Kullanılmış Index C100 satın al (1)

Durumu: kullanılmış, TECHNICAL DATA - Number of axes: 10 - Number of spindles: 2 - Number of turrets: 3 MAIN SPINDLE - Spindle nose: A2-5 - Spindle drive power: 22/29 [kW] - Spindle speed: 7,000 [rpm] - Max. bar diameter: 42 [mm] - Max. main chuck diameter: 110 [mm] - Minimum C-axis resolution: 0.001 [degrees] SUB SPINDLE - Spindle nose: A2-5 - Spindle drive power: 16.5/19 [kW] - Spindle speed: 7,000 [rpm] - Max. bar diameter: 42 [mm] * Max. main chuck diameter: 110 [mm] - Minimum C-axis resolution: 0.001 [degrees] - Travel: 500 [mm] - Rapid traverse speed: 60 [m/min] - Distance between spindles: 515 [mm] LEFT UPPER TURRET - Number of stations: 10 - Number of driven stations: 10 - Travel X/Z: 70 / 250 [mm] - Travel Y: 70 [mm] - Tool type: VDI 25 - Driven tool speed: 8,000 [rpm] - Driven tool power: 4.2 [kW] RIGHT UPPER TURRET - Number of stations: 10 - Number of driven stations: 10 - Travel X: 125 [mm] - Tool type: VDI 25 Gisdpsyfw I Usfx Ah Tjp - Driven tool speed: 8,000 [rpm] - Driven tool power: 4.2 [kW] LEFT LOWER TURRET - Number of stations: 10 - Number of driven stations: 10 - Travel X/Z: 70 / 400 [mm] - Travel Y: 70 [mm] - Tool type: VDI 25 - Driven tool speed: 8,000 [rpm] - Driven tool power: 4.2 [kW] ELECTRICAL SUPPLY - Supply voltage: 400 [V] - Total drive power: 37 [kW] WEIGHT AND DIMENSIONS - Required floor space: 5990 x 1710 [mm] - Machine height: 2140 [mm] - Machine weight: 5,500 [kg] MACHINE HOURS - Operating hours: 16,759 [hrs] ACCESSORIES - Control: Fanuc Series 31i-B - 3-color status lamp - Coolant tank * with high-pressure pump: 25 [bar] * with paper filter - Internal coolant supply (ICS) - Chip conveyor: DROITE - Coolant tank: KLH - Parts pick-off - Parts conveyor belt - Bar feeder: IEMCA BOSS 552 HD/32L
