neuform-Türenwerk Hans Glock GmbH & Co. KG

Durumu: kullanılmış, Üretim yılı: 2013, Makine yapısı: Akış tipişi / X ekseninde işleme boyutu: 1000 mm / Y ekseninde işleme boyutu: sınırsız mm / İşleme kalınlığı (Z boyutu): 60 mm Ana iş mil sayısı: 1 adet Ana iş mili gücü: 3,3 kW Takım değiştirici: Yok Arka duvar kanalı ünitesi: Y ekseninde sabit Godpex Urniofx Aduott Dikey delme milleri - X ekseninde: 5 adet Dikey delme milleri - Y ekseninde: 5 adet Dikey delme mili devir hızı: 4000 dev/dak X ekseninde yatay delme mili: 2 çift milli Y ekseninde yatay delme mili: 1 çift milli Yatay delme mili devir hızı: 4000 dev/dak Monitör boyutu: 17" Kontrol tipi: PC kontrolü İşletim sistemi: Windows XP Q-klavye: Evet Mouse: Evet Program sistemi: Masterwork DXF Arayüz: Evet Çevrimiçi bağlantı imkanı: Evet CD ROM sürücüsü: Evet Tabla tipi: Yuvarlanan sabit tabla Ağırlık yaklaşık: 1300 kg Boyutlar: 2200 x 2470 x 1590 mm Depo yeri: Müşteri

Durumu: kullanılmış, Üretim yılı: 2006, X-Y-Z çalışma alanı: 5300 x 1700 x 180 mm X-Y-Z çalışma uzunluğu: 6040 x 1810 x 280 mm 30 + 8 milli delme kafası Hız: 6000 rpm Güç: 2,2 kW Otomatik merkezi yağlama 10 destekli TV çalışma masası (L = 1500 mm) 4 çalışma alanı 2 çapraz lazer Vakum pompası 250 m³/h PC kontrol sistemi ISO 30 dikey freze ünitesi 7,5 kW RAPID 14 takım değiştirici ve vektör ekseni Ek delme ünitesi (E ekseni) XILOG yazılımı için Dongle Gtodox Twd Hjpfx Aduot Depolama yeri: Nattheim

Durumu: kullanılmış, Üretim yılı: 2007, Çalışma alanı: 2780 x 1140 mm (dikey frezeleme) 2500 x 950 mm (yatay delme) Hareket X-Y: 2980 x 1271 mm Hareket uzunluğu Z ekseni: 200 mm Geçiş yüksekliği: 180 mm Taban gövdesinin yapısı kalın duvarlı çelikten yapılmış monolitik bir yapıdır. Makine yatağının tamamı kaynaklı üçgen plakalarla sertleştirilmiş olup, bu nedenle son derece sağlamdır. Yük taşıyan parçalarda kullanılan geniş tabanlı üçgen form, uzun süreli hassasiyet ve sağlamlığın sırrıdır. Makinenin yerleşimi, minimum alan gereksinimine rağmen kullanıcıya optimum iş akışı sağlar. Bu şekilde inşa edilen taban gövdesi, işleme ünitesine dengeli ve güvenli bir taban sağlarken, yük dağılımını da oldukça iyi hale getirir. Mobil agrega taşıyıcısı, masif monobloktan inşa edilmiştir. Prizmatik taşlanmış kılavuzlar üzerinde, geri dönen bilyalı kızaklar vasıtasıyla X yönünde konumlandırılır. Bu mobil ünite taşıyıcısında, çalışma ünitesi prizmatik, zemin kılavuzları ve devridaim bilyalı kızak üzerine monte edilmiştir. Ünite ve aksesuarların tanımı (temel) Delme ünitesi: 10 + 4 milli delme kafası · X'te ayrı ayrı erişilebilen 6 dikey mil · Y'de ayrı ayrı erişilebilen 4 dikey mil · X'te (1 + 1) 2 yatay mil · Y'de (1 + 1) 2 yatay mil · Hız: 4.000 dev/dak · Güç: 2,2 kW · Izgara: 32 mm · Matkap mandreni: 11 mm bağlantı parçalı M 10 · Çıkarma memesi: D = 160 mm Dikey freze ünitesi (konum 2) · Takım mandreni HSK 63F · İnverter üzerinden sürekli ayarlanabilir hız 1.500 - 24.000 dev/dak · Motor gücü 12.000 dev/dak'dan (S1) itibaren 4,4 kW (6 HP) · Sağ / sol dönüş · Seramik yataklar · Teslimat kapsamı: Pens mandreni olmadan 4 takım mandreni (sağ) · Takım değiştirici · Tam takım magazini 7 yollu (TR7) yan montajlı · Kırılmayı önlemek için kapsülleme · HSK 63F takım tutucu için sıralı olarak düzenlenmiş 7 takım pozisyonu · Maksimum takım çapı D = 120 mm · Tutucu başına maksimum ağırlık 4,5 kg · Tüm takımların maksimum takım ağırlığı 20 kg (TR7) · Açısal dişliler yerleştirilebilir Yatay frezeleme ünitesi (konum 1) Frezeleme ve kanal açma için iki zıt çıkışa sahip yatay ünite. · Hız 9.000 - 18.000 dev/dak sürekli inverter üzerinden ayarlanabilir · 3-20 mm pens için 1 çıkış (ER 32) · 3-12 mm testere/pens için 1 çıkış (ER20) (Testere D = 120 mm / delik 50 mm için) · Motor gücü 3 kW (4 BG) · Maks. Takım çapı ön frezeleme: 20 mm · Maks. Ön frezeleme takım uzunluğu: 110 mm · Maks. Takım çapı arka frezeleme: 12 mm · Maks. Arka frezeleme takım uzunluğu: 80 mm · Maks. testere bıçağı çapı: 100 mm · Delme testere bıçağı (ER 32): 50 mm · Mandrel testere bıçağı çapı (ER 20): 12 mm Çalışma masası Çalışma masası, operatöre maksimum hareket özgürlüğü garanti edecek şekilde tasarlanmıştır. Vakumlu hızlı sıkıştırma sistemi, iş parçalarının hassas konumlandırılması ve optimum tutuşu ile maksimum esneklik sağlar. · X'te manuel olarak sürekli ayarlanabilen 4 adet 900 mm destek · Y'de sürekli ayarlanabilen D = 110 mm yuvarlak 8 adet vakumlu vantuz (destek başına 2 adet) · X'te 2 adet durdurucu (1 x sol / 1 x sağ) · Destek başına Y'de 1 adet durdurucu (toplam 6 adet) · Geri çekilebilir referans durdurucuları CNC ile kontrol edilir. · Teslimat kapsamı: 4 adet. Vantuzlar için tak-çıkar adaptörler · Standart sarkaç işleme (2 çalışma alanı) Eksen hareketi X, Y ve Z'deki tahrik sistemi en yüksek hassasiyet sınıfına sahip taşlanmış bilyalı vidalarla gerçekleştirilir. X ekseninin bilyalı tahrik vidası tam merkezde yer almaktadır Gsdpex Twdyefx Adujtt

