Aidt
Aidt dan Tehran
Bu satıcı henüz bir firma açıklaması eklemedi.
Sn. (Bay) Meysam Amini
No. 2, unit 4, Koche Niko, Qaitarieh St
1938853461 Tehran
İran
Benzer satıcılardan güncel teklifler
Küçük ilan
Wrocław
1.962 km
Enjeksiyon kalıplama makinesi
KraussMaffeiKM 1300-12000 MX
KraussMaffeiKM 1300-12000 MX
Çağrı
Koşul: mükemmel (kullanılmış), Üretim yılı: 2012, Krauss Maffei KM 1300-12000 MX Injection Moulding Machine
Control system: MC5
Year of manufacture: 2012
Clamping unit:
Clamping force [kN]: 13,000
Platen dimensions (h x v) [mm]: 2,210 x 1,910
Tie bar clearance (h x v) [mm]: 1,570 x 1,270
Min./max. mould height [mm]: 700–1,400
Maximum daylight opening [mm]: 3,050
Maximum ejector stroke [mm]: 350
Injection unit:
Screw diameter [mm]: 105
Injection volume [cm³]: 5,195
Shot weight PS [g]: 4,728
Injection pressure [bar]: 2,296
Maximum injection speed [g/s PS]: 186
Electrical–hydraulic equipment:
Rated pump motor power [kW]: 132
Rated screw drive power [kW]: 145
Heater capacity [kW]: 71
Dimensions and weight:
Net weight with control cabinet [t]: 70
Dimensions (L x W x H) [m]: 13.03 x 3.65 x 2.82
Additional equipment:
Parallel movements: Independent hydraulic screw drive
Hot runner: 12 integrated temperature control zones
Core pull: 3 hydraulic circuits (2 on the moving platen, 1 on the fixed platen)
Pneumatics: 2 air valves (blow-off) + 1 valve for hot runner needle control
Hydraulic accumulator
Cooling: 20-rotameter system (10 for the fixed platen + 10 for the moving platen)
Pgsdpfjy Hqwysx Anxjk
Interfaces: Euromap 67 and Euromap 18
Insulation: BluePower – barrel thermal insulation
Küçük ilan
Trenčianske Stankovce
1.760 km
Krauss Maffei KM1300 - 8100 MX (2016)
KraussMaffeiKM1300 - 8100 MX
KraussMaffeiKM1300 - 8100 MX
Çağrı
Koşul: mükemmel (kullanılmış), Üretim yılı: 2016, sıkıştırma kuvveti: 13.000 kN, Sıkıştırma kuvveti: 1300 t
Vidalı mil çapı: 105 mm
Kılavuzlar arası mesafe V: 1270 mm
Kılavuzlar arası mesafe H: 1570 mm
Vuruş hacmi: 4546 cm³
Tip: Yatay
Tahrik: Hidrolik
KM1300 - 8100 MX
Üretim yılı: 2016
KM1300MX
Kapatma kuvveti (ton): 1300
Piston kolu aralığı: 1570 x 1270 mm
Kalıp yüksekliği min/maks: 700/1400 mm
Plaka ölçüleri: 2210 x 1910 mm
Açma strok: 2350 mm
Maks. açılma mesafesi: 3050 mm
Enjeksiyon ünitesi tipi 8100 MX
Vidalı mil çapı: 105 mm
Pgjdpfx Ajy Emursnxjk
Maks. enjeksiyon hacmi: 4546 cm³
Öz. enjeksiyon basıncı: 1778 bar
Merkezleme halkası ölçüsü: 315 mm
Hidrolik çekirdekler: 4 + 4
Kalıp için ısıtıcı sayısı: 32
Soğutma devreleri: 8+8
Elektriksel kaskadlar: 12
Soğutma: 12 + 12
Hidrolik sıcak yolluk: 1x EUROMAP 6
Küçük ilan
İtalya
2.465 km
ITALTECH KS 1200 8300 ES
ITALTECHKS 1200 8300 ES
ITALTECHKS 1200 8300 ES
Çağrı
Koşul: işlem için hazır (kullanılmış), Üretim yılı: 2011, sıkıştırma kuvveti: 11.772 kN, vida çapı: 130 mm, enjeksiyon ağırlığı: 6.210 g, toplam ağırlık: 70.000 kg, Hidrolik enjeksiyon kalıplama makinesi 2011 yılında üretilmiştir. Bu ITALTECH KS 1200 8300 ES, 130 mm'lik bir vida çapına ve 11.772 kN'lik bir sıkıştırma kuvvetine sahiptir. Atış hacmi 8630 cm³ ve maksimum enjeksiyon basıncı 1460 bar'dır. Yüksek kaliteli enjeksiyon kalıplama yetenekleri elde etmek istiyorsanız, satılık ITALTECH KS 1200 8300 ES makinesini düşünün. Daha fazla ayrıntı için bizimle iletişime geçin.
