Bantlı konveyör

Durum: işlem için hazır (kullanılmış), Üretim yılı: 1973, Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: 162 026, X ekseni hareket mesafesi: 3.000 mm, Y ekseni hareket mesafesi: 2.000 mm, Z ekseni hareket mesafesi: 1.250 mm, masa yükü: 15.000 kg, TEKNİK ÖZELLİKLER X ekseni hareket mesafesi: 3.000 mm Y ekseni hareket mesafesi: 2.000 mm Z ekseni hareket mesafesi: 1.250 mm W ekseni hareket mesafesi (Kılavuz mil hareketi): 700 mm Tabla boyutu: 2.000 × 1.500 mm Tabla taşıma kapasitesi: 15.000 kg Tabla dönüşü: 360° Tabla indeksleme: 1° Mil hızı: 8–800 devir/dakika MAKİNE ÖZELLİKLERİ Konum ölçüm sistemi: Heidenhain doğrusal ölçekler Pgedpsz Ahabsfx Ak Hot EKİPMAN Heidenhain doğrusal ölçekler

Durum: işlem için hazır (kullanılmış), Üretim yılı: 1995, Fonksiyonellik: tamamen fonksiyonel, Çubuk çapı (maks.): 32 mm, torna boyu: 80 mm, dönme hızı (dk.): 3.150 dev/dak, delme derinliği: 80 mm, No reserve price – guaranteed sale to the highest bidder! The machine is sold with collets, holders, and additional accessories! For more Schütte multi-spindle machines from the same location, see below! TECHNICAL DETAILS Maximum turning length: 80 mm Maximum drilling depth: 80 mm Maximum material passage: 32 mm Maximum material feed: 125 mm Turning speed: 200–3,150 rpm Thread cutting speed (right-hand): 11.2–1,575 rpm Thread cutting device: Right-hand threads by undercutting MACHINE DETAILS Coolant capacity: 600 l Pump capacity: 170 l/min Dimensions & Weight Required floor space: 7.3 x 2.5 m Height: 2 m Weight: 8,300 kg Voltage: 380 V Frequency: 50 Hz Main drive: 20.5 kW Immersion pump: 1.5 kW Feed drive: 1.5 kW Hydraulic pump: 1.5 kW Circulation oil pump: 0.25 kW EQUIPMENT 6 cross slides 6 longitudinal slides 6 cams for cross slides 6 cams for longitudinal slides Operator tools Collets Pgodpjz Ag A Iofx Ak Hjt Holders Additional accessories

Durum: işlem için hazır (kullanılmış), Üretim yılı: 1992, Fonksiyonellik: tamamen fonksiyonel, Çubuk çapı (maks.): 32 mm, torna boyu: 80 mm, delme derinliği: 80 mm, No reserve price – guaranteed sale to the highest bidder! The machine is sold with collets, tool holders, and additional accessories! For more Schütte multi-spindle machines available from the same location, see below! TECHNICAL DETAILS Maximum turning length: 80 mm Podpfx Aksz Ag Ans Hsgt Maximum drilling depth: 80 mm Maximum round bar diameter: 32 mm Maximum square bar diameter: 22 mm Maximum hexagonal bar diameter: 27 mm Maximum octagonal bar diameter: 29 mm Spindle pitch circle diameter: 300 mm Standard bar feed: 125 mm Special bar feed: 290 mm Standard longitudinal slide total travel: 100 mm Standard longitudinal slide working travel: 80 mm Special longitudinal slide total travel: 145 mm Special longitudinal slide working travel: 115 mm Cross slide upper slide total travel: 50 mm Cross slide upper slide working travel: 33 mm Cross slide middle slide total travel: 50 mm Cross slide middle slide working travel: 30 mm Cross slide lower slide total travel: 60 mm Cross slide lower slide working travel: 37.5 mm Maximum material passage: 32 mm Maximum material feed: 125 mm MACHINE DETAILS Voltage: 400 V Frequency: 50 Hz Coolant capacity: 700 l Pump: submersible pump (E-type) Pump capacity: 180 l/min EQUIPMENT High-speed drilling unit Gripper unit Reaming unit Independent additional longitudinal control Motorized cross-slide adjustment Collets Tool holders Additional accessories