Durumu: kullanılmış, Üretim yılı: 2011, Working area: 2,550 x 1,067 mm Travel X-Y: 2,980 x 1,450 mm Z-axis travel: 150 mm Clearance height: 120 mm Drilling unit F14: Drilling head with 8 + 6 spindles • 5 individually selectable vertical spindles in X • 3 individually selectable vertical spindles in Y • 4 horizontal spindles in X (2+2) • 2 horizontal spindles in Y (1+1) • Speed: 4,000 rpm (6,000 rpm optionally available) • Power: 2.2 kW • Grid spacing: 32 mm • Drill holder: M 10 with 11 mm fitting • Pneumatic advance stroke: 60 mm Grooving saw unit in X • Integrated in the drilling head • Grooving saw blade up to a maximum diameter of 120 mm Main milling unit: • Tool holder: HSK 63F • Speed: 1,500 – 24,000 rpm, infinitely variable via inverter • Motor power: 6.6 kW (9 HP) from 12,000 rpm (S1) • Motor power: 7.5 kW (10 HP) from 12,000 rpm (S6) Gsdsx Twc Njpfx Aduett • Clockwise / counterclockwise rotation • Ceramic bearings • Preparation for use of angle gearboxes Tool changer TR10 Automatic lateral tool changer for 10 tools • Number of tool positions: 10 • Max. tool diameter: 120 mm • Max. weight per tool: 4.5 kg • Max. total tool weight: 28 kg A central extraction port combines all processing units into a single connection (D=200 mm). As a result, the required extraction capacity is reduced to approx. 3,200 m³/h. Worktable TVF The worktable is designed to provide the operator with maximum freedom of movement. The quick vacuum clamping system offers maximum flexibility for precise positioning and optimal hold of the workpieces. • 4 TVF supports, L=1,100 mm, infinitely adjustable in X • 12 TVF vacuum cups, 120 x 120 mm, infinitely adjustable in Y • 2 stops in X (1 left / 1 right) • 1 stop in Y per support (total 4 pieces) • The retractable reference stops are CNC-controlled Automatic central lubrication The correct amount of grease is distributed via an electronic CNC control unit (X, Y, Z axes) Vacuum system (base machine): • Vacuum pump: 90 m³/h • Power: 2.2 kW • Max. negative pressure (at pump): 0.9 bar PROGRAMMING SYSTEM XILOG PLUS Software features: - Import of DXF files - Import of ASCII files - User interface in the operator’s native language Safety features with bumpers Machine technical data: • Total connected load max.: 18 kW • Recommended fuse: 64 A • Supply: 400 V, 50–60 Hz • Compressed air: 6–7 bar • System pressure (recommended): 8 bar • Compressed air consumption: 200 Nl/min • Central extraction port diameter: 200 mm • Extraction speed: 30 m/s • Air consumption (central extraction): 3,200 m³/h • Negative pressure: 3,000 Pascal • Weight: approx. 2,500 kg Remote control of machine functions 6 TVF supports, L=1,100 mm, and 18 vacuum cups, 120 x 120 mm Cross lasers for positioning the vacuum cups Two cross lasers mounted on the unit carrier facilitate easy positioning of the vacuum cups. Location: Nattheim

