CNC abkant presler

KK Kletzer CNC Abkantpresse KKI EUROPA XL 1550 mm x 60 to Esa

Durumu: yeni, Üretim yılı: 2024, Hydraulic Press Brake PBO-3220-CNC Delem DA-58T Technical Specifications - Nominal press force: 2000 kN - Maximum bending length: 3200 mm - Throat depth (distance between tool and back wall): 320 mm - Maximum ram stroke: 200 mm - Maximum open height: 480 mm - Distance between side frames: 2600 mm - Maximum back gauge travel: 600 mm - Motor power: 15.0 kW - Length: 3300 mm - Width: 1800 mm - Height: 2900 mm - Weight: 10,500 kg Tooling - Front sheet supports: 2 pcs - Back gauge positioning (X-axis): Servo drive - Ram positioning (Y-axis): Servo drive - Back gauge finger height adjustment (R-axis): Manual - Punch clamping type: AMADA-type quick-release system Delem DA-58T Control - Advanced operator support based on intelligent algorithms Hsdpeipxzpofx Agfji - Enhanced graphical simulation of bending processes - On-screen operator guidance - Algorithms for reducing cycle times - Automatic crowning Manual crowning (optional*) This feature ensures the operator can always maintain a consistent bending angle across the full length of the workpiece. Automatic crowning (optional*) Allows the control system to monitor and automatically adjust crowning, guaranteeing optimal settings at all times. OCS The oil cooling system ensures stable machine parameters, even under extended continuous operation. Professional support We ensure continuous contact with our customers. That’s why, with every machine purchase, we provide an hourly package for professional support by Otinus technicians. Come and test our machines Take part in a unique demonstration, where a qualified Otinus technician will present all machine functionalities. You are welcome to bring your technical drawings and sample materials. Machine delivery includes: A two-day operator training and commissioning - Day 1 (up to 8 hours) – Commissioning and control training. - Day 2 (up to 8 hours) – Independent work on the machine under technician supervision, with the option to program specific parts. Telephone consultation with a specialist - Available Mon-Sat, 7:30 to 21:00 – an 8-hour package to be used within 12 months. Free loan of transport rollers and two hydraulic jacks to facilitate installation at the customer’s site. Rollers and jacks will be provided upon prior request (at least 7 days before machine delivery). Terms of cooperation - 24-month warranty period. - Delivery time: approx. 6-8 weeks. Excludes machines marked as in stock. - The machine is brand new. - Dealer warranty and post-warranty service. - The customer is responsible for the machine during unloading and transportation on site.

Durumu: yeni, Üretim yılı: 2024, Hydraulic Press Brake PBO-3225-CNC Delem DA-58T Technical Specifications - Maximum sheet thickness (S235): up to 10.0 mm - Rated force: 2500 kN - Maximum bending length: 3200 mm - Throat depth (distance between tool and back wall): 400 mm - Maximum beam stroke: 250 mm - Maximum open height: 535 mm - Distance between frames: 2500 mm - Maximum backgauge travel: 600 mm - Motor power: 18.5 kW - Length: 3300 mm - Width: 1850 mm - Height: 2900 mm - Weight: 11,600.0 kg Tooling - Front support arms: 2 pcs. Hjdpeium Hkefx Agfei - Backgauge adjustment (X axis): servo drive - Beam adjustment (Y axis): servo drive - Backgauge finger height adjustment (R axis): manual - Punch clamping system: AMADA-type quick change Delem DA-58T Control System - Advanced operator guidance based on algorithms - Enhanced graphical bending simulation - Operator prompts - Algorithms for reduced production time - Automatic crowning Manual Crowning (optional*) This feature ensures that the bend angle is consistent across the full length of the workpiece. Automatic Crowning (optional*) Enables the controller to monitor and automatically adjust crowning, ensuring optimal settings at all times. OCS The oil cooling system guarantees stable machine parameters, even during prolonged continuous operation. Professional Support We maintain continuous contact with our customers by offering a professional support package with each machine purchase. Otinus technicians provide expert assistance as part of this service. Test Our Machines Participate in a demonstration led by a qualified Otinus technician and experience the machine’s full functionality. You may bring technical drawings and sample material. Machine Delivery Includes: - Two-day operator training and commissioning - Day 1 (up to 8 hours): Commissioning and control software training - Day 2 (up to 8 hours): Independent operation under technician supervision, including part programming - Telephone support from a specialist - Available Mon-Sat, 7:30–21:00 (8-hour package valid for use within 12 months) - Free lending of transport rollers and two jacks to aid machine setup at your premises. Rollers and jacks are supplied upon prior request (at least 7 days before delivery). Terms & Conditions - 24-month warranty - Delivery time: approx. 6-8 weeks (unless in-stock availability is specified) - The machine is brand new - Warranty and post-warranty support provided by the seller - Customer is responsible for the machine during unloading and on-site transport.

