Sebastian Justus Bewertung - Verwertung - Handel

Durumu: kullanılmış, Single-column hydraulic press EXNER Type EEX 20 S No. 1615 Year of manufacture 1980 Pressing force: 20 tons Throat depth: 180 mm Table size: 380 x 350 mm Table opening: Ø 50 mm Ram surface: 310 x 250 mm Clamping pin: Ø 35 mm Ram stroke: 100 mm Max. installation height: 250 mm Table height above floor: 900 mm Downward speed: approx. 480 mm/s Upward speed: approx. 480 mm/s Working speed: 20 mm/s Hydraulic tank capacity: 110 liters Hydraulic operating pressure at 20 tons: 200 bar Motor power: 4 kW Power connection: 400 Volt, 50 Hz - Stroke release via two-hand operation or light barrier - Operating modes: setup, two-hand operation, BWS - SICK light curtain, Type LVU with single-stroke and two-stroke modes and safety function - Rapid approach and working stroke - Stroke limitation depending on pressure or distance - Mechanical adjustable fixed stop - Manual press force adjustment via knurled wheel - Control cabinet mounted laterally on the machine - Operating manual and electrical wiring diagram available - Stroke counter Required space (L x W x H): 1250 x 750 x 2000 mm Weight: 1.4 tons Gbsdsyz Dtdopfx Adrjk Good condition

Durumu: yeni, Üretim yılı: 2025, Fonksiyonellik: tamamen fonksiyonel, presleme kuvveti: 125 t, Single-column press – Manufacturer: Durendus – 125 t servo press – Table 2200 × 750 mm For sale is a hydraulic C-frame servo press from Durendus with an adjustable pressing force of up to 125 t and an integrated 50 t ejector. Thanks to modern servo hydraulics, the machine offers energy savings of up to 40% compared to conventional systems, making it ideal for demanding assembly, forming, and production processes. ===== Technical Data & Information: Hydraulic Servo Press – C-frame – 125 t ==== General Information - Manufacturer: Durendus - Model: Single-column press / Servo press - Design: C-frame press - Pressing force: 20 – 125 t (adjustable) - Machine weight: approx. 8,700 kg Gedpsx Aqtqjfx Adrobk - Dimensions (W × D × H): approx. 2,400 × 2,000 × 3,300 mm - Table height: 870 mm - Installation height: max. 1,000 mm ==== Table & Ram - Table surface: 2,200 × 750 mm - Ram surface: 980 × 750 mm - Guidance: 4 guide columns, Ø 100 mm - Tool centering: 50 mm receptacle - Prepared for: vibration isolator pads (30 mm) - Prepared for: robot interface ==== Ejector - Ejector force: 50 t - Ejector stroke: 200 mm ==== Hydraulic Cylinder - Stroke: 0 – 700 mm (adjustable) - Operating pressure: max. 245 bar - Return speed: 300 mm/s - Idle speed: 300 mm/s - Pressing speed: - up to 25% load: 25 mm/s - up to 50% load: 14 mm/s - up to 80% load: 7 mm/s - up to 100% load: 6 mm/s ==== Hydraulic Unit - Servo hydraulic pump: Duplomatic, 143 l/min - Servo motor power: 15 kW - Pressure accuracy: ± 5 bar - Pre-fill valve: NG-160 ===== Assembly operations, forming technology, series production, automated production, tool and die making, press operations with energy optimization. Servo press, single-column press, C-frame press, hydraulic press, industrial press, production press, energy-efficient press, tool adjustment press, tryout press, tool tryout press Are you looking for a hydraulic press tailored to your application? Contact us for an individual offer. Our hydraulic presses are manufactured according to German and European machinery directives (Directive 2006/42/EC), EC standards, and EU safety requirements. Furthermore, our presses exceed Canadian and European safety requirements, as they fully comply with the Brazilian national safety regulation NR 12, which builds on these standards. Our core strength lies in custom machine building and press automation. We supply tailored hydraulic presses at surprisingly competitive prices. The hydraulics in our presses predominantly use components from leading European manufacturers.