Durumu: kullanılmış, Üretim yılı: 2023, Exhibition machine Garbsen CNC-CONTROLLED MACHINING CENTER morbidelli m100 Drilling and milling made for you! This numerically controlled machining center is equipped with a comprehensive range of tools for milling and drilling, enabling it to meet any woodworking requirement. Exceptionally high performance – featuring drilling spindles with 8,000 rpm and state-of-the-art technology, it boasts the most robust spindle available on the market, with over 1,000 maintenance-free cycles. Fully equipped – the suction pads can be individually configured on the TV FLEX worktable, allowing the machine to be tailored to specific requirements. Intuitive and straightforward programming thanks to integrated Cad-Cam MAESTRO CNC software. Easy to operate, the lowered machine frame ensures the worktable is always accessible. The control cabinet and vacuum pump are built into the machine base, and in the PRO SPACE version, no additional safety barriers are required. Supporting Structure Gtedpfxjx Twcie Aduot The supporting structure consists of an especially sturdy, monolithic steel base, heavily ribbed and highly robust. The particularly broad foundation has been specifically designed to provide the machine with stability and to ensure constant precision under all working conditions. Anchoring to the floor is not necessary. The base provides a large, solid platform for the moving gantry: the machining unit is equipped with a balanced, stable, and resilient support, capable of withstanding even the heaviest loads, thereby ensuring higher quality and greater accuracy. The moving gantry is constructed from a single, solid piece anchored to the base, and runs on high-quality prismatic guides with ball-bearing carriages. The machining unit is attached to this and also moves along the Y and Z axes on prismatic guides with ball-bearing carriages. Movement of the lower moving unit (X-axis) and the machining unit along the traverse (Y-axis) is achieved via helical rack and pinion drive; this provides greater tooth-to-tooth engagement for increased acceleration and higher speed along the X and Y axes. The purpose-designed helical gearing ensures reduced wear and quieter operation. The vertical Z-axis is driven by a recirculating ball screw, ensuring perfect balance under dynamic loads and effective resistance to strong acceleration and deceleration. The main milling unit is directly coupled to the Z-axis carriage, delivering extremely fine machining quality by virtually eliminating vibrations. All X-Y-Z axis movement is powered by brushless motors driven by static inverters, ensuring: - Reduced machining times thanks to improved acceleration - Higher positioning precision due to the high-resolution encoder - Elimination of setup routines at machine start-up thanks to absolute encoders - No general maintenance required, as the brushless system requires no brushes Axis movements and general control of the machining elements are managed by...