Enjeksiyon Ünitesi
• Enjeksiyon ünitesi boyutu: 8300
• L/D oranı: 20
Pgsdpey Dua Tjfx Anxek
• Atış hacmi (teorik): 8,630 cm³
• Maksimum enjeksiyon basıncı: 1,460 bar
• Enjeksiyon akış hızı: 1.200 cm³/s
• Vida hızı: 110 rpm'ye kadar
• Vida torku: 8.400 Nm
• Plastikleştirme kapasitesi (HDPE): 140 g/s
• Isıtma kapasitesi: 79 kW
• Sıcaklık kontrol bölgeleri: 5 + 1Sıkıştırma Ünitesi
• Sıkıştırma kuvveti: 11,772 kN (~1,200 t)
• Açılma kuvveti: 300 kN
• Minimum kalıp yüksekliği ile açılma stroku: 2000 mm
• Maksimum kalıp yüksekliği ile açma stroku: 1400 mm
• Kalıp yüksekliği: 600-1.200 mm
• Maksimum gün ışığı: 2.600 mmMerdane ve Ejektör
• Merdane boyutu (G x Y): 1.900 x 1.770 mm
• Bağlantı çubukları arasındaki mesafe (G x Y): 1.250 x 1.120 mm
• Bağlantı çubuğu çapı: 220 mm
• Ejektör kuvveti: 226 kN
• Ejektör stroku: 300 mmGüç ve Tüketim
• Pompa motor gücü: 180 kW
• Kurulu güç: 265 kW
• Yağ tankı kapasitesi: 1.800 LPerformans
• Kuru döngü: 10 sn
Küçük ilan
Almanya
2.465 km
Krauss Maffei 1600-17200MC
KraussMaffei1600-17200MC
KraussMaffei1600-17200MC
Çağrı
Koşul: işlem için hazır (kullanılmış), Üretim yılı: 2001, çalışma saatleri: 4.517 h, sıkıştırma kuvveti: 16.000 kN, vida çapı: 125 mm, enjeksiyon ağırlığı: 7.450 g, Bu 3 eksenli Krauss Maffei 1600-17200MC hidrolik enjeksiyon kalıplama makinesi 2001 yılında üretilmiştir. Sıkıştırma kuvveti 16.000 kN ve vida çapı 125 mm'dir. Makine 7450 g maksimum atış ağırlığına ve 2600 x 2110 mm plaka boyutuna sahiptir. Yüksek kaliteli enjeksiyon kalıplama yetenekleri elde etmek istiyorsanız, satılık Krauss Maffei 1600-17200MC makinesini düşünün. Daha fazla bilgi için bize ulaşın.
• Enjeksiyon ünitesi: 17200
• Bağlantı çubukları arasındaki mesafe (h × v): 1600 × 1250 mm
• Merdane boyutu (h × v): 2600 × 2110 mm
• Net mesafe (x × y): 1800 × 1400 mm
• Maks. kalıp açma stroku: 2.500 mm
• Kalıp montaj yüksekliği (min-maks): 900-1.600 mm
Pgodpfx Aeyyyr Tenxok
• Açılma genişliği: 3.400 mm
• Kalıp açma kuvveti: 1,108 kN
• Hareketli plaka kuvveti: Açılış 177 kN / Kapanış 153 kN
• Ejektör stroku: 300 mm
• Ejektör kuvveti (ileri/geri): 415 / 177 kN
• Çalışma gerilimi: 400 V / 50 Hz
• Motor akımı: 446 A
• Isıtma akımı: 164 A
• Toplam pompa çalışma saati: 73,761 h
Ek ekipman
• Yedek silindir/vida seti (1x)
• Dahili soğutma sistemi
• Çekirdek çekiciler (2x)
Küçük ilan
Almanya
2.465 km
Krauss Maffei 1300-12000 MC
KraussMaffei1300-12000 MC
KraussMaffei1300-12000 MC
Çağrı
Koşul: işlem için hazır (kullanılmış), Üretim yılı: 2002, çalışma saatleri: 57.752 h, sıkıştırma kuvveti: 13.000 kN, vida çapı: 105 mm, toplam ağırlık: 83.000 kg, Hidrolik enjeksiyon kalıplama makinesi 2002 yılında üretilmiştir. Bu Krauss Maffei 1300-12000 MC, 105 mm vida çapına ve 450°C maksimum işleme sıcaklığına sahiptir. Hidrolik mekanik 2 plaka sıkıştırma sistemi ve 261 A'lık sağlam bir motor akımı içerir. Yüksek kaliteli enjeksiyon kalıplama yetenekleri elde etmek istiyorsanız, satılık Krauss Maffei 1300-12000 MC makinesini düşünün. Daha fazla bilgi için bizimle iletişime geçin.
• Uluslararası boyut tanımı: 12000 MC / 1300
• Çalışma saatleri: 57,752 hElektrik
• Çalışma gerilimi: 400 V, 3 fazlı, 50 Hz (400/230 V Avrupa standardı)
• Motor akımı: 261 A
• Isıtma akımı: 239 A
• Motor toplam akımı: 245 A
• Motor sigortası: 315 A
• Isıtma sigortası: 250 A
• Ana şalter: 6 kutuplu, ısıtma ve güç ayrı
• Soketler: Servis soketi Schuko 10 A; 3x Schuko 16 A; 2x CEE 16 A; 2x CEE 32 A
• Yağ soğutmalı pompa motoru: IP54
• Kabin soğutma fanıKontrol ve HMI
• MC4 32-bit mikroişlemci kontrolü
• TFT renkli ekran
• 3,5 inç disket sürücüsüSıkıştırma ünitesi
• Hidrolik mekanik 2 plakalı bağlama sistemi
• Hareketli plakaya entegre 4 basınç yastığı
• Hidrolik merkezi ejektör
• Hidrolik karot çekme kontrolü
• Operatör tarafında hidrolik güvenlik kapısı
• Minimum kalıp yüksekliği: 700 mm
• Maksimum kalıp yüksekliği: 1400 mm
• Maksimum açılma stroku: 2250 mm
• Maksimum gün ışığı açıklığı: 2950 mmEnjeksiyon ve plastikleştirme
• PV kontrollü enjeksiyon ünitesi
• Termoplastik plastikleştirme ünitesi, aşınmaya dayanıklı tasarım
• Vida çapı: 105 mm
• Çek valf takılı
• Açık nozul tasarımı
• Nozul yarıçapı: 15 mm; nozul delik çapı: 4 mm
• Sabit motorlu hidrolik vida tahriki
• Paralel plastikleştirme mümkün
• Plastikleştirme ünitesi: SP12000
• Maksimum işleme sıcaklığı: 450°C
• Ekran üzerinden ayarlanabilen enjeksiyon kabartma kontrolü
