I.S.M. Industrieservice GmbH
I.S.M. Industrieservice GmbH dan Babenhausen
Firma I.S.M. Industrieservice GmbH wurde im Jahre 2017 gegründet und in ganz Europa erfolgreich.
Ob unser Service oder unsere Produkte, alles ist von höchster Qualität.
Sie bekommen durch unser großes Netzwerk alles aus einer Hand zu Herstellerkonditionen!!!
Egal ob Werkzeugmaschine, Späneförderer, Markiersysteme oder Spänebrecher, Absauganlagen, Filtersysteme oder Zentrifugenanlagen, wir können Ihnen alles bieten!!!
Sn. (Bay) Murat Yildirim
Stadtgasse 19
87727 Babenhausen
Almanya
Benzer satıcılardan güncel teklifler
Küçük ilan
Wiesbaden
2.448 km
Gravür makinesi
SK LASER GmbHUV-Faserlaser 355nm, 6 W – NEU
SK LASER GmbHUV-Faserlaser 355nm, 6 W – NEU
Ara
Durumu: yeni, Üretim yılı: 2026, Fonksiyonellik: tamamen fonksiyonel, mil uzunluğu: 355 mm, giriş voltajı: 230 V, giriş akımı türü: Klima, lazer gücü: 6 W, soğutma tipi: hava, toplam genişlik: 920 mm, toplam yükseklik: 1.760 mm, toplam uzunluk: 940 mm, yükseklik ayar tipi: elektrikli, tarama alanı uzunluğu: 110 mm, tarama alanı genişliği: 110 mm, Z ekseni hareket mesafesi: 500 mm, masa uzunluğu: 710 mm, masa genişliği: 400 mm, lazer dalga boyu: 355 nm, ortam sıcaklığı (min.): 15 °C, ortam sıcaklığı (maks.): 35 °C, giriş frekansı: 50 Hz, ekstraksiyon meme çapı: 50 mm, çalışma genişliği: 110 mm, Donanım: kabin, UV Fiber Laser 355 nm, 6 W – NEW, SK LASER KOLLTRONIC with Workstation, Made in Germany
Beam Source: IPG – Made in Germany
Laser Safety Class 1
Workstation:
- Combined sitting/standing workstation with ergonomic legroom
- Full enclosure constructed from aluminum profiles
- Front door with laser safety glass for unobstructed viewing
- Bright workspace illumination
- Dimensions: H 1760 × W 920 × D 940 mm
- Work platform: Stainless steel plate with 25 mm grid (710 × 400 mm)
- Rear service door, bolted on for easy part insertion
- Motorized Z-axis: Travel range 500 mm (focus depends on lens)
- Extraction port DN50 (extraction system optional)
- Safety (PL4)
- Emergency stop
- Interlock with 2 standard relays
- Safety relay for door monitoring
UV Fiber Laser:
- Wavelength: 355 nm
- Power: 6 W 40 kHz
- Pulse energy: 20 µJ
- Pulse frequency: 10–300 kHz
- Air-cooled
- Pilot laser (red light) + 2 distance lasers for focus adjustment (Laser Class 2)
- Laser head manually adjustable in Y-direction
Scanner & Optics:
- F-Theta lens F = 160 mm, anti-reflective protective glass
- Marking area: 110 × 110 mm
Control:
- Windows 11
- 19" TFT monitor, keyboard, mouse
- Interfaces: RS232 / Ethernet / USB
- KOLLTRONIC marking software: text, logos, QR/data matrix, barcodes
Hfedeyiz Dzspfx Aggoc
Operation:
- 230 V / 50 Hz
- 15–35 °C
Condition:
- Brand new machine
- CE-compliant · Made in Germany
Küçük ilan
Wiesbaden
2.448 km
Gravür makinesi
SK LASER GmbHF20iW1 MOPA 20W mit X/Y/Z Verfahrung
SK LASER GmbHF20iW1 MOPA 20W mit X/Y/Z Verfahrung
Ara
Durumu: yeni, Üretim yılı: 2026, Fonksiyonellik: tamamen fonksiyonel, mil uzunluğu: 1.070 mm, giriş voltajı: 230 V, giriş akımı türü: Klima, lazer gücü: 20 W, soğutma tipi: hava, yükseklik ayar tipi: elektrikli, tarama alanı uzunluğu: 175 mm, tarama alanı genişliği: 175 mm, X ekseni hareket mesafesi: 500 mm, Y ekseni hareket mesafesi: 500 mm, Z ekseni hareket mesafesi: 350 mm, lazer dalga boyu: 1.070 nm, ortam sıcaklığı (min.): 15 °C, ortam sıcaklığı (maks.): 35 °C, giriş frekansı: 50 Hz, ekstraksiyon meme çapı: 50 mm, çalışma genişliği: 175 mm, Donanım: kabin, SK LASER KOLLTRONIC F20iW1 · IPG MOPA 20 W · XXL Workstation · X/Y/Z Axes Travel
Laser Safety Class 1 · CE · Made in Germany
System Concept:
- New complete system consisting of a 20 W IPG MOPA fiber laser combined with an XXL workstation for productive operation. The workstation features a removable central worktable, with the floor area beneath the table freely accessible.