Durumu: kullanılmış, Üretim yılı: 2006, · Working area: 2,650 x 1,240 mm · Travel range X-Y: 2,995 x 1,385 mm · Z-axis travel length: 200 mm · Clearance height: 180 mm The base structure is a monolithic construction made of thick-walled steel. It is reinforced over the entire machine bed with welded-in triangular plates, resulting in extreme stability. The triangular shape with a broad base used for the load-bearing components is the secret to lasting precision and stability. The design of the machine allows the user to optimize workflow while minimizing space requirements. This base provides the processing unit with a balanced and secure foundation with particularly good load distribution. The mobile unit carrier is built as a solid monoblock. It is positioned in the X-direction on ground prismatic guides via ball-bearing carriages. On this moving unit carrier, the working unit is also mounted on ground prismatic guides with ball-bearing carriages. Description of the units and standard accessories --- Drilling unit: Drill head with 12 + 6 spindles: · 7 individually selectable vertical spindles in X · 5 individually selectable vertical spindles in Y · 4 horizontal spindles in X (2+2) · 2 horizontal spindles in Y (1+1) · Speed: 4,000 rpm · Power: 2.2 kW · Pitch: 32 mm · Drill chuck: M 10 with 11 mm locating surface Grooving saw unit in X: · Integrated in the drill head Gtjdpfxox Twcco Adust · Grooving saw blade, diameter up to max. 120 mm Main milling unit (Position 2): · Tool holder: HSK 63F · Speed: 1,500 - 24,000 rpm, infinitely variable via inverter · Motor power: 4.4 kW (6 HP) from 12,000 rpm (S1) · Motor power: 6.6 kW (9 HP) from 12,000 rpm (S6) · Clockwise / counterclockwise rotation · Ceramic bearings · Scope of delivery: 4 pcs. tool holders (right), without collets Tool changer R8L Automatic tool changer for 8 tools, moving with the rear unit carrier for quick tool access. · Number of tool slots: 8 · Max. tool diameter: 120 mm · Max. tool weight: 4.5 kg · Max. total weight of all tools: 22 kg · Holder for 1 angle gearbox · Moves in X Horizontal milling unit (Position 1): Horizontal unit with two opposing exits for milling and grooving. · Speed: 9,000 - 18,000 rpm, infinitely variable via inverter · 1 output for collet 3-20 mm (ER 32) · 1 output for saw/collet 3-12 mm (ER 20) (for saw D=120 mm / bore 50 mm) · Motor power: 3 kW (4 HP) · Max. tool diameter front milling: 20 mm · Max. tool length front milling: 110 mm · Max. tool diameter rear milling: 12 mm · Max. tool length rear milling: 80 mm · Max. saw blade diameter: 100 mm · Bore saw blade (ER 32): 50 mm · Arbor diameter saw blade (ER 20): 12 mm Work table The work table is designed to guarantee the operator maximum freedom of movement. The quick-release vacuum clamping system offers maximum flexibility for precise positioning and optimal holding of workpieces. · 6 supports, 1,000 mm, infinitely pneumatically adjustable in X · 12 round vacuum cups, D = 110 mm, infinitely adjustable in Y (2 pcs. per support) · 2 stops in X (1 left / 1 right) · 1 stop in Y per support (total 6 pcs.) · The retractable reference stops are CNC controlled · Pendulum processing standard (2 working fields) --- Other clamping systems are optional --- Axis movement The drive system in X, Y, and Z uses ground ball screws of the highest precision class. The ball screw nuts...

Durumu: işlem için hazır (kullanılmış), Üretim yılı: 2016, Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: AB/226310, toplam uzunluk: 4.300 mm, toplam genişlik: 1.880 mm, toplam yükseklik: 2.350 mm, boş ağırlık: 1.310 kg, Makine Detayları Boyutlar & Ağırlık Boyutlar (U x G x Y): 4.300 x 1.880 x 2.350 mm Gtsdpfox Tpv Iex Adujt Boş Ağırlık: 1.310 kg

Durumu: mükemmel (kullanılmış), Üretim yılı: 2019, Fonksiyonellik: tamamen fonksiyonel, SCM Morbidelli N100 CELL Çalışma alanı X: 4.286 mm Çalışma alanı Y: 2.185 mm Çalışma alanı Z: 150 mm Dikey delik açma üniteleri: 12 Yatay delik açma ünitesi X: 4 Yatay delik açma ünitesi Y: 2 X ekseninde 1 oluk açma testeresi Takım değiştirici: 20 Barkod okuyucu 3 vakum pompası SCM eye-M kontrol ünitesi Gtedpfsx Tgubjx Adujt Durumu iyi

Durumu: kullanılmış, Complete production line for the manufacturing of slatted frames. From wood processing to final assembly/packaging. Includes all components such as milling machines, saws, profiling equipment, forklifts, compressors, etc. The larger machines/plants are from approx. year 2000. Consisting of: Solid Wood Side Rail Production - 2 x Multi-blade saws RAIMANN KR 450 + KS 310 - Optimising saw GRECON ILLERTISSEN OPTICUT 704R - Four-side planer WEINIG HYDROMAT 23 - Stacking unit Foiling / Surface Refinement of Longitudinal Rails: - 2 x Profile wrapping machines FRIZ OPTIMA PU25-PAP - Foil slitting machine FRIZ FSM 1500 CNC Drilling and Sawing Lines - KOCH drilling and sawing line with turning and stacking unit - ISE CNC drilling and sawing line with stacking unit - 2 x ISE CNC woodworking centres / drilling lines - ISE CNC slot slat milling machine - 2 x Manual slat drilling machines Individual Machines - GANNOmat CNC drilling and dowel insertion machine - Pnahans spindle moulder - 2 x EiMa double mitre saws - SCM panel saw - Barth frame press - 2 x FLOTT column drilling machines - SAMCO combination saw and spindle moulder - 2 x multi-spindle drilling machines - 2 x belt sanders - Spray booth - Various small machines Assembly - Automatic assembly machine for standard slatted frames Gtodpfx Aex S Scbodust - Press-in machine/line for end caps - 14 x pneumatic assembly tables Logistics – Plant Equipment - 3 x LINDE forklifts E16 / E20 - 7 x LINDE electric pallet trucks / high-lift trucks - WEYCOR wheel loader 95E SUPER - Atlas Copco compressor station - WEIMA single-shaft shredder - Kärcher ride-on sweeper - HONDA snow blower - Extraction system for outdoor yard - Lot of mesh box pallets + euro pallets - Various racking systems Packaging - Shrink tunnel system - Stationary pallet wrapper - Mobile pallet wrapper Goods - Remaining stock of wood / slat strips - Remaining stock of end caps / plastic parts - Remaining stock of various assembly materials Many further PHOTOS and detailed DATA available on request.