• Enjeksiyon vuruş kontrolü
• Tutma basıncı kontrolü
• Enjeksiyon hız kontrolüHidrolik, yağlama, soğutma
• Rejeneratif pompa kontrol sistemi
• Dahili yağ filtreleme sistemi
• Yağ izleme sistemi
• Su beslemesi için yağ soğutucusu: maks. 31°C
• Soğutma suyu basıncı: 4-6 barSıcaklık kontrolü
• 8 sıcak yolluk için sıcaklık kontrol devresi
• Uyarlanabilir sıcaklık kontrolörleri
• Maksimum sıcaklık kontrol cihazı gücü: 2 kW
• 230 V sıcaklık kontrol cihazı beslemesiİzleme ve yazılım
• Kalite izleme paketi
• Süreç izleme sistemi
• Tolerans bandı izleme
• Çevrim analizi ekranı
• Döngü verilerini 20.000 döngüye kadar saklama
• Olay günlüğü protokolü
• Alarm geçmişi
• Grafiksel süreç eğrileri
• 12 parametre için trend grafikleriArayüzler ve bağlantı
• RS232 arayüzü
• Ethernet arayüzü TCP/IP
• Euromap 12 arayüzü
Pgodpfx Ansyx Ez Roxok
• Euromap 63 / SPI yazılım desteği
• Harici sıcaklık ünitesi arayüzü 20 mA
• Merkezi bilgisayar arayüzü
• 5 kontaklı BDE arayüzü
• Dozajlama ünitesi için potansiyelsiz kontak
Küçük ilan
Almanya
2.465 km
Krauss Maffei 1000-8000 M
KraussMaffei1000-8000 M
KraussMaffei1000-8000 M
Çağrı
Koşul: işlem için hazır (kullanılmış), Üretim yılı: 1997, çalışma saatleri: 111.569 h, sıkıştırma kuvveti: 10.000 kN, Bu 6 eksenli Krauss Maffei 1000-8000 M hidrolik enjeksiyon kalıplama makinesi 1997 yılında üretilmiştir. Maksimum 1000 mm X ekseni hareketine, 1400 mm Y ekseni hareketine ve 3500 mm Z ekseni hareketine sahiptir. Makine 185 barlık bir enjeksiyon basıncı limiti ve yaklaşık 465 mm'lik bir ölçüm stroku içerir. Yüksek kaliteli enjeksiyon kalıplama yetenekleri elde etmek istiyorsanız, satılık Krauss Maffei 1000-8000 M makinemizi düşünün. Daha fazla bilgi için bize ulaşın.
• Enjeksiyon ünitesi
• Vida hızı: 92 rpm
• Enjeksiyon hızı aşamaları:
• 25 → 23 mm/s
• 50 → 46 mm/s
• 75 → 69 mm/s
• 100 → 92 mm/s
• Enjeksiyon ölçüm stroku: 200 mm ileri hareket aslında atışı enjekte etmek için kullanılır
• Ölçüm stroku: plastikleştirme sırasında yaklaşık 465 mm maksimum vida hareketi
• Enjeksiyon basınç limiti: 185 bar
• Hidrolik sistem
Pgsdjywlvropfx Anxek
• Pompa diferansiyel basıncı: 10 bar
• Basınç devreleri:
• Ana basınç: 250 bar
• Enjeksiyon basıncı: 185 bar
• Hidrolik devre: 150 bar
• İkincil basınç: 120 bar
• Yardımcı basınç: 50 bar
• Kapanma basıncı düşüşü: yaklaşık 4-6 bar/dak
• Oransal valf basınç aralıkları:
• Minimum: 50 bar
• Maksimum: 150 bar
• İş mili hızı: 92 rpm
• Isıtma sistemi
• Isıtma bölgesi sayısı: 9
• Silindir ısıtıcı güç örnekleri: 9100 W, 8200 W, 6200 W, 5200 W, 2400 W, 650 W, 300 W
• Kaydedilen çalışma gerilimleri: 230 V, 220 V, 380 V
• Sıcaklık doğruluğu sapması: yakl. -1 K ila +2 K
• Durum / bakımla ilgili veriler
• Makine hizalama toleransı:
Küçük ilan
Langenfeld (Rheinland)
2.579 km
Enjeksiyon kalıplama makinesi
BATTENFELDHM 10000-9200
BATTENFELDHM 10000-9200
Çağrı
Koşul: ikinci el, Üretim yılı: 2003, çalışma saatleri: 67.092 h, Fonksiyonellik: tamamen fonksiyonel, sıkıştırma kuvveti: 10.000 kN, vida çapı: 120 mm, silindir hacmi: 5.655 cm³, enjeksiyon basıncı: 1.632 bar, toplam uzunluk: 11.600 mm, toplam genişlik: 2.900 mm, toplam yükseklik: 2.500 mm, toplam ağırlık: 76.500 kg, Kapatma kuvveti: 10000 kN
Kolon ölçüsü y x e: 1120 x 1400 mm
Plaka boyutu y x e: 1960 x 1690 mm
Min. kalıp montaj yüksekliği: 550 mm
Maks. kalıp montaj yüksekliği: 1020 mm
Pgsdpfoywg N Tjx Anxjk
Maks. plaka arası mesafe: 2120 mm
Açılma mesafesi: 1100 mm
Vida çapı: 120 mm
Enjeksiyon hacmi: 5655 ccm
Enjeksiyon basıncı: 1632 bar
Donanım:
Ekran metni Almanca
Compact-Flash sürücü
4x hidrolik çekirdek çekici
Seviyeleme elemanları
EUROMAP 12 arayüzü
Sıcaklık kontrol cihazı için arayüz
Büyütülmüş yağ soğutucu
16x kalıp ısıtıcı
Makine ölçüleri UxGxY: 11,6 m x 2,9 m x 2,5 m
Toplam ağırlık: 76500 KG
Küçük ilan
Wrocław
1.962 km
Enjeksiyon kalıplama makinesi
KraussMaffeiKM 1100-12000 MX
KraussMaffeiKM 1100-12000 MX
Çağrı
Koşul: mükemmel (kullanılmış), Üretim yılı: 2008, Injection Moulding Machine KRAUSS MAFFEI KM 1100-12000 MX
Basic Information
Manufacturer: Krauss Maffei
Model: KM 1100-12000 MX
Year of manufacture: 2008
Control system: MC5
Control panel: colour monitor integrated with control desk
Interfaces: 3 USB ports
The machine is equipped with a fully hydraulic clamping system and a complete plasticizing unit for thermoplastics processing with abrasion protection.