XXL Workstation:
- Seated/standing workstation with ample legroom
- Aluminum housing
- Bright work light, DN50 suction nozzle
- Side and front doors: left and right sides, front door with slot
Hfjdpfxoyizvws Aggoc
- Doors monitored by sensors, safety equipment: emergency stop, interlock, safety relay
Axis System – SK LASER X/Y/Z Travels:
- Gantry with two motorized Z-axes and rotary axis
- X-axis: 500 mm, computer-controlled
- Y-axis: 2 × 500 mm, computer-controlled
- Z-axis: 350 mm, computer-controlled (travel distance depends on installation)
- Two spindles per axis for increased stability
- Axis controller
- Made in Germany
Laser – IPG MOPA Fiber Laser:
- Output power: 20 W
- Peak power: 1 mJ at 20 kHz
- Pulse duration: 2-350 ns, MOPA (suitable for plastics)
- Wavelength: 1060–1070 nm
- Pulse frequency: 20–80 kHz
- Beam quality M² < 1.6
- Air-cooled, power consumption < 400 W
- Red pilot laser + 2 distance lasers (650 nm,
Küçük ilan
Wiesbaden
2.448 km
Gravür makinesi
SK LASER GmbHF20iW1 – 20W mit autom. Schubladensystem
SK LASER GmbHF20iW1 – 20W mit autom. Schubladensystem
Ara
Durumu: yeni, Üretim yılı: 2026, Fonksiyonellik: tamamen fonksiyonel, mil uzunluğu: 1.070 mm, iş parçası ağırlığı (maks.): 300 kg, giriş voltajı: 230 V, giriş akımı türü: Klima, lazer gücü: 20 W, soğutma tipi: hava, yükseklik ayar tipi: elektrikli, tarama alanı uzunluğu: 175 mm, tarama alanı genişliği: 175 mm, X ekseni hareket mesafesi: 500 mm, Y ekseni hareket mesafesi: 500 mm, Z ekseni hareket mesafesi: 350 mm, masa uzunluğu: 700 mm, masa genişliği: 500 mm, lazer dalga boyu: 1.070 nm, ortam sıcaklığı (min.): 15 °C, ortam sıcaklığı (maks.): 35 °C, giriş frekansı: 50 Hz, ekstraksiyon meme çapı: 50 mm, Donanım: kabin, New: SK LASER KOLLTRONIC F20iW1 – 20 W IPG fiber laser with automatic drawer system, Laser Class 1
System Concept:
- Complete system consisting of fiber laser + Workstation 1 with drawer system for productive loading and unloading.
- Automatic start of the laser job when the drawer is closed. The laser head is automatically moved out of the work area in the Z-direction at the end of the job.
Workstation & Drawer System:
- Sit/stand workstation with ample legroom
- Aluminum housing
- Bright work light, suction nozzle DN50
- Drawer system: 2 positions, max. load 300 kg (150 kg per side)
- Drawer dimensions approx. H = 500 mm × W = 700 mm, motorized operation
- Doors monitored by sensors, safety equipment: emergency stop, interlock, safety relay
Axis System – SK LASER X, Y, Z Drive:
- X-axis 500 mm computer-controlled
- Y-axis 2 × 500 mm computer-controlled
- Z-axis 350 mm computer-controlled (travel distances depend on installation)
- 2 spindles each for increased stability
- Axis controller
- Made in Germany
Laser – IPG Fiber Laser:
- Diode-pumped ytterbium fiber laser
- Output power: 20 W
- Peak power: 1 mJ at 20 kHz
- Pulse duration: 200 ns
- Wavelength: 1060 – 1070 nm
- Pulse frequency: 20–80 kHz
- Beam quality M² < 1.6
- Air cooled, power consumption < 400 W
- Red pilot laser + 2 distance lasers (650 nm,
Hedpjyizr Sofx Aggofc
Küçük ilan
Wiesbaden
2.448 km
Gravür makinesi
SK LASER GmbHF20iW1 – Workstation XXL mit Schiebed
SK LASER GmbHF20iW1 – Workstation XXL mit Schiebed
Ara
Durumu: yeni, Üretim yılı: 2026, Fonksiyonellik: tamamen fonksiyonel, mil uzunluğu: 1.070 mm, iş parçası ağırlığı (maks.): 350 kg, giriş voltajı: 230 V, giriş akımı türü: Klima, lazer gücü: 20 W, soğutma tipi: hava, toplam genişlik: 1.200 mm, toplam yükseklik: 1.800 mm, toplam uzunluk: 940 mm, çalışma aralığı: 175 mm, yükseklik ayar tipi: elektrikli, kapı açıklığı genişliği: 1.100 mm, kapı açıklık yüksekliği: 700 mm, tarama alanı uzunluğu: 175 mm, tarama alanı genişliği: 175 mm, Z ekseni hareket mesafesi: 400 mm, masa uzunluğu: 710 mm, masa genişliği: 400 mm, lazer dalga boyu: 1.070 nm, ortam sıcaklığı (min.): 15 °C, ortam sıcaklığı (maks.): 35 °C, giriş frekansı: 50 Hz, ekstraksiyon meme çapı: 50 mm, çalışma genişliği: 175 mm, Donanım: kabin, Laser safety class 1 · Made in Germany · NEW
12-month warranty
System & Workstation:
- Combined seated/standing workstation, aluminum enclosure
- Fully glazed right front door, safety glass, laser class 1
- Bright working lamp, DN50 extraction port
- Standard size: H 1760 × W 920 × D 940 mm
- Workstation XXL: W 1200 × H 1800 × D 940 mm, sliding roof for crane loading, max. 350 kg
- Manual sliding door, opening approx. 1100 × 700 mm
- Safety equipment: emergency stop, dual-channel interlock, performance level 4
- Motorized Z-axis, travel range 400 mm, focus depends on lens used
Hfsdeyipxaepfx Aggoc
Laser:
- IPG ytterbium fiber laser
- Output power 20 W, pulse energy 1.0 mJ
- Wavelength 1060–1070 nm, pulse duration 100 ns
- Pulse frequency 20–80 kHz, air-cooled, power consumption < 400 W
- Beam quality M² < 1.2
- Pilot laser + 2 distance lasers, Y-direction adjustable manually
Scanner & Control:
- F-Theta lens F = 254 mm, marking field 175 × 175 mm
- Windows 11 Pro, SSD, 23" monitor, keyboard & mouse
- Interfaces: RS232, Ethernet, USB
- SK CONTROL software for texts, logos, QR/DataMatrix codes, barcodes