Durum: işlem için hazır (kullanılmış), Üretim yılı: 1992, Fonksiyonellik: tamamen fonksiyonel, Çubuk çapı (maks.): 32 mm, torna boyu: 80 mm, delme derinliği: 80 mm, No reserve price – guaranteed sale to the highest bidder! The machine is sold complete with collets, holders, and additional accessories! For more Schütte multi-spindle machines being sold from the same location, see below! TECHNICAL DETAILS Maximum turning length: 80 mm Maximum drilling depth: 80 mm Maximum round bar diameter: 32 mm Maximum square bar diameter: 22 mm Maximum hexagonal bar diameter: 27 mm Maximum octagonal bar diameter: 29 mm Spindle circle diameter: 300 mm Standard bar feed length: up to 125 mm Special bar feed length: up to 290 mm Standard longitudinal slide travel, total: 100 mm Standard longitudinal slide travel, working stroke: 80 mm Special longitudinal slide travel, total: 145 mm Special longitudinal slide travel, working stroke: 115 mm Top cross slide travel, total: 50 mm Top cross slide travel, working stroke: 33 mm Middle cross slide travel, total: 50 mm Middle cross slide travel, working stroke: 30 mm Bottom cross slide travel, total: 60 mm Bottom cross slide travel, working stroke: 37.5 mm Maximum workpiece passage: 32 mm Maximum material feed: 125 mm MACHINE DETAILS Voltage: 400 V Frequency: 50 Hz Coolant capacity: 700 L Pump: Submersible pump Pgjdpfoz Ag Abex Ak Hot Pump output: 180 L/min EQUIPMENT High-speed drilling unit Gripper device Reaming unit Independent auxiliary longitudinal control Motorised cross slide adjustment Collets Holders Additional accessories

Durum: işlem için hazır (kullanılmış), Üretim yılı: 1991, Fonksiyonellik: tamamen fonksiyonel, Çubuk çapı (maks.): 32 mm, torna boyu: 80 mm, dönüş hızı (maks.): 3.150 dev/dak, delme derinliği: 80 mm, No reserve price – guaranteed sale to the highest bidder! The machine is sold with collets, tool holders, and additional accessories! For more Schütte multi-spindle machines from the same location, see below! TECHNICAL DETAILS Maximum bar capacity: 32 mm Maximum bar feed: 125 mm Maximum turning length: 80 mm Maximum drilling depth: 80 mm Spindle speed for turning: 200–3,150 rpm Spindle speed for right-hand threading: 11.2–1,575 rpm MACHINE DETAILS Coolant capacity: 600 l Pump capacity: 170 l/min Dimensions & Weight Floor space required: 7.3 x 2.5 m Height: 2 m Weight: 8,300 kg Voltage: 380 V Frequency: 50 Hz Main drive: 20.5 kW Immersion pump: 1.5 kW Feed drive: 1.5 kW Hydraulic pump: 1.5 kW Circulation oil pump: 0.25 kW Pgjdpfx Aoz Agz Dok Hst EQUIPMENT 6 cross slides 6 longitudinal slides 6 cams for cross slides 6 cams for longitudinal slides Operating tools Collets Tool holders Additional accessories

Durum: işlem için hazır (kullanılmış), Üretim yılı: 1983, Fonksiyonellik: tamamen fonksiyonel, maksimum mil hızı: 3.150 dev/dak, Çubuk çapı (maks.): 32 mm, toplam ağırlık: 8.300 kg, No minimum price – guaranteed sale to the highest bidder! The machine is sold complete with collets, holders, and additional accessories! For more Schütte multi-spindle machines available from the same location, see below! Pgsdsz Agzqopfx Ak Het TECHNICAL DETAILS Maximum bar diameter round: 32 mm Maximum bar diameter square: 22 mm Maximum bar diameter hexagonal: 27 mm Maximum bar diameter octagonal: 29 mm Spindle pitch circle diameter: 300 mm Bar feed normal/special up to: 125 / 290 mm Longitudinal slide travel normal, total/travel stroke: 100 / 80 mm Longitudinal slide travel special, total/travel stroke: 145 / 115 mm Cross slide travel upper slide, total/travel stroke: 50 / 33 mm Cross slide travel middle slide, total/travel stroke: 50 / 30 mm Cross slide travel lower slide, total/travel stroke: 60 / 37.5 mm Number of spindle speeds: 49 Spindle speed range I: 450–3,150 rpm Spindle speed range II: 200–1,400 rpm Workpiece revolutions per cycle, normal: 60–425 Workpiece revolutions per cycle, short: 33.5–236 Workpiece revolutions per cycle, extended: 95–670 Number of main times per spindle speed: 35 MACHINE DETAILS Nominal motor power: 18.5 kW Motor speed: 1,500 rpm Dimensions incl. control cabinet (L x W): 3,850 x 1,510 mm Length with bar feeder: 6,453 mm Machine weight: 8,300 kg Space requirement for packaged machine: 15 m³ EQUIPMENT Collets Holders Additional accessories