Clamping Unit
Clamping force: 11,000 kN
Mould opening force: 770 kN
Platen dimensions (H × V): 2210 × 1910 mm
Tie bar clearance (H × V): 1550 × 1250 mm
Mould opening stroke: 2,000 mm
Minimum mould height: 600 mm
Maximum mould height: 1,200 mm
Platen movement stroke: 2,600 mm
Ejector stroke: 300 mm
Ejector force: 220 / 110 kN
Injection Unit
Screw diameter: 120 mm
Maximum injection pressure: 1,758 bar
Injection volume: 6,786 cm³
Shot weight (PS): 6,175 g
Screw speed (standard/option): 103 / 145 rpm
Injection rate (standard): 1,118 cm³/s
Injection rate (accumulator): 1,696 cm³/s
Electrical and Hydraulic Equipment
Pump motor rated power: 132 kW
Installed heater power: 82 kW
Number of cylinder heating zones: 7
Number of dry cycles (EUROMAP): 802 cycles/h
Hydraulic oil tank capacity: 2,440 l
Machine Dimensions and Weight
Net weight (with control cabinet): 73 t
Machine dimensions (L × W × H):
12.47 × 3.65 × 2.82 m
Optional Energy Saving System ESS (Energy Saving Systems)
The machine can be fitted with a modern ESS servo drive system, which significantly increases the energy efficiency of hydraulic injection moulding machines.
The system controls the operation of the hydraulic pump motor by means of a frequency inverter, adjusting the motor speed to the actual demand during the production cycle.
Primary Benefits
- Reduction of electricity consumption by up to 30%
- Servo drive technology for hydraulic pumps
- Global quality and proven technology used in plastics processing industry
- Reduced energy loss during idle operation
- Less heating of the hydraulic system
- Extended service life of motor and hydraulic components
Pgjdpfx Asyugfzsnxjk
- Can be retrofitted on existing hydraulic injection moulding machines
The ESS system allows for significant reduction of machine operating costs while maintaining full production parameters.
Küçük ilan
Wrocław
1.962 km
Enjeksiyon kalıplama makinesi
DEMAGSystem 1500/1500-16000
DEMAGSystem 1500/1500-16000
Çağrı
Koşul: mükemmel (kullanılmış), Üretim yılı: 2008, Injection Moulding Machine DEMAG System 1500/1500-16000
Pgsdpfx Ajyugalonxok
Basic Data
Manufacturer: DEMAG
Model: System 1500/1500-16000
Year of manufacture: 2008
Clamping Unit
Clamping force: 15,000 kN
Platen dimensions (horizontal × vertical): 2,150 × 1,880 mm
Clearance between tie bars (horizontal × vertical): 1,500 × 1,250 mm
Minimum mould height: 700 mm
Maximum mould height: 1,400 mm
Maximum opening stroke: 2,900 mm
Injection Unit
Screw diameter: 145 mm
Injection volume: 10,981 cm³
Shot weight (PS): 9,880 g
Maximum injection pressure: 1,454 bar
Electrical and Hydraulic Equipment
Rated motor power (pump): 165 kW
Heater power: 97 kW
Machine Dimensions and Weight
Net weight of machine: 74 t
Weight of control cabinet: 21 t
Total weight: approx. 95 t
Dimensions (L × W × H): 14.4 × 3.4 × 2.9 m
Service History / Repairs
2010 – new screw with RSP and barrel
2015 – new IBED
2015 – new wiring board
2017 – new motor and pump no. 2
2017 – new injection cylinder piston rod BS with seals
2017 – replacement of oil cooler circulation pump
2017 – replacement of TeachBox (robot)
2018 – replacement of pumps P1 + P3 (at 65,800 h)
2018 – replacement of hydraulic oil
Optional ESS (Energy Saving Systems)
The machine can be equipped with a modern ESS servo drive system, which significantly improves the energy efficiency of hydraulic injection moulding machines.
The system controls the operation of the hydraulic pump motor by using a frequency inverter, which adjusts the motor speed to the actual demand of the machine during the production cycle. This means electrical power is consumed only when strictly required.
Key Benefits:
- Reduction of power consumption by up to 30%
- Servo drive technology for the hydraulic pump
- Worldwide quality and proven technology used in the plastics processing industry
- Reduction of energy losses during idling operation
- Lower heating of the hydraulic system
- Extended service life for motor and hydraulic components
- Suitable for retrofitting into existing hydraulic injection moulding machines
The ESS system allows for a substantial reduction in machine operating costs while maintaining full production parameters.
Küçük ilan
Wrocław
1.962 km
Enjeksiyon kalıplama makinesi
EngelDUO 11050/2300
EngelDUO 11050/2300
Çağrı
Koşul: mükemmel (kullanılmış), Üretim yılı: 2004, ENGEL DUO 11050/2300 Injection Moulding Machine
Podeyuf Tdjpfx Anxjgk
Basic Information
Manufacturer: ENGEL
Model: DUO 11050/2300
Year of manufacture: 2004
Operating hours: 70,029 hours
Clamping Unit
Clamping force: 2,300 kN
Platen dimensions (horizontal × vertical): 2,900 × 2,500 mm
Tie bar spacing (horizontal × vertical): 2,000 × 1,600 mm
Minimum mould height: 700 mm
Maximum mould height: 1,890 mm
Maximum opening stroke: 3,800 mm
Injection Unit
Screw diameter: 135 mm
Shot volume: 8,870 cm³
Shot weight (PS): 8,071 g
Maximum injection pressure: 1,600 bar
Machine Dimensions and Weight
Net machine weight: 113 t
Control cabinet weight: 18 t
Total weight: approx. 131 t
Optional ESS Energy Saving System
The machine can be equipped with a state-of-the-art ESS Servo Drive System, which enhances the energy efficiency of hydraulic injection moulding machines.
The system manages the operation of the hydraulic pump motor via a frequency inverter, adjusting the motor speed according to the real-time requirements of the production cycle. As a result, electrical power is only consumed when actually needed.