Durumu: mükemmel (kullanılmış), Üretim yılı: 2009, Weeke BHX 500 – Operator Side Right Weeke Machining Centre equipped with one machining head each on the top and bottom Infeed table with automatic workpiece feeding and positioning WORKPIECE DIMENSIONS Min. workpiece length: 200 mm Max. workpiece length: 2,500 mm Min. workpiece width: 70 mm Max. workpiece width: 1,000 mm Min. workpiece thickness: 8 mm (2*4 mm) Max. workpiece thickness: 80 mm Max. workpiece stacking: 2 pieces Machine Configuration: 2V21 HIGH SPEED 7500 Vertical drilling unit installed on both the upper and lower machining supports, each with 21 drilling spindles (individually controllable with variable speed). 2H4X/1Y Horizontal drilling unit mounted on both the upper and lower machining supports, each with 10 program-controlled, individually selectable drilling spindles. 8 drilling spindles each in the X-direction 2 drilling spindles each in the Y-direction N2 X-Y 90° Groove saw unit mounted on the upper and lower machining supports for operations in X-Y direction, swivelling 90°. Max. cutting depth: 30 mm ADDITIONAL INFORMATION ON GROOVE SAW BLADE Saw blade width: up to 8.4 mm. The material removal cross-section must not exceed 70 mm². F2-ETP-6 KW Milling unit mounted on both the upper and lower machining supports, suitable for shank tools. Manual tool change. Tool insertion: manual, ETP 25 hydro quick-clamping system. Rotation: clockwise/counterclockwise. Speed: 6,000 – 18,000 rpm, infinitely programmable. Processing capacity up to 3,000 mm. Gtjdpfx Adox S Hzljust Infeed table with automatic workpiece feeding and positioning Workpiece removal area with cross belt conveyor and lifting arms – Workpiece length measurement integrated in the machine – Movable operator terminal – Barcode software incl. scanner

Durumu: kullanılmış, Üretim yılı: 2010, makine/araç numarası: 9532, toplam uzunluk: 30.000 mm, toplam genişlik: 3.000 mm, toplam yükseklik: 3.000 mm, Listing Description – Hundegger SC-3 (Year of Manufacture: 2010) Hundegger SC-3 – CNC Throughfeed Processing Center For sale is a Hundegger SC-3 from 2010, a proven and high-performance CNC throughfeed processing center designed for modern timber construction. This machine is ideal for carpentry shops, timber frame manufacturers, and industrial wood processing. It stands out thanks to its high precision, reliability, and productivity. Highlights: - CNC-controlled throughfeed processing center - High degree of automation and efficient material flow - Precise cutting for timber components - Versatile machining options – with suitable accessory units or retrofitting, additional operations such as drilling, milling, slotting, marking, and labelling are possible in addition to cutting Gtjdpox Rkrfjfx Aduot - Robust, durable construction by Hundegger Technical specifications: - Manufacturer: Hundegger - Model: SC-3 - Year: 2010 - Condition: used, in operation - Location: Estonia - Price: on request/as per listing The Hundegger SC-3 is an economical solution to increase throughput, accuracy, and process reliability in wood processing. 📩 Further information, technical details, or an inspection available on request.

Durumu: kullanılmış, Üretim yılı: 2012, available upon agreement Machine design: Fixed gantry machine Godpfx Ajx Rdmceduott Working area in X-direction: 3548 mm Working area in Y-direction: 1350 mm Working thickness (Z-dimension): 160 mm Number of main spindles: 1 unit Main spindle power: 11 kW Main spindle speed: 1,200–20,000 rpm Clamping system: HSK-63 F Spindle cooling: Liquid cooling Number of axes: 5 Tool changer: Disc-type changer Tool positions: 12 units Rear wall groove unit: Yes Vertical drilling spindles – X-direction: 10 units Vertical drilling spindles – Y-direction: 8 units Vertical spindle speed: 6,000 rpm Horizontal drilling spindles in X-direction: 2+2 units Horizontal drilling spindles in Y-direction: 2+2 units Horizontal spindle speed: 6,000 rpm Control system: PC control Operating system: Windows Typewriter keyboard: Yes Mouse: Yes Programming system: Xilog DXF interface: Yes CD-ROM drive: Yes Table design: Console table, hose-free Stop system: Stop cylinder for veneer Support arms: 6 units Vacuum cups: 18 units Lifting rails: 4 units Number of vacuum pumps: 1 unit Vacuum pump capacity: 250 m³/h Alternating field allocation: Yes Safety guard left: Yes Safety guard right: Yes Safety guard rear: Yes Extraction hood: axis-controlled Setup aid: Point laser setup aid Safety device: Bumper Central lubrication: Automatic Tools: Available at extra cost Weight approx.: 6,500 kg Extraction diameter: 200 mm Further details and photos available on request Stock location:

