Geçişli delme makinesi 2800 mm

MAGGI BORING SYSTEM 240 5V PLUS

Factory-new machine, only used for testing purposes, in perfect condition.

TECHNICAL DESCRIPTION
Chedpfx Ajxd Ruwed Ujc
The DIGIT MAGGI through-feed drilling machine is an automatic, multi-head through-feed drilling machine equipped with 2 horizontal and 6 vertical heads, designed for high-volume production.

TECHNICAL DATA

- Number of horizontal heads: 2
- Number of vertical heads: 6
- Minimum distance between vertical heads: 165 mm
- Minimum distance between horizontal heads: 320 mm
- Spindle pitch: 32 mm
- Number of spindles on horizontal head (left red - right black): 23 (11 - 12)
- Number of spindles on vertical head (left red - right black): 11 (5 - 6)
- Maximum vertical drilling depth: 55 mm
- Maximum horizontal drilling depth: 65 mm
- Maximum workpiece dimensions: 2800 x 870 x 50 mm
- Minimum workpiece dimensions: 250 x 150 x 12 mm
- Number of motors: 12
- Power of horizontal head motor: 2 HP (1.5 kW)
- Power of vertical head motor: 1.5 HP (1.1 kW)
- Number of clamps: 10
- Feed speed of loading device: 57 m/min
- Working air pressure: 6-8 bar
- Standard air consumption: 60 l/cycle
- Maximum clamp height from working table: 75 mm
- Overall dimensions: 4150 x 1600 x 1800 mm
- Working table height: 950 mm
- Packaging dimensions: 4300 x 1950 x H 1900 mm