Working Area & Safety:
- Magnetic positioning on stainless steel platform 710 × 400 mm, 25 mm grid
- Operating conditions: 230 V / 50 Hz, 15–35 °C
Küçük ilan
Wiesbaden
2.448 km
Gravür makinesi
SK LASER GmbHF50iW1 50 W Faserlaser – Workstation 1,
SK LASER GmbHF50iW1 50 W Faserlaser – Workstation 1,
Ara
Durumu: yeni, Üretim yılı: 2026, Fonksiyonellik: tamamen fonksiyonel, mil uzunluğu: 1.070 mm, iş parçası ağırlığı (maks.): 150 kg, giriş voltajı: 230 V, giriş akımı türü: Klima, lazer gücü: 50 W, soğutma tipi: hava, çalışma aralığı: 175 mm, yükseklik ayar tipi: elektrikli, tarama alanı uzunluğu: 175 mm, tarama alanı genişliği: 175 mm, masa yüksekliği: 710 mm, masa uzunluğu: 710 mm, masa genişliği: 400 mm, lazer dalga boyu: 1.070 nm, ortam sıcaklığı (min.): 15 °C, ortam sıcaklığı (maks.): 35 °C, giriş frekansı: 50 Hz, ekstraksiyon meme çapı: 50 mm, çalışma genişliği: 110 mm, Donanım: kabin, IPG Laser Source – Laser Class 1 · Made in Germany
Workstation – Heavy-Duty Design:
- Sit/stand workstation, fully enclosed aluminum housing
- Front door with laser safety glass, bright work lighting
- Stainless steel work platform, 25 mm perforated grid (710 × 400 mm)
- Manually adjustable drawer, precision rails, load capacity up to 150 kg
- Suction nozzle DN50, motorized Z-axis (travel distance 500 mm)
- Interlock, emergency stop, safety relay performance level 4
Fiber Laser:
- Diode-pumped ytterbium fiber laser, 50 W
- Pulse energy: 1.0 mJ, pulse duration 100 ns
- Wavelength: 1060–1070 nm, pulse frequency 20–200 kHz
- Beam quality M² < 1.2
- Air-cooled, power consumption < 400 W
- Pilot laser + 2 distance lasers (Laser Class 2)
Hfsdpfxeyim S Is Aggoc
Scanner & Optics:
- F-theta lens F = 160 mm (marking field 110 × 110 mm)
- Optional: F = 254 mm, travel up to table height
- X-Y galvo scanner for 1064 nm
- Scanning speed max. 4 m/s
Control & Software:
- Industrial PC, Windows 11
- Monitor, keyboard & mouse, monitor arm
- KOLLTRONIC marking software: texts, logos, QR/Data Matrix codes, barcodes
- Matrix function for batch processing
- Easy positioning, focusing, designing, working, coding
Additional:
- Rotary engraving unit for cylindrical parts up to Ø 60 mm
- Controller & software upgrade included
Operating Conditions:
- Power supply: 230 V / 50 Hz
- Operating temperature: 15–35 °C
Condition:
- New machine
- CE-compliant
- Made in Germany
Küçük ilan
Wiesbaden
2.448 km
Gravür makinesi
SK LASER GmbHF20iMW1 – 20 W MOPA Faserlaser mit Work
SK LASER GmbHF20iMW1 – 20 W MOPA Faserlaser mit Work
Ara
Durumu: yeni, Üretim yılı: 2026, Fonksiyonellik: tamamen fonksiyonel, mil uzunluğu: 1.064 mm, iş parçası ağırlığı (maks.): 250 kg, giriş voltajı: 230 V, giriş akımı türü: Klima, lazer gücü: 20 W, toplam yükseklik: 2.700 mm, çalışma aralığı: 175 mm, yükseklik ayar tipi: mekanik, tarama alanı uzunluğu: 175 mm, tarama alanı genişliği: 175 mm, masa uzunluğu: 1.200 mm, masa genişliği: 1.200 mm, gereken yükseklik: 2.700 mm, lazer dalga boyu: 1.064 nm, çalışma yüksekliği: 500 mm, ortam sıcaklığı (min.): 15 °C, ortam sıcaklığı (maks.): 35 °C, giriş frekansı: 50 Hz, ekstraksiyon meme çapı: 50 mm, çalışma genişliği: 175 mm, Donanım: kabin, IPG fiber laser type M · Laser class 1 · Made in Germany
Workstation XXL – Special Construction:
- Standing workstation with table height designed for standing operation
- Folding sliding door, right side fully glazed, safety glass class 1
- Bright work light
- DN50 stainless steel suction nozzle
- Heavy-duty drawer system: up to 250 kg, internal dimensions 1.2 × 1.2 m
Hedpsyimz Asfx Aggofc
- Outside position: loading/unloading
- Inside position: laser processing
- Programmable auto-start, magnetic switch as interlock
- Double-sided slot for extra-long parts, beam protection brush
- Roof height for parts up to 500 mm under 254 mm lens
- Z-axis manual, base value can be stored
- Exterior height of the machine: approx. 2.50–2.70 m
Laser – IPG MOPA:
- Diode-pumped ytterbium fiber laser
- Power: 20 W
- Pulse duration adjustable (suitable for plastics)
- Wavelength: 1064 nm
- Pilot laser + 2 distance lasers (650 nm,
Küçük ilan
Wiesbaden
2.448 km
Gravür makinesi
SK LASER GmbHF20iW1 – 20 W Faserlaser mit elektrische
SK LASER GmbHF20iW1 – 20 W Faserlaser mit elektrische
Ara
Durumu: yeni, Üretim yılı: 2026, Fonksiyonellik: tamamen fonksiyonel, mil uzunluğu: 1.070 mm, giriş voltajı: 230 V, giriş akımı türü: Klima, lazer gücü: 20 W, soğutma tipi: hava, toplam genişlik: 920 mm, toplam yükseklik: 940 mm, toplam uzunluk: 1.760 mm, kapı açıklığı genişliği: 670 mm, kapı açıklık yüksekliği: 500 mm, tarama alanı uzunluğu: 175 mm, tarama alanı genişliği: 175 mm, Z ekseni hareket mesafesi: 400 mm, masa yüksekliği: 710 mm, masa uzunluğu: 710 mm, masa genişliği: 400 mm, gereken genişlik: 920 mm, gereken yükseklik: 940 mm, lazer dalga boyu: 1.070 nm, alan gereksinimi uzunluk: 1.760 mm, ortam sıcaklığı (min.): 15 °C, ortam sıcaklığı (maks.): 35 °C, giriş frekansı: 50 Hz, ekstraksiyon meme çapı: 50 mm, çalışma genişliği: 175 mm, Donanım: kabin, Fiber laser system for professional marking and engraving of metals and plastics.