Durumu: mükemmel (kullanılmış), Üretim yılı: 2023, Fonksiyonellik: tamamen fonksiyonel, SCM Morbidelli X 400-1531 Çalışma alanı X: 3100 mm Çalışma alanı Y: 1500 mm Çalışma alanı Z: 180 mm Invertörlü delme kafası 0-90 derece otomatik döner grup (disk freze için) 5 eksenli grup, 13,5 kW 5 eksenli elektro mil için CNC kontrollü emiş başlığı FAST14 (15xx) model 14 istasyonlu otomatik takım değiştirici Maestro CNC programlama yazılımı Etiketleme makinesi Vakum pompaları Gsdpfsx Ivp Dox Adujtt

Durumu: kullanılmış, Üretim yılı: 2024, 1 unit CNC wood milling machine HOLZFRAESE AXOLOX 4021 Working area X 4000mm, Y 2100mm, Z 100mm, rated voltage 230V, spindle speed continuously variable 1000-24000 rpm, PC with Windows 10, control software Beamicon2, vacuum table consisting of six individually adjustable segments, vacuum pump with a capacity of 160 m³/h, including piping, according to photos and inspection, self-dismantling required Color: grey Year of manufacture: 2024 Godox Ifhcepfx Adustt Machine serial number: SN: 0232024 Weight approx. in kg: 2500 Condition: used Payment method: advance payment by bank transfer Storage location: joinery/workshop, hall 2 Shipping: Collection only – No shipping offered for this item!

Durumu: kullanılmış, TF 100/20 - Year of manufacture: 2017 - Front and rear tables - Workpiece height: 60mm, maximum workpiece length: unlimited - Maximum workpiece width: 1000mm, minimum width: 80mm - Feed speed: 0-25m/min - Air tables in the working area Gsdpfx Ajx Ha Rpoduett - 6-position changer - Ball screw and linear guides - DXF file import - Milling unit - Speed: 1000 to 18000 rpm - 3.3kW - Drilling unit with 16 drills for 5-sided machining - Grooving saw unit - Weight: 1380kg - 400 Volt - 15.8 kW

Durumu: kullanılmış, Fonksiyonellik: tamamen fonksiyonel, Satılık Alberti Format 90 CNC işleme merkezi! Teknik özellikler Çalışma alanı: 3000 x 1250 mm Maksimum panel kalınlığı: 50 mm Maksimum programlanabilir hız: X ekseni 40 m/dk, Y ekseni 40 m/dk, Z ekseni 9 m/dk Mil motor gücü: 2 adet, 2 HP - 3000 devir/dk 32 mm merkez mesafelerinde 27 bağımsız dik milli 4 adet morse konik freze bağlama imkânı Freze dönüş hızı ve güç çıkışı: 18000 devir/dk 1 adet daire testere bağlama imkânı Testere dönüş hızı ve güç çıkışı: 12000 devir/dk Gsdpfx Adox Ey Sdeustt Çalışma basıncı: 6 bar Toplam ağırlık: 4450 kg Boyutlar (elektrik panosu dahil): 5800 x 3450 x 1950 mm

Durumu: kullanılmış, Üretim yılı: 2006, BACCI DOUBLE is a CNC machining center with two machining heads and 10 interpolated axes, numerically controlled and equipped with automatic material feed. The DOUBLE is designed for woodworking joints such as mortise and tenon, finger jointing, drilling, mortising, and milling—both at the ends of elements as well as between the ends. • Serial number AB 059 • 380 V, 50 Hz, 50 kW • OSAI control system • Travel paths: o X-axis 2400 mm o Y-axis 650 mm o Z-axis 1000 mm o A-axis rotary 360° o B-axis 260° • Machining dimensions: L min. 150 mm, L max. 2400 mm, W max. 250 mm, H max. 100 mm • X-, Y-, and Z-axis feed rate: 50 m/min • Maximum tool diameter: 200 mm • 4 tool holders per machining side • 2 pneumatic clamps • Spindle holder: ER 32 Gtedpfx Aex Dib Nsdust • Spindle (right side): speed 12,000–24,000 rpm, power 7.4 kW • Spindle (left side): speed 12,000–24,000 rpm, power 7.4 kW

