Dört taraflı planya makinesi WEINIG tip Powermat 600

Weinig Powermat 600

Durumu: kullanılmış, Üretim yılı: 2014, Number of spindles: 5 pcs Working width: 230 mm Planing height: 120 mm Surface table length: 2,500 mm Feed motor: 4 kW Feed speed: 5–30 m/min Control: Memory function Weinig Powermat 600 Compact ----- Machine will be cleaned and thoroughly inspected. Short summary: ----- - 5 spindles - Powerful motors - Left and top spindle motorized and controlled for width and height Detailed description: ----- Technical specifications: Working width: 20–230 mm Working height: 10–120 mm Number of spindles: 5 1st spindle – bottom ----- Motor with brake: 7.5 kW Spindle diameter: 40 mm Speed: 6,000 rpm Tool cutting circle: 125–145 mm Tool cutting circle rebate cutter: 130–160 mm Axial adjustment travel: 5 mm Rebate unit MarathonCoating for table insert in front of 1st lower tool holder Electronic digital readout for radial adjustment 2nd spindle – right ----- Motor with brake: 11.0 kW Shared motor with left tool holder Spindle diameter: 40 mm Speed: 6,000 rpm Tool cutting circle 40 mm below table level: 93–200 mm Tool cutting circle 55 mm below table level: 93–180 mm Max. tool cutting circle for straight knife heads: 163 mm Max. tool diameter behind fence level: 180 mm Max. profiling depth: 35 mm Axial adjustment travel: 55 mm 3rd spindle – left ----- Motor with brake: Shared motor with 2nd spindle Spindle diameter: 40 mm Speed: 6,000 rpm Tool cutting circle 40 mm below table level: 93–200 mm Tool cutting circle 55 mm below table level: 93–180 mm Max. tool cutting circle for straight knife heads: 163 mm Max. profiling depth: 35 mm Axial adjustment travel: 55 mm Spindle radial CNC-controlled 4th spindle – top ----- Motor with brake: 11.0 kW Spindle diameter: 40 mm Speed: 6,000 rpm Tool cutting circle: 93–200 mm Max. tool cutting circle for straight knife heads: 180 mm Max. profiling depth: 35 mm Axial adjustment travel: 40 mm Spindle radial CNC-controlled Divided pressure shoe in front of upper tool holder, adjustable to the tool cutting circle and can be swung away from the tool, spring-loaded. Pressure shoe in front of and discharge after the top spindle with electronic digital readouts, integrated into the memory function or PowerCom 5th spindle – bottom ----- Motor with brake: 7.5 kW Spindle diameter: 40 mm Speed: 6,000 rpm Tool cutting circle: 93–200 mm Max. profiling depth: 15 mm Axial adjustment travel: 35 mm Codpfjwzmu Rex Ad Ushc Feed system ----- Electronic feed, infinitely variable with brake: 4 kW, 5–30 m/min Infeed roller in front of first lower tool pneumatically controlled high/low Durofer pointed tooth rollers with depth limiter and self-cleaning Adjustment path of feed rollers in relation to left tool holder, axial 35 mm Machine electrics ----- Operating voltage: 400 V (voltage range 380–420 V), 50 Hz All spindles IE2 efficiency class Electrical equipment according to DIN VDE 0113, electrical equipment of industrial machinery EN60204, IEC-204-1. No additional electrical regulations considered. Mach...

Durumu: işlem için hazır (kullanılmış), Üretim yılı: 2014, Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: 119676, çalışma genişliği: 230 mm, çalışma yüksekliği: 120 mm, iş mili çapı: 40 mm, dönüş hızı (maks.): 6.000 dev/dak, TEKNİK DETAYLAR Çalışma yüksekliği: 8/120 mm Çalışma genişliği: 20/230 mm Çalışma hızı: 5/30 m/dak Mil hızı: 6.000 rpm Mil çapı: 40 mm MAKİNE DETAYLARI Boş ağırlık: 2.500 kg Boyutlar (U x G x Y): 3.620 x 2.140 x 1.650 mm Toplam güç: 41 kW Üretim yılı: 2014 Seri numarası: 119676 CE işareti mevcut: Evet Ekipman Mil - yatay alt Mil - dikey sağ Mil - dikey sol Mil - yatay üst Mil - yatay alt Belgeler mevcut: Hayır Taşıma boyutları: 3.620 mm x 2.140 mm x 1.650 mm Taşıma ağırlığı: 2.500 kg Taşıma paketleri: 1 Cjdpfewtddtox Ad Ujhc Ek seçenekler: Titreşim izleme Makine lambası Hız algılama Saat sayacı Panel yağlama

Durumu: mükemmel (kullanılmış), Üretim yılı: 2014, Fonksiyonellik: tamamen fonksiyonel, Küçük Powermat 600 Chodsv Dac Iepfx Ad Uoc 2014 üretim yılı 5 iğ 3 kW besleme motoru 1 motor 7,5 kW 2 motor 11 kW 3 motor 7,5 kW 4 motor 7,5 kW mil yapılandırması - alt, sağ, sol, üst, alt yumuşak başlangıç ısıtmalı kontrol kabini (webasto) pnömatik masalar tezgahların manuel kontrolü elektronik frenler manuel eksen ayarı düzgün besleme düzenlemesi