With SK-LASER workstation, laser class 1, and automatic lift door.
Laser class 1 · CE · Made in Germany
System & Lift Door:
- Complete system: IPG fiber laser + workstation + electric lift door
Process Workflow:
- Start → Door closes → Laser process → Door opens automatically
- Door opening approx. H 500 × W 670 mm
- Access protection via safety control system
Laser – IPG (Made in Germany):
- Power: 20 W
- Pulse energy 1.0 mJ
- Pulse duration 100 ns
- Frequency 20–80 kHz
- Wavelength 1060–1070 nm
- Beam quality M² < 1.2
- Air-cooled, < 400 W
Optics & Scanner:
- F-Theta f = 254 mm
- Marking area 175 × 175 mm
- Pilot laser + 2 distance lasers
- Manually adjustable laser head (Y-axis)
Control System:
- Windows 11 Pro, SSD, 23" monitor
- Interfaces: Ethernet / USB / RS232
- SK CONTROL: text, logos, QR codes, variable data, parameter management
Workstation 1 – Laser Class 1:
- Seated/standing workstation, aluminum enclosure
- Work surface 710 × 400 mm, 25 mm hole grid
- Dimensions 1760 × 920 × 940 mm
Motorized Z-axis (400 mm)
- Extraction nozzle DN50
- Safety (PL4)
- Emergency stop
- 2-channel interlock
Safety relay
- Rear service door (with open door, laser class 4)
Operation:
230 V / 50 Hz
15–35 °C
Condition:
Hodpfx Ajyimpaoggefc
- New machine
- CE · Made in Germany
Küçük ilan
Wiesbaden
2.448 km
Gravür makinesi
SK LASER GmbHF50iW1 – 50 W Faserlaser mit Drehteller
SK LASER GmbHF50iW1 – 50 W Faserlaser mit Drehteller
Ara
Durumu: yeni, Üretim yılı: 2026, Fonksiyonellik: tamamen fonksiyonel, mil uzunluğu: 1.070 mm, iş parçası ağırlığı (maks.): 25 kg, giriş voltajı: 230 V, giriş akımı türü: Klima, lazer gücü: 50 W, soğutma tipi: hava, toplam genişlik: 1.400 mm, toplam yükseklik: 2.000 mm, toplam uzunluk: 1.500 mm, çalışma aralığı: 280 mm, yükseklik ayar tipi: elektrikli, tarama alanı uzunluğu: 280 mm, tarama alanı genişliği: 280 mm, X ekseni hareket mesafesi: 600 mm, Z ekseni hareket mesafesi: 400 mm, masa uzunluğu: 1.000 mm, masa genişliği: 1.000 mm, gereken genişlik: 1.400 mm, gereken yükseklik: 2.000 mm, lazer dalga boyu: 1.070 nm, alan gereksinimi uzunluk: 1.500 mm, ortam sıcaklığı (min.): 15 °C, ortam sıcaklığı (maks.): 35 °C, giriş frekansı: 50 Hz, ekstraksiyon meme çapı: 50 mm, çalışma genişliği: 280 mm, Donanım: kabin, Automated fiber laser system with SK-LASER workstation and rotary table for series production.
Laser class 1 · CE · Made in Germany
System:
- Complete system: Fiber laser + workstation + rotary table
- 2 processing positions with partition wall (400 mm)
- Access protection via safety light curtain
- 2-stroke operation, 180° rotation
Equipment:
- Workstation XXL: W 1,400 × H 2,000 × D 1,500 mm
- Option: High-speed scan head Superscan
Rotary table & axes:
Hodpfeyil Dvex Aggjfc
- Rotary table Ø 1,000 mm, hole matrix 25 mm
- Automatic production cycle
- 2 × Z-axis 400 mm, 1 × X-axis 600 mm
- Ball screw drive, load capacity up to 25 kg
Laser – IPG
- 50 W, 1.0 mJ
- 50–250 kHz, 100 ns
- 1060–1070 nm, M² < 1.2
- Air-cooled, < 400 W
Optics
- F-Theta f = 420 mm
- Field approx. 280 × 280 mm
- Pilot laser + distance laser
Control
- Windows 11 Pro, SSD, 23" monitor
- Ethernet / USB / RS232
- SK CONTROL: Text, logos, QR/DM, serial numbers, material parameters
Workstation:
- Suitable for seated/standing operation
- Extraction nozzle DN50
- Emergency stop, 2-channel interlock, safety relay
Operation:
- 230 V / 50 Hz
- 15–35 °C
Condition:
- New machine
- CE-compliant · Made in Germany
Küçük ilan
Viersen
2.622 km
CO2 lazeri
Cameo EpilogZING 24
Cameo EpilogZING 24
Ara
Durumu: iyi (kullanılmış), Üretim yılı: 2020, Epilog Cameo Zing 24 CO2 Lazer, UML 340 emiş ünitesi ile birlikte satılmaktadır.