Durumu: yeni, Üretim yılı: 2025, Fonksiyonellik: tamamen fonksiyonel, presleme kuvveti: 20 t, C-frame Press – Manufacturer: Durendus – 3–20 t Hydraulic Press – Table 1000 × 400 mm Gbjdpfxox Ap Uts Adrsk For sale is a hydraulic single-column (C-frame) press from Durendus, featuring an adjustable pressing force from 3 to 20 t. This compact and robust machine is ideal for assembly, pressing, and light forming operations in workshops and production environments. ==== Technical Data + Information: Hydraulic C-frame Press – 3–20 t ==== General Information - Manufacturer: Durendus - Model: Assembly Press / Single-column Press - Design: C-frame Press - Press Force: 3 – 20 t (adjustable) - Machine Weight: approx. 1,200 kg - Paint finish: RAL 7035 (Light Grey) / RAL 2009 (Orange) ==== Working Area - Max. Distance Table – Ram: 500 mm - Stroke / Travel: 500 mm - Table Height: 940 mm ==== Table & Ram - Table Plate: 1,000 × 400 × 40 mm - Ram: Ø 250 mm, round, interchangeable ==== Speeds - Downward Speed: 2 – 10 mm/s (adjustable) - Upward Speed: 20 mm/s ==== Hydraulics - Motor Power: 2.2 kW - Oil Tank Capacity: 60 l - Pump: Agro-Hytos or equivalent ==== Equipment & Controls - Pressure adjustment via rotary regulator - Robust machine frame - Control cabinet technology from renowned manufacturers - Emergency stop switch ==== Documentation & Delivery - CE Declaration of Conformity - Documentation in German - Assembly, commissioning, and operator training available at extra cost ===== Assembly work, press-fitting, workshop applications, small batch production, light forming technology C-frame press, single-column press, hydraulic press, workshop press, press-fitting press, industrial press, die-setup press, tryout press, tool tryout press Are you looking for a hydraulic press tailored to your specific application? Contact us for a customized quotation. Our hydraulic presses are manufactured in compliance with German Machinery Directives, as well as European Machinery Directives (Directive 2006/42/EC), EC standards, and EU safety regulations. Furthermore, our presses surpass Canadian and European safety requirements, as they fully comply with all aspects of the Brazilian national safety standard NR 12, which builds upon these standards. Our key strength lies in custom machine manufacturing and press automation. We offer bespoke hydraulic presses at surprisingly competitive prices. For the hydraulic systems, we mainly use components from leading European manufacturers.

Durumu: kullanılmış, Üretim yılı: 1961, Basınç 0,25 t Godpjxukpcsfx Adrjbk Tabla boyutu 450 x 500 mm Strok 500 mm Montaj yüksekliği 550 mm Çıkıntı 200 mm Tablanın yerden yüksekliği 800 mm Tablada geçiş açıklığı 130 mm

Durumu: kullanılmış, Üretim yılı: 1980, Çıkıntı 350 mm Stroke yaklaşık 400 mm Koç çapı 95 mm Pres kuvveti 25 t Tabla derinliği 450 mm Tabla genişliği 1.500 mm Gbedpfjxgu Itsx Adrsk Tabla yüksekliği 900 mm Makine ağırlığı yaklaşık 2,5 t Alan ihtiyacı yaklaşık 2,0 x 2,0 x 2,3 m Tek kolonlu doğrultma presi MÜLLER - CR 25.2.1 - Çalışma saati: 543h - Çalışma lambası dahil

Durumu: iyi (kullanılmış), Fonksiyonellik: tamamen fonksiyonel, presleme kuvveti: 25 t, strok boyu: 500 mm, masa genişliği: 500 mm, masa uzunluğu: 500 mm, koç mili mesafe tablosu: 800 mm, toplam yükseklik: 2.700 mm, toplam ağırlık: 2.000 kg, Donanım: dokümantasyon / kılavuz, Satılıktır: 1 adet kullanılmış hidrolik pres Üretici: VEB Werkzeugfabrik Zeulenroda WMW Tip: PYE25/1 Toplam ağırlık: 2 ton Nominal presleme kuvveti: 25 MP Gbodpfjxfzdlex Adrek Piston stroku: 500 mm Tabla ile piston arasındaki en büyük mesafe: 800 mm Tabla: 500 x 500 mm Dokümantasyon dahil

Durumu: iyi (kullanılmış), Üretim yılı: 1988, makine/araç numarası: 053-019/35, Teklif 24591 Godpfx Adjwd Nyborsbk Teknik veriler: - maks. presleme kuvveti 25 t - maks. koç stroku 500 mm - Kaldırma hızı 0 - 40 mm/s - 0 - 200 m/dak'ya geri dön - Montaj yüksekliği 800 mm - Boğazdan koç merkezine 360 mm - Koç sıkıştırma yüzeyi 440 x 360 mm - Ram sıkıştırma pimi 40 mm - Masa ölçüsü 630 x 500 mm - Masanın yerden yüksekliği 710 mm - Derin çekme kuvveti 10 t - maksimum derin çekme derinliği 160 mm - Sürücü 400 V / 4 kW - Yaklaşık alan gereksinimi G 800 x Y 2720 x D 1150 mm - Yaklaşık ağırlık 2500 kilo

