KUVERTANLEGER

STENZ FEEDER

Equipment / further information:
WITH DELIVERY BELT

Bypass Belts:
For envelope format 10.5 cm x 14.8 cm and for portrait orientation, the bypass belts should be positioned towards the center conveyor belt.
Rule: For large envelopes, move the bypass belts outward, for small envelopes, push the bypass belts (22) inward.

CONNECTION TO THE PRINTING MACHINE
The STENZ FEEDER does not require synchronization. Simply guide the feeder into the printing machine using the handles and set the required height with the hand crank.
Important: Only after the print height is set, secure the rear rollers and check stability. Switch on the machine and start printing.

For single-sheet-fed presses (GTO), the feeder offers adjustable tilt.
Trouble-free envelope printing can begin.

Developed for heavy-duty use at maximum printing speed.
Compatible with all 36 x 52 presses, regardless of feed system (overlapping/single-sheet feeder).
- No mechanical modifications to the printing press required.
- No synchronization settings are necessary, thanks to laser technology.
- Extremely short setup times allow cost-efficient operation from as little as 1000 envelopes
- Easy operation
- The feeder’s design forces sheet overlapping. Thus, throughput of the Stenz Feeder is not limited
- Minimal wear parts for extremely long service life
- Already approved in thousands of different printing presses
- A Swiss quality product
- Designed by printers for printers

Specifications:
Speed: Limited by printing machine
Length: 115 cm
Width: 50 cm
Adjustable height
Cedpfx Adsw Rvu Ds Uehc
Max. format size: 36.5 x 35 cm
Max. feed width: 36.5 cm
Electrical: 230 V, 50 Hz
