Makaralı konveyör

Durumu: işlem için hazır (kullanılmış), Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: 516220V00316, Üretim yılı: 2019, çalışma saatleri: 6.820 h, yük kapasitesi: 1.600 kg, kaldırma yüksekliği: 3.180 mm, serbest kaldırma: 150 mm, Donanım: yan kaydırma, TECHNICAL DETAILS Load capacity: 1,600 kg Load center: 500 mm Load distance: 374 mm Wheelbase: 1,319 mm Lift height: 3,180 mm Free lift: 150 mm Length incl. fork back: 1,861 mm Fork thickness: 40 mm Fork width: 80 mm Fork length: 800 mm Fork carriage width: 980 mm Axle load with load front/rear: 4,160 / 565 kg Axle load without load front/rear: 1,500 / 1,625 kg Ground clearance with load under mast: 290 mm Ground clearance at wheelbase center: 114 mm Aisle width for pallet 1,000 x 1,200 (crosswise): 3,186 mm Aisle width for pallet 800 x 1,200 (lengthwise): 3,311 mm Turning radius: 1,487 mm Minimum pivot distance: 1,487 mm Mast height retracted: 2,160 mm Mast height extended: 3,742 mm Height above overhead guard: 2,035 mm Seat height: 1,058 mm Njdjyiaxzepfx Agfowc Coupling height: 473 mm MACHINE DETAILS Dimensions & Weight Dimensions: 2,661 x 1,099 x 2,160 mm Operating weight including battery: 3,125 kg Mast height extended: 3,742 mm Height above overhead guard: 2,035 mm Seat height: 1,058 mm Coupling height: 473 mm Voltage: 48 V Capacity: 625 Ah Operating hours: approx. 6,820 h EQUIPMENT UVV 04/26 Charger Side shifter Seat with seat heating Blue Spot front and rear LED headlights: 2x front, 1x rear Front windshield with wiper Panoramic roof Digital display Interior mirror Operating manual Note: Upholstery is worn.

Durumu: işlem için hazır (kullanılmış), Üretim yılı: 2004, çalışma saatleri: 18.183 h, Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: 15035709304, X ekseni hareket mesafesi: 700 mm, Y ekseni hareket mesafesi: 600 mm, Z ekseni hareket mesafesi: 520 mm, B ekseni dönme açısı (maks.): 180 °, C ekseni döndürme açısı (maks.): 360 °, The machine will remain connected to power until 06.03.2026. Nwodoymmpdepfx Agfec TECHNICAL DETAILS Travel - X axis: 750 mm Travel - Y axis: 600 mm Travel - Z axis: 520 mm C axis: ±360° B axis: 180° Spindle type: SK-40 Spindle speed: 18,000 rpm Rotary Table Clamping surface: 700 × 500 mm T-slot spacing: 63 mm Number of T-slots: 7 T-slot size: 14 H7 Centering hole: 30 H6 Rotary axis torque: max. 1,674 Nm Table plate speed: max. 21.5 rpm Swiveling torque: max. 2,019 Nm Swiveling speed: 18.9 rpm Swivel range: 0 – 180° Input and display unit: 0.001° Max. tool length from spindle nose: 315 mm Max. tool weight (with automatic tool change): 6 kg MACHINE DETAILS Control: Siemens 840D Shop Mill Operating hours Power-on hours: 65,794 h Spindle hours: 18,183 h Dimensions & Weight Machine dimensions (L x W x H): 2,604 x 2,820 x 2,785 mm Machine weight with floor plate: 9,255 kg EQUIPMENT 5-axis simultaneous machining 32-position tool changer Chip conveyor Coolant-through-spindle system with 70 bar pressure Blum TC50 spindle probe