Durumu: kullanılmış, Üretim yılı: 2000, Basınç 25 ton İnme 150mm Projeksiyon 420 mm Montaj yüksekliği 450 mm Gedpfevut N Nex Adrjbk Masa yüzeyi 700 x 820 mm Zeminden masa yüksekliği 850 mm Ram yüzeyi 600 x 600 mm 370 mm/s'den başlayan hız 370 mm/s'ye kadar hız Çalışma hızı 18 - 33 mm/s Yağ içeriği 300 l Tahrik gücü 5,5 kW Ağırlık 5,8 ton Alan gereksinimi yaklaşık 1,1 x 2,0 x 2,4 mxmxm CE standartlarına uygun olarak el kakma işleri için onaylanmıştır Yağlı-hidrolik tahrikli, basınca/zamana ve mesafeye bağlı olarak kontrol edilebilir, kesme şoku emilimi, mekanik derinlik durdurma, iki elle çalıştırma

Durumu: yeni, Üretim yılı: 2025, Fonksiyonellik: tamamen fonksiyonel, güç: 3 kW (4,08 bg), presleme kuvveti: 25 t, strok boyu: 480 mm, işletme hızı: 13 mm/s, geri hız: 24 mm/s, masa genişliği: 780 mm, masa uzunluğu: 200 mm, yağ tankı kapasitesi: 20 l, toplam uzunluk: 10.400 mm, toplam genişlik: 7.800 mm, toplam yükseklik: 23.000 mm, çalışma basıncı: 230 bar, ÇOK AMAÇLI atölye / hidrolik pres Hem 20 hem de 25 ton kapasiteli modeller mevcut. Gbjdpet A Dznjfx Adrsk BAR-MAN 20: 3.450 euro BAR-MAN 25: 3.990 euro BAR-MAN çok çeşitli uygulamalar için kullanılabilir. Bakım çalışmaları, kama kanalı açma, rulmanların takılıp çıkarılması ve çok daha fazlası için idealdir. Bu güçlü makine ile tüm işlemlerinizi rahatlıkla gerçekleştirebilir ve konforlu bir şekilde çalışabilirsiniz.

Durumu: mükemmel (kullanılmış), Üretim yılı: 1987, Fonksiyonellik: tamamen fonksiyonel, güç: 8,75 kW (11,90 bg), presleme kuvveti: 25 t, strok boyu: 500 mm, işletme hızı: 100 mm/s, geri hız: 450 mm/s, masa genişliği: 630 mm, masa uzunluğu: 500 mm, koç plakası genişliği: 450 mm, tabla uzunluğu: 360 mm, kolonlar arası açıklık: 800 mm, toplam uzunluk: 16.500 mm, toplam genişlik: 10.500 mm, toplam yükseklik: 27.500 mm, toplam ağırlık: 2.200 kg, kalıp yastığı stroku: 160 mm, Hydraulic press PYE 25 S1M with ejector. Year of manufacture: 1987. Manufacturer: VEB Wema Zeulenroda (Germany). Specifications: - Maximum pressing force: 25 tons - Operating pressure: 16 MPa Gbjdotzwxdopfx Adrek - Upper table: 450 x 360 mm - Lower table: 630 x 500 mm - Clearance: 800 mm - Cylinder stroke: 500 mm - Downward speed: 100 mm/s - Upward speed: 450 mm/s - Bottom ejector force: 10 tons - Bottom ejector stroke: 160 mm - Power requirement: 8.75 kW - Weight: 2,200 kg - Height: 2,750 mm, Length: 1,650 mm, Width: 1,050 mm Technical condition of the machine is very good. The machine has undergone a major overhaul. Inspection and testing of the machine under power are possible.

Durumu: kullanılmış, Üretim yılı: 1976, Basınç 20 t Projeksiyon 185 mm strok 100 mm Masa sıkıştırma yüzeyi 380 x 350 mm Montaj yüksekliği 250 mm Tablanın yerden yüksekliği 840 mm Godstqqwuspfx Adrjbk Toplam güç gereksinimi 4 kW Makine ağırlığı yaklaşık 1,3 ton