Satın alma yılı: 2020 (Üretim yılı: 2019/2020)
Dairesel gravür aparatı ve kompresör dahil.
Lazer gücü: 30 Watt
Maksimum çalışma alanı: 610×305 mm
Maksimum çalışma yüksekliği: 191 mm
Lazer güvenlik sınıfı: 2
Hedpfx Ageyh Rhkjgsfc
Çözünürlük: 1.000 dpi
Frekans: 10-5.000 darbe/inç
Arayüzler: 10 Base T-LAN, USB
Ek yazılım dahil değildir.
#8480
Küçük ilan
Hessisch Lichtenau
2.407 km
Gravür Lazer CO₂ Lazer
TrotecRayjet 50
TrotecRayjet 50
Ara
Durumu: mükemmel (kullanılmış), Üretim yılı: 2019, Fonksiyonellik: tamamen fonksiyonel, Donanım: kabin, Trotec Rayjet 50 – CO₂ Laser System for Engraving & Cutting
The Trotec Rayjet 50 is a compact and reliable CO₂ laser designed for precise engraving and cutting applications. This system is ideally suited for small businesses, workshops, schools, and for professional entry-level laser processing.
Currently, 2 units available from stock.
Manufacturer: Trotec
Model: Rayjet 50
Year of manufacture: 10/2019
Technical data:
Laser source: CO₂ laser
Laser power: 30 W
Working area: 500 × 300 mm
Max. material height: 145 mm
Engraving speed: up to 2.0 m/s
Positioning accuracy: 0.01 mm
Resolution: up to 1,000 dpi
Cooling system: Air-cooled
Interface: USB / Ethernet
Software: Controlled via standard graphic programs (e.g. CorelDRAW)
Hedpjyhyu Hsfx Aggjfc
Dimensions (W × D × H): approx. 870 × 670 × 430 mm
Including extraction unit 8401 Atmos Cube
All information without guarantee.
Subject to prior sale.
Küçük ilan
Wymysłów
1.958 km
FLYMARKER XL – mobil nokta markalama cihazı
FLYMARKER XL – mobilna znakowarka punktowaFLYMARKER XL – mobilna znakowarka punktowa
FLYMARKER XL – mobilna znakowarka punktowaFLYMARKER XL – mobilna znakowarka punktowa
Ara
Durumu: mükemmel (kullanılmış), For sale: Professional mobile industrial marking machine FlyMarker XL.
Handheld device for permanent marking of metal components using the dot peen method.
Model: FlyMarker XL
Power supply: 24 V DC
Control via built-in screen and keyboard
Standalone operation without the need to connect to a computer
Manufactured in Germany
Technical condition: good, device starts up and operates properly.
Screen and keyboard are functional.
Visual condition: used, normal signs of wear and use.
Applications:
- Marking serial numbers
- Technical and production markings
Hedpfx Agsyhnu Degofc
- Marking steel, aluminum, and other metals
Set includes:
- FlyMarker XL marker
- Power supply
- Cables
- Exactly what is shown in the photos
Shipping or personal collection available.
If you have any questions, please feel free to contact me.
Küçük ilan
Korschenbroich
2.611 km
Gravür makinesi
Franz KuhlmannGravier Gel/1
Franz KuhlmannGravier Gel/1
Ara
Durumu: kullanılmış, Üretim yılı: 1969, Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: Gel/1 02.0026, İkinci el Gravier makinesi
Hfjdpfx Asyg Rv Usggjc
Marka: Franz Kuhlmann
Seri No: Gml/1 / 02.0026
Aksesuarlarıyla birlikte
Küçük ilan
Philippsburg
2.408 km
Gravür makinesi
TrotecSpeedy 100 c
TrotecSpeedy 100 c
Ara
Durumu: iyi (kullanılmış), Üretim yılı: 2022, çalışma saatleri: 1.700 h, Fonksiyonellik: tamamen fonksiyonel, lazer gücü: 45 W, - Manufacturer: Trotec
- Model: Speedy100c-8063
- Date of manufacture: August 2022
- Serial number: S1-7145
- 45 watt CO2
- 230 V
- 50 Hz
- with autofocus
- with air assist
- with 2.0" lens
- with 12.7 mm cutting table
- with performance upgrade
- with X-axis with 2 carriages
- Scales in mm
Including:
- Extraction system
- Manufacturer: Aigner/Trotec
- Model: 8401 Atmos Cube Speedy 230 V
- Serial number: 01732-18928
Hjdpfxoygl Nvj Aggjfc
- Extraction connection cable
Additionally available: Large stock of engraved parts made of wood, plastic, etc. Various shapes / designs
Shipping available upon request.
Sale only to commercial customers.
Küçük ilan
Deutschlandsberg
1.845 km
Gravür makinesi
trotecQ400 und Absaugung Atmos Duo Plus 230
trotecQ400 und Absaugung Atmos Duo Plus 230
Ara
Durumu: kullanılmış, Üretim yılı: 2022, giriş voltajı: 230 V, giriş akımı türü: Klima, toplam genişlik: 1.085 mm, toplam yükseklik: 1.050 mm, toplam uzunluk: 1.550 mm, çalışma aralığı: 1.000 mm, giriş akımı: 16 A, giriş frekansı: 50 Hz, We are offering this used Q400 Trotec laser, including the Trotec unit and an Atmos Duo Plus 230 extraction system, with a laptop, year of manufacture 2022.
Hjdpfxsygl Das Aggefc
Model: Trotec Q400
and Atmos Duo Plus 230 extraction system
Airflow: 2×320 m3/h
Pressure: 8500 Pa
Input voltage: 230 VAC
Current: 16.0 A
Power: 2.4 kW
Frequency: 50/60 Hz
Protection rating: IP40
Trotec-No.: 42335
Circuit diagram: AD 1.0
Date of manufacture: 10/2022
Serial number: 01422-19284
Laser dimensions:
Length 155 cm x Width 108.5 cm x Height 105 cm
Extraction unit dimensions:
Length 54.5 cm x Width approx. 65 cm x Height 105 cm
Engraving area: 100 x 60 cm
Collection only.