Durumu: işlem için hazır (kullanılmış), Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: 516220V00299, Üretim yılı: 2019, çalışma saatleri: 6.310 h, yük kapasitesi: 1.600 kg, kaldırma yüksekliği: 3.180 mm, serbest kaldırma: 150 mm, direk tipi: dupleks, Donanım: yan kaydırma, TECHNICAL DETAILS Load capacity: 1,600 kg Load center: 500 mm Load distance: 374 mm Wheelbase: 1,319 mm Lift height: 3,180 mm Free lift: 150 mm Length incl. fork back: 1,861 mm Fork thickness: 40 mm Fork width: 80 mm Fork length: 800 mm Fork carriage width: 980 mm Axle load with load front/rear: 4,160 / 565 kg Axle load without load front/rear: 1,500 / 1,625 kg Ground clearance with load under mast: 290 mm Ground clearance at wheelbase center: 114 mm Aisle width for pallet 1,000 x 1,200 transverse: 3,186 mm Aisle width for pallet 800 x 1,200 lengthwise: 3,311 mm Turning radius: 1,487 mm Smallest turning circle: 1,487 mm Mast height retracted: 2,160 mm Nwedjyia Dkepfx Agfoc Mast height extended: 3,742 mm Height above protective roof: 2,035 mm Seat height: 1,058 mm Coupling height: 473 mm MACHINE DETAILS Dimensions & Weight Dimensions: 2,661 x 1,099 x 2,160 mm Service weight incl. battery: 3,125 kg Mast height extended: 3,742 mm Height above protective roof: 2,035 mm Seat height: 1,058 mm Coupling height: 473 mm Voltage: 48 V Capacity: 625 Ah Operating hours: approx. 6,310 h EQUIPMENT UVV 05/26 Charger Side shifter Seat with seat heating Blue Spot front and rear LED headlights: 2x front, 1x rear Front windshield with wiper Panoramic roof Digital display Interior mirror Operator’s manual

Durumu: işlem için hazır (kullanılmış), Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: 511903V00414, Üretim yılı: 2019, çalışma saatleri: 6.292 h, yük kapasitesi: 1.700 kg, kaldırma yüksekliği: 5.750 mm, serbest kaldırma: 1.880 mm, direk tipi: dupleks, TECHNICAL DETAILS Load capacity: 1,700 kg Load centre: 600 mm Load distance: 410 mm Wheelbase: 1,453 mm Free lift: 1,880 mm Lift height: 5,750 mm Nwjdpfsyh Eppox Agfoc Fork dimensions: 50 / 100 / 1,150 mm Fork carriage width: 760 mm Fork outside spread min./max.: 316 / 620 mm MACHINE DETAILS Dimensions & weight Dimensions (L x W x H): 2,412 x 1,270 x 2,900 mm Weight: 3,470 kg Length incl. fork back: 1,262 mm Height with mast extended: 6,320 mm Overhead guard height: 2,200 mm Seat height: 1,140 mm Height of outriggers: 308 mm Battery voltage/capacity: 48 V / 620 Ah Mast type: Duplex (side shift) Operating hours: approx. 6,292 h EQUIPMENT Charger Rear Blue Spot Operating manual UVV inspection: 06/26