Durumu: kullanılmış, Tek kolonlu hidrolik pres HYDRAP tip HPSK 25 No. 6312 Yapım yılı 1989 Basınç kuvveti 25 ton. Ram stroku 500 mm boğaz derinliği 300 mm Kurulum yüksekliği 700 mm Masa yüzeyi 1000 x 500 mm Masa deliği Ø 210 mm Piston yüzeyi 400 x 360 mm Sıkıştırma ağzı deliği Ø 40 mm Tablanın yerden yüksekliği 855 mm Hızlı traversde ilerleme hızı 280 mm/sn. Presleme hızı 3,5 mm/sn. ila 25 mm/sn. Dönüş hızı 280 mm/sn. Hidrolik tank kapasitesi 240 litre Tahrik gücü 7,5 kW Şebeke bağlantısı 400 Volt, 50 Hz. - OP1 kontrol sistemi ile SIEMENS S5 üzerinden çalıştırma ve programlama - Strok ayarı için ölçüm sistemi - Potansiyometre ile kademesiz olarak değiştirilebilen presleme hızı - Basınç regülatörü ile manuel olarak kademesiz ayarlanabilen basınç ayarı - Kısa strok cihazı - T yuvaları ve sıkıştırma pimi deliği ile koç üzerinde mekanik takım sıkıştırma Godpfxjhrakve Adrebk - Makine üzerinde elektrik kumandalı şalter dolabı - İki elle kullanım ve ayak kumandası için elektrik bağlantısı - Elektrikli kalıp izleme için sağlanan kontrol - Hidrolik şema ve elektrik şeması mevcuttur Alan gereksinimi U x G x Y 1800 x 1200 x 2930 mm Ağırlık yaklaşık 4 ton iyi durumda

Üretim yılı: 1986, Durumu: yeni gibi (kullanılmış), Satılık hidrolik pres PJ Hare kft C-çerçevesi: Pj Hare Limited satılık hidrolik pres MODEL PRES: 25LE Toplam yükseklik MM: 2425 Toplam genişlik MM: 1120 Toplam derinlik MM: 1470 Ağırlık KG: 2000 Sıkıştırma deliğinin bir parçası. MM: 18 Sabit delik merkezi MM x MM: 610 x 1108 Sabit plakanın boyutları MM x MM: 120 x 250 Yağ hacmi L: 50 Maks bar: 6 Hava basıncı min.bar: 4 Ana motor gücü kW: 7,5 Motor sigortası A: 20 Yastıkla birlikte Güç kaynağı: min. Sigorta A: 35 Min. Tel boyutu mm: 2.5 2. Kapama yüksekliği: 200 Maks. Sonraki veto: 450 Fermuar yükseklik ayarı: 100 Kapı derinliği: 250 Yatak yüksekliği: 650 Yatak derinliği: 480 Önden merkez hattına: 250 Açıklık çapı: 150 Yatak altı Açıklık: 350/250 Tişört konum bilgisi: 18,15,34 ,33 Yük kalınlığı: 95 Yan oluk genişliği: - Yeşil oluk genişliği: 255 Oluk genişliği: 250 Yükseklik [...] Godpfxjhcfyus Adrsbk

Durumu: yeni, Üretim yılı: 2021, presleme kuvveti: 17 t, Single-column press – Manufacturer: Hidrobrasil – 17 t C-frame press – Table 400 × 400 mm For sale is a compact hydraulic single-column press (C-frame) from Hidrobrasil with a pressing force of 17 t. This machine is designed for continuous shift operation and is ideally suited for assembly, pressing, and light forming tasks. Thanks to its robust construction and simple operation, it is versatile for workshop and production use. ==== Technical data & information: Hydraulic single-column press – C-frame – 17 t ==== General Information - Manufacturer: Hidrobrasil - Model: Single-column press - Design: C-frame press / single-column press - Pressing force: max. 17 t (170 kN) - Pressure range: adjustable from 5 to 17 t - Total weight: approx. 1 t - Dimensions (L × W × H): approx. 1,150 × 800 × 2,200 mm - Table height: 850 mm - Operating sides: 1 ==== Working Area - Max. opening width: 250 mm - Stroke: 100 mm - Minimum opening: 100 mm - Parallel deviation: ± 0.1 mm ==== Table & Ram - Table plate: 400 × 400 mm - Ram plate: 200 × 200 mm - Features: with T-slots and central cylinder clamping ==== Speeds - Advancing speed: 10 mm/s - Return speed: up to 25 mm/s - Pressing speed: approx. 10 mm/s ==== Hydraulics - Number of cylinders: 1 - Operating pressure: max. 250 bar - Pressure accuracy: ± 5 bar - Pump: Gear pump, approx. 6 l/min - Oil volume: approx. 100 l (HLP 46) - Oil temperature: max. 55 °C Gbjdsgrki Sepfx Adrek - Ambient temperature: max. 40 °C ==== Drive & Electrical - Motor power: 2.2 kW - Total connected load: approx. 3 kW - Main supply: 400 V AC - Control voltage: 24 V DC - Frequency: 50 Hz ==== Features & Operation - Hand lever control with two speeds - Pressure adjustment via rotary knob - Oil temperature display - Control cabinet mounted on right - Supply line: 3,000 mm cable with 16 A plug - Machine body powder-coated / double painted ==== Control Cabinet - Protection class: IP54 - Reserve space: approx. 20 % - Cooling: none - Internal lighting: none - Mode selector switch: lockable ==== Construction & Safety - Hydraulic unit mounted on top of the machine - Constructed as an oil-hydraulic single-column press - Complies with current accident prevention regulations (UVV) and EU directives ===== Assembly work, pressing tasks, small-batch production, workshop applications, light forming technology Single-column press, C-frame press, hydraulic press, workshop press, assembly press, industrial press, die spotting press, tryout press, tool try-out press Are you looking for a hydraulic press tailored to your application? Contact us for an individual quotation. Our hydraulic presses are manufactured in accordance with German machine guidelines, European Machinery Directive (Directive 2006/42/EC), EC standards, and EU safety regulations. In addition, our presses surpass Canadian and European safety requirements, as they fully comply with the national Brazilian safety guideline NR 12, which builds upon these standards. Our greatest strength lies in custom machine engineering and press automation. We supply tailor-made hydraulic presses at surprisingly attractive prices. For the hydraulics, we mainly use components from leading European manufacturers.