Benefits of the ESS System:
- Reduces energy consumption by up to 30%
- Hydraulic pump servo drive technology
- World-class, proven technology used in the plastics processing industry
- Reduction of energy losses during machine idle periods
- Less heat generation in the hydraulic system
- Prolongs the service life of the motor and hydraulic components
- Can be retrofitted to existing hydraulic injection moulding machines
The ESS system significantly lowers machine operating costs while maintaining full production performance.
Küçük ilan
Hambach
2.502 km
Enjeksiyon kalıplama makinesi
KraussMaffeiKM 3200-19000 MC
KraussMaffeiKM 3200-19000 MC
Çağrı
Koşul: ikinci el, Üretim yılı: 1998, çalışma saatleri: 99.161 h, sıkıştırma kuvveti: 32.000 kN, vida çapı: 130 mm, enjeksiyon ağırlığı: 8.100 g, toplam uzunluk: 4.900 mm, toplam yükseklik: 4.200 mm, toplam ağırlık: 230.000 kg, A high-performance injection molding machine from German manufacturer KraussMaffei is offered for sale.
This is the KM 3200-19000 MC model, specifically designed for the production of large-volume plastic components and industrial-scale manufacturing. The machine provides exceptionally high clamping force and is ideally suited for applications involving technical plastic parts or oversized components.
It features a clamping force of 32,000 kN, a screw diameter of 130 mm, and a maximum shot weight of 8,100 g, enabling the efficient production of large parts with significant material requirements.
Additionally, the system is equipped with extensive peripheral equipment, including a robot interface for KUKA KRC4, a S.I.S.E. IS’Tech sequential injection controller, GWK temperature control units, and a Motan Colormetric dosing and mixing system. A belt conveyor is also included.
Technical Data
* Manufacturer: KraussMaffei
* Model: KM 3200-19000 MC
* Machine No.: IMM MC3F No.12
* Year of manufacture: 1998
Pgodpfx Asyt H Dhsnxjk
* Operating hours: approx. 99,161 h
Performance Data
* Clamping force: 32,000 kN
* Screw diameter: 130 mm
* Maximum shot weight: 8,100 g
Dimensions & Weight
* Machine weight: approx. 230,000 kg
* Machine depth: approx. 4,900 mm
* Machine height: approx. 4,200 mm
This machine offers a robust and established solution for industrial plastic processing and is particularly appealing to manufacturers requiring large-format injection molding capabilities.
Additional information, photos, or inspection appointments are available upon request.
Küçük ilan
Hambach
2.502 km
Enjeksiyon kalıplama makinesi
KraussMaffeiKM 4000-19000 MC
KraussMaffeiKM 4000-19000 MC
Çağrı
Koşul: ikinci el, Üretim yılı: 1998, çalışma saatleri: 98.806 h, sıkıştırma kuvveti: 40.000 kN, vida çapı: 130 mm, enjeksiyon ağırlığı: 8.100 g, toplam uzunluk: 4.900 mm, toplam yükseklik: 4.200 mm, toplam ağırlık: 255.000 kg, 2x KraussMaffei KM 4000-19000 MC – Injection Moulding Machines – Year of Manufacture 1998
Pgjdpfxsyt Hy Ns Anxek
For sale are two identical injection moulding machines by KraussMaffei, model KM 4000-19000 MC, featuring the MC3F control unit. These machines are especially suited for the production of large plastic components that require exceptionally high clamping force.
The systems are fully equipped and include multiple peripheral devices for material feeding and process management.
## Technical Data
* Manufacturer: KraussMaffei
* Model: KM 4000-19000 MC
* Control system: MC3F
* Year of manufacture: 1998
* Machine hours: approx. 98,806 h
* Clamping force: 40,000 kN
* Max. shot weight: 8,100 g
* Screw diameter: 130 mm
## Dimensions & Weight
* Machine depth: 4,900 mm
* Machine height: 4,200 mm
* Machine weight: approx. 255,000 kg
## Equipment
* Robot interface: KUKA KRC4
* Sequential injection controller: S.I.S.E. IS-Tech
* Temperature control units: GWK
* Dosing and mixing system: Motan Colormetric
* Belt conveyor
## Machines
* Machine No. 14
* Machine No. 15
The machines can be purchased individually or as a package.
Viewing by appointment.
Küçük ilan
Hambach
2.502 km
Enjeksiyon kalıplama makinesi
KraussMaffeiKM2300 14700MC
KraussMaffeiKM2300 14700MC
Çağrı
Koşul: ikinci el, Üretim yılı: 1998, çalışma saatleri: 101.215 h, makine/araç numarası: 23J01415, sıkıştırma kuvveti: 23.000 kN, enjeksiyon ağırlığı: 6.100 g, toplam uzunluk: 4.500 mm, toplam yükseklik: 3.800 mm, toplam ağırlık: 205.000 kg, Two powerful injection molding machines from the renowned manufacturer KraussMaffei are available for sale. These are KM 2300-14700 MC models, engineered for the production of large-volume plastic parts and series industrial manufacturing.
Each unit provides a clamping force of 23,000 kN and features a screw diameter of 105 mm as well as a maximum shot weight of 6,100 g, making them particularly suitable for applications requiring large components and high material throughput.
Both machines come equipped with extensive peripheral technology, including a robot interface for KUKA KRC4, a S.I.S.E. IS’Tech sequential injection controller, GWK temperature control units, and a Motan Colormetric dosing and blending system. A belt conveyor is part of the scope of delivery.
Manufactured in 1997 and 1998, both machines have been operated in an industrial production environment.
Technical data:
Machine 1
* Model: KraussMaffei KM 2300-14700 MC (IMM MC3F No. 6)
* Year of manufacture: 1998
* Operating hours: approx. 101,215 h
Machine 2
* Model: KraussMaffei KM 2300-14700 MC (IMM MC3F No. 9)
* Year of manufacture: 1997
* Operating hours: approx. 99,030 h
Shared technical specifications:
* Clamping force: 23,000 kN
* Screw diameter: 105 mm
* Maximum shot weight: 6,100 g
Pjdpfx Anjyt Hidexjgk
* Machine weight: approx. 205,000 kg
* Machine dimensions:
* Depth: approx. 4,500 mm
* Height: approx. 3,800 mm
These machines provide a solid and proven solution for industrial plastics processing and are especially attractive for companies requiring large-scale injection molding capacity.
