Segmented folding machine TB 1020, box and pan brake

Bernardo TB 1020

Bernardo TB 1020 is a universal, manual segmented bending machine with a working length of 1020 mm, ideal for sheet metal work in repair and craft workshops. The machine features a robust construction and a foot-operated upper beam clamping system, allowing the operator to position the workpiece freely with both hands. Thanks to the exchangeable segmented upper beam, the machine precisely forms various profiles and boxes from sheet metal up to 2.5 mm thick.

- Bending machine for universal use in repair and metalworking workshops
- Compact, stable design with a modern look
- Simple adjustment of the upper beam clamping via foot pedal; both hands remain free to accurately position the workpiece
- Manual bender for standard tasks
- Segments on the upper clamping beam expand bending possibilities
- Offered at a competitive price
- Fast and easy operation with a handle
- Pedal covered with non-slip rubber sheath
- Simple lower beam clamping adjustment to suit sheet thickness
- High upper beam clamping force for tall bend profiles
- Segment sizes: 2.5 / 3 / 3.5 / 4 / 4.5 / 5.0 / 7.5 / 10 / 15 / 20 / 27 cm

Technical specifications:
Working length: 1020 mm
Max. sheet thickness (mild steel): 2.5 mm
Dkjdpfx Aaeyn Iiuszsw
Max. opening: 48 mm
Bending angle: 0 - 135°
Dimensions (width): 1350 mm
Dimensions (depth): 1115 mm
Dimensions (height): 1140 mm
Weight approx.: 290 kg