Durumu: yeni, Üretim yılı: 2019, makine/araç numarası: DF0287, presleme kuvveti: 25 t, Assembly Press – Manufacturer: Hidrobrasil – 25 t Laboratory Press with Sliding Table – Table 1000 × 800 mm Gbodpfx Adofxyikorjk For sale is a hydraulic assembly and disassembly press from Hidrobrasil, offering 25 tons of pressing force. This machine is equipped with both a sliding table and an additional assembly table, making it ideally suited for precise assembly, disassembly, and testing operations in workshops, laboratories, and production environments. ==== Technical Specifications & Information: Hydraulic Assembly Press – 25 t – Sliding Table ==== General Information - Manufacturer: Hidrobrasil - Model: Assembly Press / Laboratory Press - Design: Single-column press with sliding table - Pressing force: 25 t - Machine weight: approx. 4 t - Dimensions (L × W × H): approx. 2,054 × 2,200 × 3,126 mm ==== Working Area - Clearance width: 1,000 mm - Stroke: 800 mm - Max. working height: 800 mm - Table height: approx. 850 mm ==== Table & Ram - Table plate: 1,000 × 800 mm - Ram plate: 400 × 400 mm - Ram thickness: 122 mm - Table cut-out: 650 × 150 mm - Additional assembly table: 1,000 × 800 mm (mounted on the left) - Steel plate on rollers: 600 × 400 × 15 mm ==== Guidance & Construction - Ram guidance: 4 chrome-plated linear guides Ø 50 mm - Type of guide: Bronze bearings ==== Speeds - Approach speed: up to 80 mm/s - Pressing speed: 10 mm/s - Rapid traverse: 80 mm/s ==== Hydraulics - Motor power: 5 kW - Retraction force: 2 t - Oil tank volume: 200 l ==== Control & Operation - Control system: Siemens S7-1200 - Monitor: Siemens, 10" - Operation: precision control for assembly and disassembly processes ==== Safety - Light curtains: Schmersal, 1,800 mm from floor level ===== Assembly work, disassembly work, testing operations, laboratory applications, press fitting, service and maintenance Assembly press, laboratory press, hydraulic press, single-column press, sliding table press, industrial press, die setting press, tryout press, tool try-out press Are you looking for a hydraulic press tailored to your specific application? Contact us for a custom quote. Our hydraulic presses are manufactured in accordance with German machine directives as well as European machinery directives (Directive 2006/42/EC), EC standards, and EU safety regulations. Furthermore, our presses exceed Canadian and European safety requirements, as they meet all aspects of the Brazilian national safety standard NR 12, which is based on these requirements. Our greatest strength lies in special purpose machine construction and press automation. We supply custom-made hydraulic presses at surprisingly competitive prices. Hydraulic systems on our presses are fitted primarily with components from leading European manufacturers.

Durumu: mükemmel (kullanılmış), Üretim yılı: 1990, Kuvvet 25 ton Boğaz 160mm Günışığı 500mm Masa boyutu 650x650mm Ram boyutu yuvarlak 140mm İnme 130mm istenen güç 4 KW Ağırlık 2000Kg yükseklik 2100mm genişlik 1100mm derinlik 1500mm Gsdpfx Adjfcw Apjrsbk