Durum: işlem için hazır (kullanılmış), Üretim yılı: 1982, Fonksiyonellik: tamamen fonksiyonel, maksimum mil hızı: 3.150 dev/dak, Çubuk çapı (maks.): 32 mm, toplam ağırlık: 8.300 kg, No reserve price – guaranteed sale to the highest bidder! The machine is sold including collets, tool holders, and additional accessories! For more Schütte multi-spindle machines available at the same location, see below! Podpfez Agzdox Ak Hjgt TECHNICAL DETAILS Maximum bar diameter round: 32 mm Maximum bar diameter square: 22 mm Maximum bar diameter hexagonal: 27 mm Maximum bar diameter octagonal: 29 mm Spindle pitch circle diameter: 300 mm Bar feed normal/special up to: 125 / 290 mm Longitudinal slide travel normal, total/traverse: 100 / 80 mm Longitudinal slide travel special, total/traverse: 145 / 115 mm Cross slide travel upper slide, total/traverse: 50 / 33 mm Cross slide travel middle slide, total/traverse: 50 / 30 mm Cross slide travel lower slide, total/traverse: 60 / 37.5 mm Number of spindle speeds: 49 Spindle speed range I: 450–3,150 rpm Spindle speed range II: 200–1,400 rpm Workpiece revolutions per cycle, normal: 60–425 Workpiece revolutions per cycle, short: 33.5–236 Workpiece revolutions per cycle, extended: 95–670 Number of main cycle times per spindle speed: 35 MACHINE DETAILS Drive motor: 18.5 kW Drive motor speed: 1,500 rpm Dimensions & Weight Dimensions with control cabinet (L x W): 3,850 x 1,510 mm Length with bar feeder: 6,453 mm Machine weight: 8,300 kg Required space for packed machine: 15 m³ EQUIPMENT Collets Tool holders Additional accessories

Durum: işlem için hazır (kullanılmış), Üretim yılı: 1992, Fonksiyonellik: tamamen fonksiyonel, maksimum mil hızı: 3.750 dev/dak, Çubuk çapı (maks.): 26 mm, toplam ağırlık: 6.800 kg, No reserve price – guaranteed sale to the highest bidder! The machine is being sold with collets, tool holders, and additional accessories! For further Schütte multi-spindle machines from the same location, please see below! TECHNICAL DETAILS Bar diameter, round: 26 mm Bar diameter, square: 19 mm Bar diameter, hexagonal: 22 mm Bar diameter, octagonal: 24 mm Spindle pitch circle diameter: 270 mm Standard bar feed: 125 mm Special bar feed: 290 mm Total longitudinal slide travel, standard: 80 mm Working travel, standard: 63 mm Total longitudinal slide travel, special: 125 mm Working travel, special: 98 mm Cross slide travel, upper slide total: 40 mm Cross slide working travel, upper slide: 25 mm Cross slide travel, middle slide total: 40 mm Cross slide working travel, middle slide: 25 mm Cross slide travel, lower slide total: 50 mm Cross slide working travel, lower slide: 31 mm Number of spindle speeds: 49 Spindle speed range I: 530–3,750 rpm Spindle speed range II: 236–1,700 rpm Workpiece revolutions per cycle, standard: 60–425 Pedpfx Asz Agy Hsk Hsgt Workpiece revolutions per cycle, short cycle: 33.5–236 Workpiece revolutions per cycle, long cycle: 95–670 Number of main times per spindle speed: 35 MACHINE DETAILS Rated power, drive motor: 18.5 kW Drive motor speed: 1,500 rpm Dimensions & Weight Dimensions with control cabinet (L x W): 3,500 x 1,450 mm Total length with bar guide: 6,470 mm Machine weight: 6,800 kg Space required for packed machine: 14 m³

Durum: işlem için hazır (kullanılmış), Üretim yılı: 2017, çalışma saatleri: 9.800 h, Fonksiyonellik: tamamen fonksiyonel, X ekseni hareket mesafesi: 1.200 mm, Y ekseni hareket mesafesi: 600 mm, Z ekseni hareket mesafesi: 630 mm, kontrolör modeli: Heidenhain 530, maksimum mil hızı: 15.000 dev/dak, TEKNİK ÖZELLİKLER X ekseni hareket mesafesi: 1.200 mm Y ekseni hareket mesafesi: 600 mm Z ekseni hareket mesafesi: 630 mm Maksimum mil devri: 15.000 devir/dakika Psdpfez Apd Uox Ak Hjgt Takım tutucu: BT40 MAKİNE ÖZELLİKLERİ Kontrol sistemi üreticisi: Heidenhain 530 Çalışma saati: 9.800 saat Makine ağırlığı: yaklaşık 7.700 kg EKİPMAN Talaş taşıma sistemi

Durum: işlem için hazır (kullanılmış), Üretim yılı: 2011, çalışma saatleri: 16.140 h, Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: 111214, X ekseni hareket mesafesi: 1.100 mm, Y ekseni hareket mesafesi: 610 mm, Z ekseni hareket mesafesi: 610 mm, kontrolör modeli: Heidenhain 530, toplam ağırlık: 7.800 kg, TEKNİK ÖZELLİKLER X ekseni hareket mesafesi: 1.100 mm Y ekseni hareket mesafesi: 610 mm Z ekseni hareket mesafesi: 610 mm Takım değiştiricinin kapasitesi: 30 Masa boyutları: 1250 x 610 mm Pedpfjz Apdzjx Ak Hogt MAKİNE ÖZELLİKLERİ Kontrol ünitesi: Heidenhain 530 Çalışma saati: 16.140 saat Makine ağırlığı: Yaklaşık 7.800 kg
