Tam otomatik katlama merkezi

RAS MiniBendCenter 79.05

Refurbished RAS MiniBendCenter 79.05

Technical data
Chedpfx Ajxlgrbod Uoc
Sheet length: 50–600 mm
Sheet width: 40–600 mm
Max. sheet thickness (400 N/mm²), depending on tooling: 3.0 mm
Max. upper beam stroke: 500 mm
Minimum leg height (standard, depending on tooling): 5 mm x s
Maximum leg height: 127 mm
Bending cell weight: 10 tons
Cladding and electrical weight: approx. 2027 kg
Machine elements weight: approx. 945 kg
Motor control: 400V, 50/60 Hz, 3-phase
Year of manufacture: 2015
Condition: refurbished – good used condition

Bending cell:

Automatic sheet thickness adjustment
Automatic tool clamping
Blank scanner

Main manipulator:
3 servo motors for X, Y, Z axes
1 servo motor for lower rotation axis + separate drive for rotation axis
Double sheet detection

Tool changer:
3 servo motors for X, Y, Z axes
1 pneumatic swivel drive for rotation axis
Tool gripper
2-level tool magazine
Automatic tool clamping in the tool magazine

Cladding:
Front and rear enclosure of the bending cell

Movable control panel:
18" Touch & More control unit

Pallet station:
Roller conveyors and heavy-duty chain conveyors
1 space for new pallets (parts to be processed)
1 space for "pallet in process"
2 spaces for finished pallets (empty or with remaining quantity)

Additional equipment:
Intelligent loading robot
Combined camera-scanner system
Analysis software
Transfer table, Sauerfeld (52x9mm) suction cup series (7x20mm)
Conveyor bend with 6 connection stations
Cladding for finished part discharge
Complete tool set
RAS CAM-Office software incl. SolidWorks license and maintenance contract for 2 years

This high-quality used RAS MiniBendCenter 79.05 offers you proven quality at an attractive price and is available directly from the manufacturer. It is a fully automated bending center specifically designed for the efficient processing of small parts. It comes with a factory warranty including maintenance and the latest software version. Featuring advanced technology such as automatic sheet thickness regulation, an intelligent loading robot, and a powerful control system, it optimizes your production and reduces costs. Benefit from high flexibility and rapid depreciation thanks to automated processes and versatile configuration.

Bu ilan otomatik olarak tercüme edildiğinden bazı çeviri hataları oluşmuş olabilir.