Viewing by appointment possible.
If you have any questions or need further information, please do not hesitate to send us a message or give us a call.
Küçük ilan
Mindelheim
2.225 km
Gravür makinesi
BaublysBF 50IP/NC30
BaublysBF 50IP/NC30
Ara
Durumu: kullanılmış, Üretim yılı: 2011, Lazer Yterbiyum - Fiber lazer
Teknik veriler: Lazer sınıfı 4
Lazer gücü: > 10 W
Darbe enerjisi: < 2 mJ
Hfjdeyghi Sjpfx Aggjc
Darbe süresi: > 5 ns
Dalga boyu: 1060 - 1070 nm
Küçük ilan
Wiesbaden
2.448 km
Gravür makinesi
SK LASER GmbHLasermarkiersystem Keyence K25W1
SK LASER GmbHLasermarkiersystem Keyence K25W1
Ara
Durumu: yeni gibi (sergi parçası), Üretim yılı: 2024, Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: 1724, lazer gücü: 25 W, soğutma tipi: hava, toplam genişlik: 850 mm, toplam yükseklik: 1.950 mm, toplam uzunluk: 1.000 mm, çalışma aralığı: 1.250 mm, toplam ağırlık: 210 kg, garanti süresi: 6 aylar, kapı açıklığı genişliği: 700 mm, masa uzunluğu: 700 mm, masa genişliği: 400 mm, Donanım: kabin, Used laser marking system for precise engraving of metals, plastics, and hybrid components.
Ex-demo machine, 6 months warranty, Made in Germany.
Technical Specifications – Laser
- Laser source: Keyence
- Marking area: 125 × 125 mm
- Focal distance: 189 mm (±21 mm)
- Features: Autofocus & distance measurement (MD-AD-ZT), 3D marking add-in (MD-AD-3D)
Workstation – SK LASER KOLLTRONIC
Hodpfxjyf Ap Dj Aggefc
- Laser class 1, enclosed workstation
- Combined sit/stand workstation
- Aluminum profile housing, silver cladding
- Front door with laser safety glass, bright work area illumination
- Rear service door (screwed, for oversized workpieces)
- Motorized Z-axis for focus adjustment
- Suction port DN50 for extraction unit
- Dimensions: Standard for SK LASER KOLLTRONIC Workstation 1
Control & Software
- Industrial PC
- 19" TFT color monitor, keyboard & mouse
- Operation via Keyence software, including 3D and autofocus features
Condition & Delivery
- Ex-demo machine, used
- 6 months warranty
- Operating temperature: 0–40 °C
- Delivery optional
Küçük ilan
Wiesbaden
2.448 km
Gravür makinesi
SK LASER GmbHF100iW1 Faserlaser 100 W
SK LASER GmbHF100iW1 Faserlaser 100 W
Ara
Durumu: yeni gibi (sergi parçası), Üretim yılı: 2025, Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: 1746, mil uzunluğu: 10.564 mm, lazer gücü: 100 W, soğutma tipi: hava, çalışma aralığı: 1.750 mm, toplam ağırlık: 205 kg, masa yüksekliği: 1.760 mm, masa uzunluğu: 12.000 mm, masa genişliği: 9.200 mm, Donanım: kabin, Used fiber laser system for laser marking, engraving, marking, and microstructuring on metals and plastics.
Demonstration unit, laser class 1, CE-compliant, Made in Germany.
Laser & Beam Source
- IPG ytterbium fiber laser
- Power: 100 W
- Wavelength: 1064 nm
- Pulse energy: 0.2–1.0 mJ
- Cooling: Air-cooled, no external cooling required
- Power supply: 230 V / 50 Hz
- Scanner: X-Y galvanometer with mirror mount for 1064 nm
Note: Manufacturer's laboratory values; actual values may vary depending on application.
Scanner & Control
- F-Theta lens: f = 254 mm, anti-reflection coated protective glass
- Marking field: 175 × 175 mm
- Max. scan speed: 4 m/s
Hjdpfx Agsyfvhgogofc
Industrial PC with Windows 11 Pro, SSD storage
- Controller cards for laser & scanner
- Digital & analog interfaces: RS232, Ethernet, USB
- Custom adaptations optional
- 19" TFT color monitor, keyboard & mouse
- SK CONTROL software
- Industrial software for texts, logos, QR codes, variable data
- Intuitive user interface, logo/photo import at the click of a mouse
- Job management and parameter library for reproducible quality
- Pilot laser indicates laser position as a red rectangle
Workstation 1 – SK LASER
- Enclosed laser class 1 workstation
- Combined sit/stand workstation
- Aluminum profile housing, front door with laser protection glass, bright work lighting
- Dimensions: H 1760 × W 920 × D 1200 mm
- Stainless steel worktop with 25 mm hole grid, 710 × 400 mm
- Motorized Z-axis, travel range 500 mm gross
- Rear door for extra-long workpieces (when rear door open: laser class 4)
- Suction connection DN50 for extraction system
- Redundant safety equipment: emergency stop, interlock, safety relay performance level 4
- Operating temperature: 15–35 °C
- Connection rating: 230 V / 50 Hz
Condition & Delivery
- Demonstration unit, tested
- Optional: Delivery including commissioning within Germany
Küçük ilan
Wiesbaden
2.448 km
Gravür makinesi
SK LASER GmbHC60W1 – CO₂-Laser 60 W – Refurbished
SK LASER GmbHC60W1 – CO₂-Laser 60 W – Refurbished
Ara
Durumu: yeni gibi (sergi parçası), Üretim yılı: 2025, Fonksiyonellik: tamamen fonksiyonel, mil uzunluğu: 10.600 mm, lazer gücü: 60 W, soğutma tipi: hava, toplam genişlik: 800 mm, toplam yükseklik: 1.800 mm, toplam uzunluk: 1.700 mm, çalışma aralığı: 1.200 mm, garanti süresi: 6 aylar, yükseklik ayar tipi: elektrikli, masa yüksekliği: 7.000 mm, masa uzunluğu: 4.000 mm, Donanım: kabin, Used CO₂ laser system for marking, engraving, and cutting plastics, wood, acrylic, paper, and more.