Durumu: işlem için hazır (kullanılmış), Üretim yılı: 1997, Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: UWID/5000/97, taşlama mili hızı: 10.000 dev/dak, X ekseni ilerleme hızı: 20 m/dak, Y ekseni ilerleme hızı: 10 m/dak, Z ekseni ilerleme hızı: 20 m/dak, merkez yüksekliği: 150 mm, TECHNICAL DETAILS Travel Range X-Axis: 600 mm Travel Range Y-Axis: 250 mm Travel Range Z-Axis: 250 mm Feed Rate X-Axis: 0 – 20 m/min Feed Rate Y-Axis: 0 – 10 m/min Feed Rate Z-Axis: 0 – 20 m/min Nwjdpfx Agoyh I U Ijfsc Center Height: 150 mm Usable Table Area: 980 x 185 mm Grinding Head Swivel Range: 240° Swivel Speed: 120°/s Spindle Diameter: 170 mm Spindle Speeds: 2,000 – 10,000 rpm Workpiece Carrier A-Axis Indexing Accuracy: ± 15″ Cumulative Indexing Error (at ∅ 100 mm): 8 µm Mounting: ISO 50 Max. Rotational Speed: 50 rpm Position Feedback System Resolution: 0.0001 mm / 0.0001° Tool Magazine: 70 tools MACHINE DETAILS Control Unit: NUM 1050 M with PC; Program Memory: 512 KB Drive Ratings Grinding Spindle Motor: 10 kW Table Drive X-Axis: 1.5 kW Workpiece Carrier A-Axis: 1.5 kW Cross Slide Z-Axis: 1.5 kW Grinding Head Column Y-Axis: 3 kW Grinding Head Rotation B-Axis: 3 kW Electrical Connection Connected Load: 23 kW Main Fuse: 63 A Operating Voltage: 400 V, 50 Hz Control Voltage: 24 V Lighting Voltage: 230 V, 50 Hz Compressed Air Air Consumption: 10–12 Nm³/h Min/Max Pressure: 5/8 bar (500/800 kPa) Compressed Air Quality: ISO 8573-1, Class 4 Ambient Temperature Operation: 15°C – 35°C Weight: 7,400 kg Additional documentation for the machine is available upon request.

Durumu: kusurlu yedek parçası bulunmakta (kullanılmış), Üretim yılı: 2007, Fonksiyonellik: çalışmıyor, taşlama uzunluğu: 3.150 mm, taşlama genişliği: 800 mm, masa yükü: 6.000 kg, taşlama mili motor gücü: 22.000 W, iş parçası yüksekliği (maks.): 650 mm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Nwedpfoylk E Hjx Agfec Grinding length: 3,150 mm Grinding width: 800 mm Max. workpiece height: 650 mm Table surface dimensions: 3,150 x 600 mm Magnetic chuck dimensions: 3,000 x 600 mm Grinding wheel dimensions: 450 x 100 x 127 mm Max. table load: 6 t MACHINE DETAILS Control system: SIEMENS 840D Total power requirement: 70.6 kW Spindle power: 22 kW Dimensions & weight Required space: approx. 11 x 3 x 2.4 m Machine weight: approx. 15 t EQUIPMENT Coolant system 2,500 l Magnetic force control Semi-automatic balancing system Note: The control unit boots up. However, the MININI grinding software does not load for unknown reasons. The control hardware has been checked and is in proper working order. Backup files are available.

Durumu: işlem için hazır (kullanılmış), Üretim yılı: 2006, Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: H-H20140, X ekseni hareket mesafesi: 610 mm, Y ekseni hareket mesafesi: 510 mm, Z ekseni hareket mesafesi: 610 mm, dönüş hızı (maks.): 15.000 dev/dak, takım magazinindeki yuva sayısı: 24, TECHNICAL DETAILS Travel X: 610 mm Travel Y: 510 mm Travel Z: 610 mm Table size: 760 mm x 510 mm Taper: SK40 Nwodpfx Aoylk Eysgfsc Spindle speed: 15,000 rpm MACHINE DETAILS Machine weight: 4,700 kg Control: Ultimax EQUIPMENT 24-position tool changer Internal coolant supply (IKZ) Chip conveyor Electronic handwheel

Durumu: işlem için hazır (kullanılmış), Üretim yılı: 2020, Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: 286.001.911.20, çalışma genişliği: 3.000 mm, çalışma uzunluğu: 6.000 mm, kontrolör modeli: Global Control S mit 15 Zoll Farb-Touchscreen, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Working area: 3,000 x 6,000 mm Number of cutting torches: 2 Gas flow control: available MACHINE DETAILS Installation footprint: 9,000 x 5,000 x 2,000 mm Control unit: Global Control S with 15" color touchscreen Electrical Data Voltage: 3 x 400 V PE/N Nwjdpfx Aeyi Ub Hsgfjc Frequency: 50 Hz Power: 9 kVA IMPORTANT: The Zinser cutting table is NOT included in the scope of delivery! EQUIPMENT as per original invoice – details without guarantee Joystick and handwheel for Global Control S panel Cabinet cooling Laser diode Heat shield without air cooling Track for dual-sided longitudinal drive HEB 9 m OmniFlow oxy-fuel supply up to 70 m³/h ALFA machine cutting torch with internal ignition SmartLifter 200 SensoMat ARKI Full gas addressing Photoelectric sensors Safety equipment: wheel arch and foot pedal Energy supply via autogen energy chain 9 m Driver for energy chain Further technical data from the manufacturer – information without guarantee: Track gauge: 4,000 mm Chain height: 500 mm Positioning speed: 50 m/min Speed: max. 35 m/min Dimensions & Weight Dimensions (L x W x H): 1,940 x 5,070 x 1,980 mm Machine weight: 2,200 kg

