Santrifüj tesisi

Walther Trowal TT 90-A/2C-V9

Gross volume: 90 l, max. usable volume: 60 l, max. fill weight: 175 kg, disc drive type: frequency-controlled electric geared motor, disc drive rated power: 4 kW, disc nominal speed: 213 rpm, tilting drive type: hydraulic cylinder, tipping angle: 49°, max. discharge height when tilting: 2200 mm, loader tilting drive type: hydraulic cylinder, tipping angle: 41°, max. discharge height when tilting: 2700 mm, buffer drive type: electric unbalance motor, drive power: 0.3 kW, tilting drive type: hydraulic cylinder, tilting range: -25° to 12°, screening machine drive type: 2x electric unbalance motor, drive power: 2x 0.25 kW, abrasive media return chute drive type: electric unbalance motor, drive power: 0.19 kW, hydraulic unit flow rate: 8.0 l/min, operating pressure: 170 bar, pump motor drive power: 3 kW, tank volume: 30 l, valve voltage: G24, length: 2812 mm, width: 2094 mm, operating hours: 14,021 h, motor operating hours: 427 h. Application areas: edge rounding, coarse and fine grinding, descaling, degreasing, glazing, polishing, deburring, cleaning. With documentation, inspection on site possible.