Durumu: yeni, Fonksiyonellik: tamamen fonksiyonel, Üretim yılı: 2025, çalışma saatleri: 1 h, makine/araç numarası: Bull30_1, çalışma genişliği: 3.100 mm, strok boyu: 270 mm, direkler arası mesafe: 3.200 mm, geri hız: 40 mm/s, X ekseni hareket mesafesi: 600 mm, arka dayama: 600 mm, arka dayama hızı R ekseni: 100 mm/s, Arka dayama hareket mesafesi R-eksen: 250 mm, arka dayanak hareket mesafesi Z ekseni: 3.200 mm, toplam ağırlık: 16.000 kg, toplam uzunluk: 20.000 mm, toplam genişlik: 40.100 mm, toplam yükseklik: 32.000 mm, garanti süresi: 36 aylar, Y ekseni hareket mesafesi: 270 mm, Z ekseni hareket mesafesi: 3.200 mm, presleme kuvveti: 250 t, yükseklik ayar tipi: elektrikli, montaj çapı: 3.100 mm, hızlı travers X ekseni: 500 m/dak, hızlı tablası Y ekseni: 40 m/dak, gereken yükseklik: 3.500 mm, alan gereksinimi uzunluk: 2.000 mm, gereken genişlik: 4.010 mm, masa genişliği: 3.200 mm, R ekseni hareket mesafesi: 250 mm, çalışma uzunluğu: 3.100 mm, Donanım: emniyet ışık bariyeri, Elektrikli abkant pres Bull30 CoastOne Oy - Finlandiya'da üretilmiştir İş mili tahriki - 5 kontrollü iş mili Üst kirişte doğrudan kontrollü taçlandırma Presleme kuvveti: 2500kN Bükme uzunluğu: 3100mm Işık bariyeri: Lazersafe IRIS Takım bağlama: WILA hidrolik Arka dayama: X-R-Z1-Z2 kontrollü Kontrol: TC15-2D grafik kontrolü Ön destek kolları, yüksekliği ayarlanabilir ve katlanabilir Önde ve durma alanında çalışma lambası Hjdpfx Agevnrdlofoi Talep üzerine fiyat ve teslim süresi Talep üzerine daha fazla donanım seçeneği Garanti: Kurulumdan 36 ay sonra

Durumu: yeni, Pressure: 200 t Bending length: 3200 mm Frame width: 2700 mm Installation height: 400 mm Stroke length (max.): 200 mm Throat depth: 350 mm Dimensions (LxWxH): 3700 x 1700 x 2700 mm Weight approx.: 14,000 kg CNC Press Brake 3200 mm x 200 t Standard equipment: ----- Robust construction CNC axes: Y1, Y2, X, and R axis CNC crowning device, motorized with CNC control CNC control: Original DELEM DA 58 T touchscreen 15 inch Backgauge with linear guide and ball screw, equipped with 4 stop fingers 2 sheet support arms Laser safety device on the upper beam Quick-clamping system for the upper tool Upper tool system: Promecam/Amada segmented gooseneck type Hjdpfettxh Njx Agfei Multi V-die system compatible with both Promecam and Amada system CE safety equipment
