - Taban yüksekliği: yaklaşık 450 mm - Toplam yükseklik: yaklaşık 2570 mm Donanım: - 4 adet ayarlanabilir ayak - Dikdörtgen adam deliği 420x320 mm - Boşaltma: disk vanalı kalan sıvı çıkışı NW40, Fredrich no 2 NW40 - Temiz sıvı çıkışı: bilyalı vana NW40, Fredrich no 2 NW40 - Seviye göstergesi - Numune alma musluğu - Dijital termometre - Yukarı uzatılmış borulama ile çift cidarlı ceket - Etiketleme levhası - Merdiven askısı - Giriş kapağı NW 300, havalandırma bağlantısı NW 50 - Vinç pabuçları

Durumu: yeni, Brand new, electrically heated stainless steel agitator tank EBB90RWP Dsdpfx Asym Arbjdtscd Including operating manual and CE declaration of conformity. The double jacket is filled with thermal oil, which is heated by an electric heating element. Alternatively available with other agitators and in other sizes. Volume: 97L Dimensions approx.: Ø 540mm x cylindrical height 625mm Total height: 910mm (+ agitator motor) Material: 1.4301 stainless steel V2A Surface finish: inside and outside matt ground Weld seams ground Max. operating temperature: 110°C Operating pressure of tank: ATM - Vertical design on castors - Upper head: hinged lid, 1/2 screwed, 1/2 hinged with stainless steel grid cover as reach-in protection (removable) - Lower head: flat bottom with lateral outlet DN50 DIN11851 and disc valve - Agitator flange connection on upper head - 2x handles for pushing - 1x nameplate Propeller agitator Power: 0.25 kW Speed: 980 rpm Operating voltage: 3PH 400V

Durumu: kullanılmış, Üretim yılı: 2014, Genel Bakış Bu 20HL bira fabrikası 2014 yılında İspanyol üretici INOX DUBRA tarafından üretilmiştir. İstenildiği zaman görüntülenebilir. Teknik detaylar Şıra demleme: 20 HL Buhar ısıtmalı Pompaları ve ısıtma sıcaklığını kontrol etmek için elektrikli kontrol paneli Vanalar manuel olarak açılır Teslimat kapsamı 2 adet Bira fabrikası 1x su deposu 3300L soğutuculu Isı eşanjörü Çeşitli hortumlar, iki pompa vb. aksesuarlar. Djdpfx Adeukafxotecd

Durumu: kullanılmış, Üretim yılı: 2015, Overview This tank package was manufactured between 2015 and 2025 by the Spanish companies Inox GC and Magusa, as well as the German company Linde AG. The package includes multiple isobaric and atmospheric fermenters, an electric hoist, and a hop torpedo for pressure dry hopping. Technical Data & Scope of Supply Isobaric Fermenter (Unit 1) | Inox GC | — | 2016 | 1,500 l; cylindroconical; isobaric; double cooling jacket Isobaric Fermenter (Unit 2) | Inox GC | — | 2016 | 1,500 l; cylindroconical; isobaric; double cooling jacket Isobaric Fermenter (Unit 3) | Inox GC | — | 2016 | 1,500 l; cylindroconical; isobaric; double cooling jacket Isobaric Fermenter | Inox GC | — | 2019 | 2,000 l; cylindroconical; isobaric; double glycol jacket Isobaric Fermenter | Inox GC | — | 2021 | 3,000 l; cylindroconical; isobaric; double-wall cooling Atmospheric Fermenter (Unit 1) | Magusa | — | 2015 | 1,300 l; atmospheric; double cooling jacket Atmospheric Fermenter (Unit 2) | Magusa | — | 2015 | 1,300 l; atmospheric; double cooling jacket Electric Hoist | Linde AG | L14 | — | Electric; 1,400–1,700 kg lifting capacity Dodpfx Adjyb S Dvetecd

Durumu: kullanılmış, Üretim yılı: 2016, Overview This complete 1,500-litre brewery system was manufactured by the Spanish company Inox GC. It comprises a three-vessel brewhouse, a 2,000-litre mash/whirlpool tank, a 2,500-litre lauter tun, and a 1,800-litre hot liquor tank. The brewhouse is equipped with pumps, a heat exchanger, CIP features, and a new automatic AEM gas burner for heating. The system is in good condition. Technical Specifications Brewhouse – Inox GC (1,500 l) - Batch capacity: 1,500 l - Vessels: HLT, mash/lauter tun, kettle/whirlpool - Material: Stainless steel AISI 304 - Heating: Compatible with automatic gas burner Dcsdpfsyb S D Nsx Adtod - Includes: Temperature control, integrated pumps Insulated Mash & Whirlpool Vessel (2,000 l) - Capacity: 2,000 l - Insulation: 50 mm mineral wool - Features: Hinged lid, agitator with frequency converter, CIP system, PT100 sensor Insulated Lauter Tun (2,500 l) - Capacity: 2,500 l - Features: 5° sloped floor, 500 mm manway, German V-profile screen, automatic rake, CIP system Insulated Hot Liquor Tank (1,800 l) - Capacity: 1,800 l - Heating: 9 kW electric heating element - Features: Mineral wool insulation, 50 mm inlet/outlet, CIP system Process Equipment - Wort pumps (screw and transfer pumps) - Tubular heat exchanger (removable) - Hop filter - Automation panel with frequency converters - Automatic gas burner – AEM GR8 PHP (2016) Type: ring main gas burner, automatic ignition

Durumu: kullanılmış, depo kapasitesi: 1.000 l, GENERAL INFORMATION Equipment: Ball valve Design: Container Notes: Frame, V2A; Manhole diameter approx. 505 mm; Outlets partially slightly angled upwards Internal diameter: 1,120 mm Total width: 1,220 mm Total height: 1,680 mm Total length: 1,220 mm Location: Bremen Nameplate: Volume: 1,000 litres Product-contact material: V4A 1.4401/04 (AISI316) Condition: used Cylindrical height: 920 mm Previous application: Pharmaceuticals TANK Mounting type: Frame EQUIPMENT Manhole / Dome: in top bottom Outlet: 72 mm Comment: Signs of use Dodpfx Adoyckgfetscd