Durumu: kullanılmış, makine/araç numarası: 008370, Çalışma alanı X ekseni: 5055 mm Çalışma alanı Y ekseni: 1930 mm Çalışma yüzeyi: Vakumlu konsol desteklerle Ana mil gücü: 19 kW Kontrollü eksen sayısı: 5 eksen Maksimum kenar yüksekliği: 60 mm Matkap mili sayısı: 29 Gtjdpsx A Tk Ssfx Adujt Takım yeri sayısı: 31

Durumu: kullanılmış, makine/araç numarası: 008321, Çalışma alanı X ekseni: 4200 mm Çalışma alanı Y ekseni: 1350 mm Çalışma yüzeyi: Vakum konsollu Ana mil gücü: 12 kW Gsdsx A Tdlepfx Aduott Kontrol edilen eksen sayısı: 4 eksen Maksimum kenar yüksekliği: 60 mm Matkap mili sayısı: 18 Takım yuvası sayısı: 22

Durumu: kullanılmış, makine/araç numarası: 008198, Çalışma alanı X ekseni: 4200 mm Gedpfox A Hbkox Adujtt Çalışma alanı Y ekseni: 1400 mm Çalışma yüzeyi: Vakum konsollu Ana mil gücü: 18,5 kW Kontrol edilen eksen sayısı: 4 eksen Maksimum kenar yüksekliği: 60 mm Delme mili sayısı: 35 Takım yuvası sayısı: 26

Durumu: kullanılmış, Üretim yılı: 2020, toplam uzunluk: 2.000 mm, toplam genişlik: 2.500 mm, toplam yükseklik: 2.100 mm, Price: On request - Machine available from: 2025-12-15 - Year of manufacture: 2020 - Documentation available: Yes - Type of documentation: Operating system, technical data, user manual, electrical schematics - CE marking present: Yes - CE certificate available: No - Serial number: 1000040377 - Main motor power [kW]: 10 - Number of milling spindles [pcs]: 1 - Horizontal drilling machine: Yes - Horizontal drilling spindles [pcs]: 10 - Vertical drilling machine: Yes - Saw unit available: Yes - Voltage [V]: 400 - Power consumption [A]: 18 - Fuse [A]: 32 - Power [kW]: 10.0 - Transport dimensions: 2000mm x 2500mm x 2100mm (L x W x H) - Transport packages [pcs]: 2 Financial information VAT: The indicated price is to be understood plus VAT VAT/margin scheme: VAT deductible for businesses Delivery and trade-in possible at any time for anything from the industrial sector Glenn Smeets Gsdjx Ad R Njpfx Adujtt

Durumu: işlem için hazır (kullanılmış), Üretim yılı: 2018, Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: 25167180701, toplam genişlik: 1.000 mm, toplam yükseklik: 60 mm, Y ekseni ilerleme hızı: 50 m/dak, Z ekseni ilerleme hızı: 20 m/dak, iş parçası yüksekliği (maks.): 60 mm, dönme hızı (dk.): 4.000 dev/dak, güç: 4,5 kW (6,12 bg), hava ihtiyacı: 2.000 m³/saat, CNC machining center Manufacturer: Masterwood Model: Project TF 100 2.0 Technical data: Axes: X-axis: Max. workpiece length: unlimited Gtedsxz Hgdepfx Adujt Min. workpiece length: 250 mm Travel speed: 0-25 m/min Y-axis: Max. workpiece width: 1,000 mm for all units Min. workpiece width: 80 mm Travel speed: 0-50 m/min Z-axis: Max. workpiece thickness: 60 mm Min. workpiece thickness: 10 mm Travel speed: 0-20 m/min Minimum and maximum workpiece dimensions are dependent on weight and the length-to-width ratio. Air tables in the working area - Roller conveyor at infeed and outfeed - Panel measuring sensor - Ball screw and linear guides - Rack and pinion drive - Centralized lubrication - Import of DXF files Milling unit Including Masterwork software extension Spindle speed: 1,000 to 18,000 rpm Motor (frequency-controlled): 3.3 kW Including integrated extraction control (Only the drilling head is extracted during drilling, only the milling unit during milling) Drilling head with 16 spindles for 5-sided machining Grooving saw unit Milling unit with 6-position tool changer Incl. grooving saw blade, 2 diamond cutters, 1 finish cutter (WPL) Prepared for CLAMEX and door processing packages 2 foldable roller conveyors Milling unit for Clamex connectors Milling unit designed for door machining, for machines with tool changer; complete with special tool holder in the tool changer, right-angle gearbox for mounting a mortising cutter, macro for mortise lock housing. Automatic centralized lubrication, program-controlled. Camera for monitoring