Durumu: işlem için hazır (kullanılmış), Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: 516220V00315, Üretim yılı: 2019, çalışma saatleri: 6.239 h, yük kapasitesi: 1.600 kg, kaldırma yüksekliği: 3.180 mm, serbest kaldırma: 150 mm, direk tipi: dupleks, Donanım: yan kaydırma, TECHNICAL DETAILS Load capacity: 1,600 kg Load center: 500 mm Load distance: 374 mm Wheelbase: 1,319 mm Lift height: 3,180 mm Free lift: 150 mm Length including forks: 1,861 mm Fork thickness: 40 mm Fork width: 80 mm Fork length: 800 mm Fork carriage width: 980 mm Axle load with load front/rear: 4,160 / 565 kg Axle load without load front/rear: 1,500 / 1,625 kg Ground clearance with load under mast: 290 mm Ground clearance at wheelbase center: 114 mm Aisle width for 1,000 x 1,200 mm pallet crosswise: 3,186 mm Aisle width for 800 x 1,200 mm pallet lengthwise: 3,311 mm Turning radius: 1,487 mm Minimum pivot point distance: 1,487 mm Nwjdjyia Hfjpfx Agfoc Mast height retracted: 2,160 mm Mast height extended: 3,742 mm Height over protective roof: 2,035 mm Seat height: 1,058 mm Coupling height: 473 mm MACHINE DETAILS Dimensions & Weight Dimensions: 2,661 x 1,099 x 2,160 mm Own weight including battery: 3,125 kg Mast height extended: 3,742 mm Height over protective roof: 2,035 mm Seat height: 1,058 mm Coupling height: 473 mm Voltage: 48 V Capacity: 625 Ah Operating hours: approx. 6,239 h EQUIPMENT UVV 04/26 Battery charger Side shifter Seat with seat heating Blue Spot front and rear LED headlights: 2x front, 1x rear Windscreen with wiper Panoramic roof Digital display Interior mirror Operating manual Note: Upholstery is worn.

Durumu: işlem için hazır (kullanılmış), Üretim yılı: 2012, Fonksiyonellik: tamamen fonksiyonel, toplam uzunluk: 90.000 mm, X ekseni hareket mesafesi: 2.600 mm, Y ekseni hareket mesafesi: 4.000 mm, masa uzunluğu: 4.000 mm, masa genişliği: 2.600 mm, TECHNICAL DETAILS Travel X-axis: 2,600 mm Travel Y-axis: 4,000 mm Table length: 4,000 mm Table width: 2,600 mm Maximum glass weight: 260 kg Glass thickness: 4 - 10 mm Nwjdpfxeyk S Uys Agfsc MACHINE DETAILS Cycle time: 10 pieces/hour Cabin type: SUP-E2-D107/20000 + "D" Total length of the production line: 90 m Installed power: 1,100 kW EQUIPMENT Loading station with lifter Vertical inlet conveyor WM Vertical washing machine with drying Vertical inspection conveyor with activation section Tilting table with horizontal transport and vertical inspection Preheating section Powder section with belt cleaning Cleaning conveyor Cooling section Tilting table with vertical and horizontal transport Vertical inspection station Unloading station Electrical distribution Deionized water system for washing machine supply The ovens that may be visible in the pictures are not included in the scope of delivery or sale.