Küçük ilan
Wrocław
1.962 km
Enjeksiyon kalıplama makinesi
KraussMaffeiKM 1300-12000 MX
KraussMaffeiKM 1300-12000 MX
Çağrı
Koşul: mükemmel (kullanılmış), Üretim yılı: 2012, Krauss Maffei KM 1300-12000 MX Injection Moulding Machine
Manufacturer: KraussMaffei
Model: KM 1300-12000 MX
Year of manufacture: 2012
Machine designed for processing thermoplastics, equipped with a complete plasticizing unit with abrasion-resistant protection version.
Technical data
Clamping unit
- Clamping force: 13,000 kN
- Mould opening force: 910 kN
- Dimensions of mounting platens: 2210 × 1910 mm
- Tie bar spacing: 1570 × 1270 mm
- Ejector stroke: 350 mm
- Ejector force: 250 / 125 kN
Injection unit
- Screw diameter: 105 mm
- Injection pressure: 2,296 bar
- Injection volume: 5,195 cm³
- Shot weight for PS: 4,728 g
- Injection rate: 856 cm³/s
Plasticizing parameters
- Screw speed: 103 / 145 rpm
- Plasticizing capacity (PS):
- standard speed: 122 g/s
- increased speed (option): 171 g/s
Electro-hydraulic equipment
- Rated pump motor power: 132 kW
- Installed heater power: 71 kW
- Number of barrel heating zones: 7
Pgedpfx Anjyrrwkoxok
- Dry cycle time according to Euromap 6: 765 cycles/h
- Hydraulic oil tank capacity: 2,440 l
Dimensions and weight
- Net weight with control cabinet: 70 tons
- Installation dimensions:
13.03 × 3.65 × 2.82 m
Küçük ilan
Yalova
543 km
Enjeksiyon kalıplama makinesi
REAL PRESSRP 4000 T
REAL PRESSRP 4000 T
Çağrı
Koşul: ikinci el, Üretim yılı: 2011, çalışma saatleri: 13.000 h, Fonksiyonellik: tamamen fonksiyonel, sıkıştırma kuvveti: 39.240 kN, vida çapı: 245 mm, kolonlar arası açıklık: 2.250 mm, enjeksiyon basıncı: 1.200 bar, enjeksiyon ağırlığı: 47.685 g, toplam ağırlık: 320.000 kg, ısıtma kapasitesi: 354 kW (481,31 bg), ÜRETİCİ: REAL PRESS
Model / Tip: RP 4000 T
Üretim Yılı: 2011
Menşei: İtalya
Kalıp Sıkıştırma Kuvveti (kN): 39.240
Kolonlar Arası Mesafe (mm): 2.250 x 2.250
Vida Çapı (mm): 245
Enjeksiyon Basıncı (bar): 1.200
Maks. Atış Ağırlığı PS (gr): 47.685
Isıtma Kapasitesi (kW): 354
Pompa Motor Gücü (kW): 132+132+132+30
Toplam Güç (kW): 790
Maks. Kalıp Kalınlığı (mm): 2.200
Podpfx Aoylwz Ijnxsgk
Min. Kalıp Kalınlığı (mm): 1.000
Makine Ölçüleri (UxGxY - m): 22 x 45 x 50
Makine Ağırlığı (ton): 320
Vida Stroğu (mm): 245
Maks. Erimiş Plastik Atış Miktarı (gr): 34.333,2
1 mm başına Maks. Atış Ağırlığı PE (gr): 140,1355102
Sabit Flanş Ölçüsü: ᴓ250
Hareketli Taraf Flanş Ölçüsü: ᴓ250
Robot: VAR
Küçük ilan
Taşköprü Bld. (Taşköprü Mh.)
533 km
Enjeksiyon kalıplama makinesi
RemuRM4000
RemuRM4000
Çağrı
Koşul: ikinci el, Üretim yılı: 1992, çalışma saatleri: 17.000 h, Fonksiyonellik: tamamen fonksiyonel, sıkıştırma kuvveti: 40.000 kN, vida çapı: 240 mm, kolonlar arası açıklık: 2.100 mm, enjeksiyon basıncı: 1.500 bar, enjeksiyon ağırlığı: 48.000 g, ejektör stroku: 700 mm, toplam uzunluk: 26.000 mm, toplam genişlik: 5.000 mm, toplam yükseklik: 7.000 mm, toplam ağırlık: 380.000 kg, MANUFACTURER: REMU
Model / Type: RM 4000
Injection Unit
Production Year: 1992
Made In: Italy
Mould Clamping Force (kN): 40,000
Space Between Tie Bars (mm): 2,100 x 2,100
Pump Motor Power (kW):
Screw Diameter (mm): 240
Injection Pressure (bar): 1,500
Max. Shot Weight PS (gr): 48,000
Heating Capacity (kW): 235
Pgjdpfxsylva No Anxek
Pump Motor Power (kW): 595
Total Installed Power (kW): 830
Clamping Unit
Max. Mould Thickness (mm): 2,000
Min. Mould Thickness (mm): 800
Ejector Stroke (mm): 700
Max. Daylight (mm): 4,500
Oil Tank Capacity (liters): 9,000
Machine Dimensions (L x W x H, m): 26 x 5 x 7
Machine Weight (tons): 380
Screw Stroke (mm): 1,400
Max. Shot Molten Plastic Weight (gr): 34,560
Max. Shot Weight per 1 mm PE (gr): 24.69
Actual Value (gr/h): 26.8
Max. Injection Weight PE (gr): 35,136
Max. Injection Weight PP (gr): 35,136
Machine Nozzle Radius: R34
Fixed Side Flange Size: ᴓ300
Moving Side Flange Size: ᴓ250
Air Connections (fixed - moving): 2 + 4
Hydraulic Cores: 4 + 4
Mold Frigel Water Connections: 2''
Mold Hot Runner Control (pcs): 40
Valve Gate System (pcs): 16 (Active)
Magnetic Plate: Yes
Mold Carrying Capacity (fixed - moving, tons): 21.8 / 18.7
Robot: Yes
Küçük ilan
Wrocław
1.962 km
Enjeksiyon kalıplama makinesi
Krauss MaffeiKM 4000-24500 MC
Krauss MaffeiKM 4000-24500 MC
Çağrı
Koşul: mükemmel (kullanılmış), Üretim yılı: 2003, KRAUSS MAFFEI KM 4000-24500 MC Injection Moulding Machine
_____
Basic Data
• Year of manufacture: 2003
• Control system: MC4
• Software languages: Swedish, German, English
_____
Clamping Unit
• Clamping force: 40,000 kN
Pedjyifg Dspfx Anxjgk
• Mold opening force: 2,525 kN
• Platen dimensions (horizontal × vertical): 3,315 × 2,920 mm
• Tie bar clearance (horizontal × vertical): 2,240 × 1,800 mm
• Mold opening stroke: 3,100 mm
• Min. / Max. mold height: 1,100 – 2,000 mm