Durumu: mükemmel (kullanılmış), CNC drilling center, Biesse Skipper V31 drill Working area: X-axis length: 200 - 3000 mm Y-axis width: 70 - 900 mm Z-axis thickness: 10 - 70 mm Milling spindle power: 4.5 kW 10 vertical spindles 6 horizontal drills (4 along the X axis, 2 along the Y axis) Grooving saw along X axis The machine is in very good condition, the drilling unit and axes operate quietly. CE mark Year: 2020, 2210 operating hours Weight: 1300 kg, machine dimensions ready for operation: 380 cm x 200 cm h-260 cm Connection power: 10 kW Gtjdpfxexztm Rs Adust

Durumu: kullanılmış, Üretim yılı: 2018, toplam uzunluk: 1.750 mm, toplam genişlik: 1.800 mm, toplam yükseklik: 1.800 mm, Net weight: 975 kg - Year of manufacture: 2018 - Documentation available: No - CE marking present: Yes Gjdpfxjxzrfrs Aduott - CE certificate present: No - Serial number: 173180025 - Main motor power [kW]: 3 - Working area X [mm]: 3000 - Working area Y [mm]: 3000 - Working area Z [mm]: 50 - Horizontal drilling machine: Yes - Horizontal drilling spindles [pcs]: 4 - Vertical drilling machine: Yes - Saw unit present: Yes - Voltage [V]: 400 - Power consumption [A]: 3 - Transport dimensions: 1750mm x 1800mm x 1800mm (l x w x h) - Transport weight [kg]: 975kg - Transport packages [pcs]: 1 Financial Information VAT: The stated price is subject to VAT VAT/margin taxation: VAT deductible for businesses Delivery and trade-in possible at any time for all items in the industrial sector Glenn Smeets

Durumu: kullanılmış, Üretim yılı: 2011, Base Machine M800 X5 TV 1 WORKING AREA X: 5,020 mm Y: 1,830 mm Z: 675 mm Clearance Height: 300 mm (from 50 mm suction cup height) MACHINE STRUCTURE The base structure is a monolithic construction made of thick-walled steel. It is reinforced with welded-in parts throughout the entire machine bed, resulting in extreme stability. The specific table design, featuring a large base, is the secret to guaranteeing long-term precision and stability. The machine layout allows the user to achieve optimal workflow with minimal space requirements. The moving gantry carrier is constructed as a solid monoblock. It is positioned in the X-direction via prismatic, ground guides and recirculating ball carriages. On this moving aggregate carrier, the working unit is also mounted on prismatic, ground guides with recirculating ball carriages. AXIS MOVEMENT All axes travel on prism-linear guides with a large cross-section and recirculating ball shoes with a large support surface, which ensures optimal sliding even at the highest speeds and accelerations. Precise and fast positioning of the mobile gantry (X-axis) is achieved via a helical rack and pinion drive. Recirculating ball screws with a large cross-section ensure the precise positioning of the working unit along the movable gantry (Y- and Z-axes). The perfect mechanical dynamics and maximum positioning accuracy are controlled by high-quality drives and brushless motors. Maximum axis speeds: - X-axis = 90 m/min - Y-axis = 90 m/min - Z-axis = 30 m/min Safety device with bumper and light curtain Around the mobile column, bumpers with sensors are installed, and a light curtain system is positioned in front of the machine. If the operator enters the active zone, the X-axis travel speed is reduced to a lower value of 25 m/min, without stopping the machine. This system allows the loading of workpieces in pendulum operation during machining, without limiting access zones as with tread mat systems. This prevents unwanted interruptions in the machining cycle and allows greater freedom of movement around the work table. CE certificate for the safety system Safety guard Protective fencing at the sides and rear Automatic central lubrication regulated by CNC control Lubrication of the X, Y, and Z axes is controlled by the CNC; scheduled at regular intervals, without manual intervention on the machine. Central extraction port All individual extraction ports of the machining units are combined into a central port. Inside the port, there are various slide valves, which are controlled via the NC control system. In this way, only the required extraction air volume is used. Chip conveyor Maxi 5-Axis Electrospindle 11 kW HSK-63 "Prisma K" - 5-axis electrospindle with 11 kW power rating at 20,000 rpm in S1 (100% duty cycle) - Maximum speed: 20,000 rpm - Direction of rotation: left/right - Liquid cooling - Tool interface: HSK 63F Gtjdpfx Asxy Tmnodust - Inverter 18 kW for stepless, uniform power delivery - Maximum rotation: B-axis = 200° (+-100°), C-axis = 650° Thanks to non-orthogonal axes, it is possible to perform complex horizontal positioning in a small working area. This enables the machining of complex geometries without the risk of collisions.
