CNC üniversal silindirik taşlama makinesi

Karstens K11 1000

Koşul: yeni gibi (sergi parçası), Üretim yılı: 2026, Karstens K11 1000 Premium Retrofit Cylindrical Grinding Machine Manufacturer: Karstens Technical Specifications: Centre distance: 1,100 mm Centre height: 180 mm / (250 mm optional) Workpiece weight: 100 kg (between centres), 300 kg (supported between centres) Grinding wheel diameter: 400 mm or 500 mm (external grinding wheel) Workpiece spindle: MT 4, infinitely variable speed 30-450 rpm, swivelling range 0 - 90° Tailstock: MT4, quill stroke 45 mm Quill force: 200-600 N manual (up to 2,500 N adjustable, optional) Table swivel: 10 degrees Cross slide travel: 80 mm Rapid traverse distance: 50 mm Coarse adjustment with air cushion: 280 mm External grinding spindle motor: 4 kW / (5.5 kW optional) Infinitely variable grinding wheel speed adjustment via potentiometer Internal grinding spindle motor: 2.2 kW Workpiece spindle motor: 1.1 kW Hydraulic motor: 1.5 kW Lubrication motor: 0.1 kW Redpfoiv Au Eox Ahljcb Hydraulic tank: 80 litres Machine weight: net 3,800 kg Infeed drive via DC motor Air cushion assisted rapid adjustment of the grinding spindle headstock for fast and safe positioning to the grinding location. Separate drives for external and internal grinding spindles. Fully automatic operation, infeed movement controlled by rotary selector switch: rapid approach, rapid retraction, grinding cycle, infeed stop, micron infeed. Automatic longitudinal grinding cycle. Central coolant supply for all grinding positions. Workpiece spindle headstock with infinitely variable drive for both rotating and lockable spindle. New digital infeed control with Siemens panel and Siemens PLC for longitudinal and plunge grinding, input for retraction, infeed amounts, feeds, spark-out times, idle strokes, compatible with old Karstens infeed control, with colour Siemens touch panel, scales in X and Z axis by HEIDENHAIN. Comparable to Weiss/ EMAG/ GP cylindrical grinding machines/ Studer/ Kellenberger/ Schaudt/ Tschudin/ Tacchella/ Dannobat/ Bahmüller / Fortuna

Koşul: yenilenmiş (kullanılmış), Üretim yılı: 2020, Maschinentyp: Rundschleifmaschine (Außenschleifen) Hersteller: Schaudt Maschinenbau GmbH Modell: PS 4 Baujahr: 1986 Generalsanierung/Retrofit: 2020 Steuerung (nach Retrofit): Siemens CNC SINUMERIK 840D Redpfjw Avrzsx Ahlscb Allgemeine Spezifikationen Anwendungsbereich: Außenzylindrisches Schleifen Schleifverfahren: Einstech-, Durchgangs- und Planschleifen Steuerungsart: CNC (Siemens-Modernisierung 2020) Maschinengewicht: ca. 3.500 – 4.500 kg Aufstellfläche: ca. 3,5 m x 2,0 m Werkstückkapazität Spitzenhöhe: 180 mm Spitzenweite: 1.000 mm (je nach Ausführung) Max. Werkstückdurchmesser: 360 mm Max. Werkstückgewicht zwischen Spitzen: ca. 150 kg Schleifspindel Schleifscheibendurchmesser: 400 mm Schleifscheibenbreite: 50 mm Bohrung: 127 mm Umfangsgeschwindigkeit: bis 45 m/s Antriebsleistung Schleifspindel: ca. 7,5 kW Drehzahlbereich: bis ca. 1.500 – 2.500 U/min (abhängig von Scheibengröße) Spindelstock Ausführung: Feststehende oder rotierende Spindel Drehzahlbereich (bei motorisiertem Spindelstock): ca. 30 – 500 U/min Spannkonus: MK4 oder vergleichbar Antrieb: AC-Servomotor (nach Retrofit) Reitstock Ausführung: Manuell oder hydraulisch betätigt Pinolenhub: ca. 50 mm Pinolendurchmesser: ca. 75 mm Achsen X-Achse (Schlittenzustellung): CNC-gesteuert Z-Achse (Längsschlitten): CNC-gesteuert Auflösung: 0,001 mm Antriebsart: digitale Servomotoren mit Kugelgewindetrieb Wegmesssysteme: Absolut-/Inkremental-Glasmaßstäbe Kühlsystem Kühlmitteltank: ca. 150 – 250 Liter Kühlmittelpumpe: Hochdruckausführung mit Filtersystem Weitere Merkmale (nach Retrofit) Siemens Bedienpanel mit Touch-Screen Elektronische Handräder (MPG) Modernisierte Sicherheitsausstattung und Einhausung Neuer Schaltschrank mit Belüftung und Kühlung Optionaler AE-Sensor zur Spalt- oder Abrichterkennung