• Max. daylight opening: 4,200 mm
• Ejector stroke: 350 mm
• Ejector force (forward / backward): 772 / 368 kN
_____
Injection Unit (HPS-AT)
• Screw diameter: 150 mm
• L/D ratio: 23
• Max. injection pressure: 1,843 bar
• Injection volume: 13,254 cm³
• Shot weight (PS): 12,061 g
• Injection rate: 1,431 cm³/s
• Plasticizing rate: 266 g/s
_____
Electrical-Hydraulic System
• Hydraulic pump motor power: 200 kW
• Installed heater power: 159 kW
• Number of heating zones (barrel): 7
• Dry cycle time (Euromap 6): 270 cycles/h
• Hydraulic oil tank capacity: 2,700 l
_____
Machine Dimensions and Weight
• Machine dimensions (L × W × H): 17.3 × 4.9 × 3.74 m
• Machine weight: 247 t
• Max. mold weight: 90,000 kg
Küçük ilan
Halver
2.547 km
Enjeksiyon kalıplama makinesi
KraussMaffeiKM 1300-12000 MX inkl. KUKA Roboter
KraussMaffeiKM 1300-12000 MX inkl. KUKA Roboter
Çağrı
Koşul: mükemmel (kullanılmış), Üretim yılı: 2007, çalışma saatleri: 81.000 h, Technical specifications
Year of manufacture: 2007
Pgjdpfx Asyifgkjnxek
Clamping Unit
Clamping force: 1300 t
Max. opening stroke/installation height: 2300 mm
Max. distance between platens: 4000 mm
Min./max. mold installation height: 1000 - 1700 mm
Max. platen height: 1910 mm
Min. mold size: 1000 - 1700 mm
Clear tie bar distance: 1500 mm
Nozzle radius: R40 mm
Mold weight: 29000 kg
Ejector stroke: 350 mm
Injection Unit
Screw diameter: 135 mm
Shot volume: 8588 ccm
Core pulls AWS/DS: 1/1
Needle shut-off valve, pneumatic: 1
Machine is delivered with Kuka robot and can be viewed in production.
Küçük ilan
Trenčianske Stankovce
1.760 km
Krauss Maffei KM 1600 - 17200 MX (2013)
KraussMaffeiKM 1600 – 17200 MX
KraussMaffeiKM 1600 – 17200 MX
Çağrı
Koşul: iyi (kullanılmış), Üretim yılı: 2013, sıkıştırma kuvveti: 16.000 kN, Donanım: dokümantasyon / kılavuz, Kilit kuvveti: 1600 t
Vida çapı: 135 mm
Kolonlar arası mesafe V: 1420 mm
Kolonlar arası mesafe H: 1870 mm
Enjeksiyon hacmi: 9662 cm3
Tip: Yatay
Tahrik: Hidrolik
Pgodpfxsyh I Emj Anxok
Küçük ilan
Trenčianske Stankovce
1.760 km
İngilizce11050/1300 (2017)
EngelDUO11050/1300
EngelDUO11050/1300
Çağrı
Koşul: mükemmel (kullanılmış), Üretim yılı: 2017, İngilizce11050/1300 (2017)
Pjdoyaat Aspfx Anxjgk
Küçük ilan
Halver
2.547 km
Enjeksiyon kalıplama makinesi
ENGELDuo 11000H/7000H/1300
ENGELDuo 11000H/7000H/1300
Çağrı
Koşul: mükemmel (kullanılmış), Üretim yılı: 2007, Engel Duo 11000H/7000H/1300
Year of manufacture: 2007
Technical data
Clamping unit
Clamping force: 13,000 kN
Opening stroke: 3,000 mm
Min. mould installation height: 1,000 mm
Max. mould installation height: 1,800 mm
Max. platen distance: 4,000 mm
Mounting platens: 2,200 x 1,990 mm
Clear tie bar spacing: 1,530 x 1,275 mm
Injection unit 1
Screw diameter: 120 mm
Shot size (stroke): 570 mm
Max. shot volume: 6,450 cm³
L/D screw ratio: 20
Specific injection pressure: 1,794 bar
Nozzle stroke: 1,000 mm
Number of heating zones: 6
Injection unit 2
Screw diameter: 120 mm
Shot size (stroke): 4,800 mm
Max. shot volume: 5,430 cm³
Pgsdpfx Anex Up Rnjxsk
Specific injection pressure: 1,370 bar
Nozzle stroke: 1,000 mm
Küçük ilan
Halver
2.547 km
Enjeksiyon kalıplama makinesi
BATTENFELDHM 10000-9200
BATTENFELDHM 10000-9200
Çağrı
Koşul: mükemmel (kullanılmış), Üretim yılı: 2003, çalışma saatleri: 67.092 h, BATTENFELD HM 10000-9200
Manufacturer: BATTENFELD
Model: HM 10000-9200
Control system: UNILOG B4
Year of manufacture: 2003
Operating hours: 67,092 h
Technical Data – Clamping Unit
Clamping force: 10,000 kN
Tie bar spacing (H x V): 1120 x 1400 mm
Platen size (H x V): 1960 x 1690 mm
Min. mold height: 550 mm
Max. mold height: 1020 mm
Max. daylight between platens: 2,120 mm
Opening stroke: 1,100 mm
Ejector stroke: 300 mm
Ejector force: 118 kN
Centering ring (moving platen): 250 mm
Centering ring (fixed platen): 315 mm
Technical Data – Injection Unit
Screw diameter: 120 mm
Shot volume: 5,655 cm³
Injection pressure: 1,632 bar
Screw length: 22 L/D
Screw stroke: 500 mm
Screw speed: 130 rpm
Screw torque: 11,370 Nm
Pgodpfx Aex Up Rhjnxok
Plasticizing rate (PS): 144 g/s
Free flow injection rate (PS): 1,144 g/s
Number of heating zones: 8
Nozzle stroke: 700 mm
Dimensions & Weight
Machine dimensions (L x W x H): 11.6 m x 2.9 m x 2.5 m
Total weight: 76,500 kg
Equipment
Operator interface in German
Compact Flash drive
4x hydraulic core pulls
Leveling elements
EUROMAP 12 interface
Interface for temperature control unit
Enlarged oil cooler
16x mold heating zones
Küçük ilan
Wrocław
1.962 km
Enjeksiyon kalıplama makinesi
KraussMaffeiKM 1100–12000 MX
KraussMaffeiKM 1100–12000 MX
Çağrı
Koşul: mükemmel (kullanılmış), Üretim yılı: 2008, Krauss Maffei Injection Moulding Machine KM 1100–12000 MX
Year of manufacture: 2008
Robot: Wittmann
Fully hydraulic clamping system.