Refurbished, 6-month warranty, Made in Germany.
Technical Specifications
- Laser source: CO₂ laser, beam source refurbished in 2023
- Peak power: 60 W
- Wavelength: 9,600 nm
- Cooling: Air cooling
- Power supply: 230 V / 50 Hz
- Scanner & Optics
- X-Y galvo scanner with mirror mount
- F-theta lens: F = 200 mm, anti-reflective protective glass
- Working area: 120 × 120 mm (other lenses available on request)
Machine & Work Area
- Enclosed workstation
- Dimensions (W/H/D): 910 × 255 × 200 mm
- Extraction port available (extraction system not included)
Control & Software
- Industrial PC
Marking software:
- Texts, logos, variable data
- Import of DXF, PLT, WMF, bitmap files
- Intuitive, user-friendly interface
Scope of Delivery & Safety
Hedeyfucvepfx Aggjfc
- Complete machine, workstation
- 6-month warranty
- CE, TÜV certified
Condition & Delivery
- Refurbished, technically inspected
Offer applies ex-works plus shipping, while stocks last
Küçük ilan
Striegistal
2.178 km
Gravür makinesi
GrafGraviermaschine
GrafGraviermaschine
Ara
Durumu: kullanılmış, Bilişim sistemli gravür makinesi Sign Pro 98
Hfjdpsydlbyofx Aggec
Küçük ilan
Almanya
2.465 km
DMG Lasertec 40
DMGLasertec 40
DMGLasertec 40
Ara
Durumu: işlem için hazır (kullanılmış), Üretim yılı: 2009, toplam yükseklik: 2.370 mm, toplam ağırlık: 2.500 kg, ürün uzunluğu (maks.): 2.850 mm, Bu 4 eksenli DMG Lasertec 40 lazer kazıma makinesi 2009 yılında üretilmiştir. Ortalama 50W güce ve 1064 nm dalga boyuna sahip bir pikosaniye lazere sahiptir. Makine, X ve Y eksenleri için 15 m/dak ve Z ekseni için 12 m/dak maksimum ilerleme hızları ile X=400 mm, Y=300 mm ve Z=500 mm hareket aralığı sunar. Bu DMG Lasertec 40 lazer kazıma makinesini satın alma fırsatını değerlendirin. Daha fazla bilgi için bize ulaşın.
• Makinenin kapladığı alan (çıkarma ile çalıştırma/bakım dahil): Derinlik 3,5 m, Genişlik 3,0 m, Yükseklik 2,5 m
Hjdpoya Ah Ajfx Aggofc
• X-Y tablası ile ağırlık: yaklaşık 2.500 kg
• Makine güç tüketimi (lazer ve soğutma ünitesi ile): 16 kVA
• Sigorta: 400 V'ta 40 A
• Çalışma gerilimi: 3/N/PE/400 V/230 V 50 Hz
• İzin verilen maksimum sapma: ±%10
• Kontrol gerilimi: 24 V DC
• İzin verilen ortam sıcaklığı: +15°C ila +35°C
• İzin verilen bağıl nem: maks. 20°C'de %75
• Hareket aralığı (X-Y tablası ile): X = 400 mm (boylamasına), Y = 300 mm (enlemesine), Z = 500 mm (dikey)
• Masa boyutu: 400 x 300 mm
• Besleme tahriki: Her bir lineer eksende dijital kontrollü AC motor ve bilyalı vida
• Maksimum ilerleme hızı: X/Y: 15 m/dak; Z: 12 m/dak
• Kılavuzlar: Tüm lineer eksenlerde vidalı mil kılavuzları
• Ölçüm sistemleri: X, Y, Z dolaylı doğrusal kodlayıcı
• Makine hassasiyeti: P = 0,010 mm (VDI/DGQ 3441)
• Lazer tipi: Pikosaniye lazer
• Ortalama lazer gücü: 50 W
• Dalga boyu: 1064 nm
• Tarayıcı: Düzlemsel alan lensi; odak uzaklığı 163 mm; alan boyutu 65 x 65 mm
• Yağlama: Manuel merkezi yağlama
• Elektrik kontrol kabini: soğutma üniteli (makineye entegre)
• Kabin: Tavan dahil tamamen kapalı kabin; lazer güvenlik ekranı (isteğe bağlı olarak çoklu); optimum operatör erişimi
Küçük ilan
Oberndorf in Tirol
2.072 km
Gravür makinesi / Kesme makinesi
TrotecSP 500
TrotecSP 500
Ara
Durumu: kullanılmış, Üretim yılı: 2019, çalışma saatleri: 2.360 h, Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: S5-0910, giriş voltajı: 230 V, giriş akımı türü: Klima, lazer gücü: 120 W, soğutma tipi: hava, toplam genişlik: 1.920 mm, toplam yükseklik: 1.140 mm, toplam uzunluk: 1.240 mm, çalışma aralığı: 1.245 mm, toplam ağırlık: 500 kg, yükseklik ayar tipi: elektrikli, kapı açıklığı genişliği: 1.420 mm, giriş akımı: 16 A, lazer dalga boyu: 10.600 nm, giriş frekansı: 50 Hz, lazer tipi: CO₂ lazer, For sale: Pre-owned, very well-maintained Trotec SP500 CO-laser cutter with 120-watt output and extensive additional equipment.