Koşul: yenilenmiş (kullanılmış), Üretim yılı: 2026, Karstens K11 1000 Full Equipment The cylindrical grinding machine has been completely overhauled by PS-Karstens. The machine has been inspected and is in excellent condition. As we specialize in Karstens cylindrical grinding machines, we can offer you comprehensive service (electrical and mechanical) for the machine after your purchase. Technical specifications: • Center distance: 1000 mm • Center height: 180 mm • Workpiece weight: 100 kg between centers (unsupported), 250 kg between centers (supported) • Grinding wheel diameter: 400 mm • Workpiece spindle: MK 4, stepless speed adjustment 30-450 rpm, swivel range 0 - 90° • Tailstock: MK4, quill stroke 45 mm, fine adjustment with micrometer • Quill force: 200-600 N, hydraulically operated via foot pedal • Table swivel: 10 degrees • Infeed spindle travel: 80 mm • Rapid traverse: 50 mm • Coarse adjustment (air cushion): 280 mm • External grinding spindle motor: 4 kW • Internal grinding spindle motor: 2.2 kW Rjdpeh Riwdefx Ahljcb • Workpiece spindle motor: 0.55 kW • Net machine weight: 3,800 kg The infeed is driven by a DC motor. Air-cushion supported rapid adjustment of the grinding spindle head enables quick and safe positioning at the grinding point. Separate drives for external and internal grinding spindles. Fully automatic work cycle: infeed movement controlled via cam switch: rapid approach, rapid return, grinding operation, infeed stop, micron-level infeed. Automatic longitudinal grinding cycle. Central coolant supply for all grinding zones. Workpiece spindle head with steplessly adjustable drive for both live and lockable spindle operation. Infeed control for longitudinal and plunge grinding, programmable for return, infeed amounts, feeds, spark-out times, and idle strokes. Digital readouts for grinding spindle (B axis), workpiece spindle, X-axis, Z-axis by HEIDENHAIN. Paper band filtration unit, approx. 250 L capacity. Comparable to Weiss / EMAG / GP cylindrical grinding machines / Studer / Kellenberger / Schaudt / Tschudin / Tacchella / Dannobat / Bahmüller / Fortuna.

Koşul: yeni gibi (sergi parçası), Üretim yılı: 2026, Karstens K11 1000 Premium Retrofit Universal Cylindrical Grinding Machine Manufacturer: Karstens Technical Data: - Centre distance: 1100 mm - Centre height: 180 mm / (250 mm optional) - Workpiece weight: 100 kg between centers, 300 kg supported - Grinding wheel diameter: 400 mm or 500 mm (external grinding wheel) - Workpiece spindle: Morse taper 4 (MK 4), infinitely variable speed 30-450 rpm, swiveling range 0 - 90° - Tailstock: MK4, quill stroke 45 mm - Quill force: 200-600 N manual, (up to 2500 N adjustable, optional) - Table swivel angle: 10 degrees - Cross-slide travel: 80 mm - Rapid traverse: 50 mm - Coarse air cushion adjustment: 280 mm - External grinding spindle motor: 4 kW / (5.5 kW optional) - Continuously variable grinding wheel speed control via potentiometer - Internal grinding spindle motor: 2.2 kW - Workpiece spindle motor: 1.1 kW - Hydraulic motor: 1.5 kW - Lubrication motor: 0.1 kW - Hydraulic tank: 80 liters - Machine weight: net 3800 kg - Cross-feed driven by DC motor Rcsdpfxoh Rimms Ahleb - Air-cushion supported rapid positioning of the grinding spindle stock for fast and precise approach to the grinding position. - Separate drives for external and internal grinding spindles. - Fully automatic operation sequence, in-feed movement via rotary cam switch: rapid approach, rapid retraction, grinding mode, in-feed stop, mym(feeding). - Automatic longitudinal grinding cycle - Central coolant supply for all grinding points - Workpiece headstock with infinitely variable drive for both rotating and clamping modes. - New digital in-feed control with Siemens panel and Siemens PLC for longitudinal and plunge grinding, input for retraction, in-feed amounts, feed rates, spark-out times, idle strokes; compatible with old Karstens in-feed control, equipped with color Siemens touch panel - Comparable to Weiss/EMAG/GP-Cylindrical Grinding Machines/Studer/Kellenberger/Schaudt/Tschudin/Tacchella/Dannobat /Bahmüller/Fortuna

Koşul: ikinci el, KARSTENS K11-1000 USED CONVENTIONAL CYLINDRICAL GRINDING MACHINE FUNCTION TESTED The machine has been function tested; it is connected to power and can be demonstrated. Technical data: Distance between centers: 1000 mm Center height: 180 mm, Grinding diameter: 360 mm Grinding spindle motor: 4 kW Workpiece spindle motor: 0.55 kW Hydraulic motor: 1.5 kW Lubrication motor: 0.1 kW Hydraulic tank: 80 liters Feed drive via DC motor Air-cushion supported rapid adjustment of the grinding spindle head for fast and secure positioning to the grinding location. Fully automatic operation, infeed movement controlled via rotary switch: Rapid advance, rapid return, grinding operation, infeed stop, micron infeed. Automatic longitudinal grinding cycle Central coolant supply for all grinding zones Workpiece spindle head with infinitely variable drive for both rotating and lockable spindle operation. Internal grinding attachment Face grinding attachment Rcsdsy Ezbtspfx Ahlob