MC5 control system with color monitor, integrated control panel, and three built-in USB ports.
Plasticizing unit:
Complete plasticizing unit for thermoplastics with abrasion-resistant design,
screw diameter: 120 mm, with non-return valve and open nozzle.
Technical specifications
Clamping unit
Clamping force: 11,000 kN
Mold opening force: 770 kN
Platen dimensions (H × V): 2,210 × 1,910 mm
Tie bar clearance (H × V): 1,550 × 1,250 mm
Mold opening stroke: 2,000 mm
Mold height (min–max): 600 – 1,200 mm
Platen traverse stroke: 2,600 mm
Ejector stroke: 300 mm
Ejector force: 220 / 110 kN
Injection unit
Screw diameter: 120 mm
Injection pressure: 1,758 bar
Shot volume: 6,786 cm³
Pgsdpfxox Tgbhs Anxek
Shot weight (PS): 6,175 g
Screw speed (standard / option): 103 / 145 rpm
Injection rate (standard): 1,118 cm³/s
Injection rate (accumulator): 1,696 cm³/s
Electro-hydraulic equipment
Pump motor rated power: 132 kW
Installed heating power: 82 kW
Number of barrel heating zones: 7
Number of dry cycles (Euromap): 802 1/h
Oil tank capacity: 2,440 l
Dimensions & weight
Net weight with control cabinet: 73 t
Machine dimensions (L × W × H): 12.47 × 3.65 × 2.82 m
Küçük ilan
Wrocław
1.962 km
Enjeksiyon kalıplama makinesi
EngelDUO 11050/2300
EngelDUO 11050/2300
Çağrı
Koşul: mükemmel (kullanılmış), Üretim yılı: 2004, ENGEL DUO 11050/2300 Injection Molding Machine
Year of manufacture: 2004
Operating hours: 70,029 hours
Screw: replaced in 2011 (reinforced – for special materials)
Clamping unit
Clamping force: 2,300 kN
Platen size (H × V): 2,900 × 2,500 mm
Tie bar spacing (H × V): 2,000 × 1,600 mm
Min./max. mold height: 700 – 1,890 mm
Maximum opening stroke: 3,800 mm
Injection unit
Screw diameter: 135 mm
Injection volume: 8,870 cm³
Shot weight (PS): 8,071 g
Injection pressure: 1,600 bar
Additional equipment
Possibility of two-stage injection
Mold tilting option
Magnetic platens
2 hydraulic cores
36 heating zones for the mold
10 hydraulic cascades (expandable)
Interface languages: English, German
Dimensions and weight
Pedpfx Ansx Tf Iasxegk
Net weight (incl. control cabinet): 113 t + 18 t
(Total weight approx. 131,000 kg)
Küçük ilan
Almanya
2.465 km
Husky E 3150 RS 170 155
HuskyE 3150 RS 170 155
HuskyE 3150 RS 170 155
Çağrı
Koşul: işlem için hazır (kullanılmış), Üretim yılı: 1997, sıkıştırma kuvveti: 31.500 kN, vida çapı: 155 mm, enjeksiyon ağırlığı: 9.642 g, toplam yükseklik: 4.090 mm, toplam ağırlık: 190.000 kg, ürün uzunluğu (maks.): 14.760 mm, Bu Husky E 3150 RS 170 155 1997 yılında üretilmiştir. Sıkıştırma kuvveti 31.500 kN, vida çapı 155 mm ve atış ağırlığı 9.642 g'dır. Büyük ölçekli üretim için ideal olan bu makinenin strok hacmi 13.205 cm³ ve enjeksiyon basıncı 1.636 bar'dır. Bu makine hakkında daha fazla bilgi için lütfen bize ulaşın.
• Montaj plakası (Y x V): 3,230 x 2,780
• Net açıklık (Y x V): 2,250 x 1,800
• Açılma stroku: 2,100 dak.
• Açılma genişliği: 4.100 mm
• Strok hacmi: 13,205 cm³
• Enjeksiyon basıncı: 1,636 bar
Podpfxox Sz Ero Anxogk
• Vida L/D: 23
• Nozul yarıçapı: 25 mm
• Daldırma derinliği: 50 mm
• Sabit tarafta üç çekirdek kasnağı
• hareketli tarafta dört çekirdek kasnak
• on iki pnömatik kademeli.