Hjdeyap Rdepfx Aggofc
Technical specifications:
Model: Trotec SP500
Output: 120 W CO
Year of manufacture: September 2019
Working area: 1200 mm x 700 mm
Camera system: Integrated, for precise positioning
Condition: Fully functional, very well cared for
Included accessories:
Honeycomb table (for fine cutting tasks)
Slat table (for processing thicker materials)
Rotary engraving unit (rotary axis for cylindrical objects)
3 different focusing lenses (for various applications and material thicknesses)
Original Trotec exhaust ports
PC with Trotec software, keyboard, and monitor (plug & play)
Various tools, spare parts, and accessories included in the package
Special features:
Ideal for engraving and cutting wood, acrylic, plastics, leather, paper, textiles, and much more
High processing speed and precision
Large working area – ideally suited for advertising technology, model making, industrial applications, or creative workshops
Fully operational – no further investment required
Price & Contact:
If you are interested or have questions regarding the machine or accessories, please feel free to contact me.
Inspection and test engraving/cutting can be arranged by appointment.
Küçük ilan
Belçika
2.465 km
EPILOG Laser Fusion Edge 12 30 watt fiber lazer
EPILOGLaser Fusion Ege 12 30watt fiber
EPILOGLaser Fusion Ege 12 30watt fiber
Ara
Durumu: işlem için hazır (kullanılmış), Üretim yılı: 2022, toplam yükseklik: 455 mm, toplam ağırlık: 63 kg, Bu EPILOG Laser Fusion Edge 12 30watt fiber 2022 yılında üretilmiştir. 610x305mm çalışma yüzeyine ve 178mm maksimum Z derinliğine sahiptir. Makine 30 watt fiber kaynakla çalışır ve 5G hızlanma ile 120 IPS'ye (3,05 m/s) kadar hızlara ulaşır. 63 kg ağırlığındaki makine, fiber lazer kesimde hassasiyet için tasarlanmıştır. Yüksek kaliteli kesim yetenekleri elde etmek istiyorsanız, satışa sunduğumuz EPILOG Laser Fusion Edge 12 makinesini düşünün ve daha fazla bilgi için bizimle iletişime geçin.
Ek ekipman
• Kaynak: 30 watt Fiber
• Hız: 5G hızlandırma ile 120 IPS (3,05 m/s)
Makine Faydaları
Teknik Makine Faydalari
• Maksimum z derinliği: 178 mm
• Çalışma yüzeyi: 610x305mm
Hodpfxox U Tmgj Aggjfc
Ekstra bilgi
Makine hala güç altında
Dimensions
Machine Depth 1003 mm
Küçük ilan
Contamine-sur-Arve
2.485 km
Lazer
TECHNIFORTF410
TECHNIFORTF410
Ara
Durumu: kullanılmış, Lazer TECHNIFOR TF410
Hfodpfx Agjx Tvhkogjc
Küçük ilan
Glattbach
2.392 km
Lazer kazıma makinesi / İşaretleme lazeri
Siro-LasertecSLC 20W
Siro-LasertecSLC 20W
Ara
Durumu: kullanılmış, Üretim yılı: 2019, Fonksiyonellik: tamamen fonksiyonel, giriş voltajı: 230 V, giriş akımı türü: Klima, lazer gücü: 20 W, giriş frekansı: 50 Hz, We are offering a used Siro-Lasertec SLC 20W laser engraving and marking machine from commercial use, year of manufacture 2019.
Hfedpfx Agex Tqc Negec
The machine is fully functional, was not used in continuous operation, and has low operating hours.
There is a slight dent on the housing, which was already present upon delivery and is purely cosmetic (no impact on functionality).
Technical data (according to nameplate / manufacturer's information):
Model: SLC 20W
Manufacturer: Siro-Lasertec GmbH
Date of manufacture: 04/2019
Laser power: 20 W
Max. Power consumption: 600 W
Mains voltage: 100–240 V AC
Frequency: 50–60 Hz
Scope of delivery:
– Siro-Lasertec SLC 20W laser engraving machine
– ECO BF5 extraction and filtration unit
– Motorized rotary axis / rotation axis with chuck
– Laptop with pre-installed laser software
– 9 additional filter inserts / filter cartridges
– Connection and accessory parts
The machine is ready for immediate use.
A demonstration upon collection is possible and welcomed.
Price: €4,201.68 net plus 19% VAT (€5,000.00 gross)
Commercial sale with invoice and VAT shown separately.
Collection preferred, no shipping.
Sale under exclusion of liability for material defects, as far as legally permissible.
Küçük ilan
Almanya
2.357 km
Lazer İşaretleme Makinesi
BaublysControl Laser UL 65QR/NC 100 50 50 SOMA
BaublysControl Laser UL 65QR/NC 100 50 50 SOMA
Ara
Durumu: işlem için hazır (kullanılmış), Üretim yılı: 2008, Bu 3 eksenli Baublys Control Laser UL 65QR/NC 100 50 50 SOMA, 2008 yılında üretilmiştir. Cihaz, 50 kHz'e kadar frekanslara ulaşabilen Q-anahtarlamalı katı hal Nd:YAG lazerine sahiptir. Makinede yaklaşık 75 cm çapında döner transfer tablası bulunmakta olup, 2,4 x 2,6 metre ölçülerinde bir kabin içinde yer almaktadır. Yüksek kaliteli lazer markalama kapasitesine sahip olmak istiyorsanız, elimizde bulunan Baublys Control Laser UL 65QR/NC 100 50 50 SOMA makinesini değerlendirebilirsiniz. Daha fazla bilgi için bizimle iletişime geçin.
Hfodpfx Agox Sz Efsgsc
Uygulama Tipleri
Diğer Sac Metal Makineleri
