Kullanılmış Dmg Mori Ctx Beta 1250 4A satın al (2)

Durumu: kullanılmış, Üretim yılı: 2013, Heidenhain iT Plus control system Dimensions (L x W x H): 6.55 x 3.46 x 2.40 m Machine weight: 14,500 kg // Technical Details Operating hours: 43,506 h Spindle hours: 25,244 h // Left spindle head: Chuck diameter: 315 mm Spindle flange diameter: 170.5 mm Spindle bore: 104 mm Spindle diameter at front bearing: 130 mm Drive power (100% duty cycle): 25 kW Drive power (40% duty cycle): 32 kW Torque (100% duty cycle): 280 Nm Torque (40% duty cycle): 360 Nm Speed range: 0–5,000 rpm C-axis speed: 2,000 rpm // Right spindle head: Chuck diameter: 315 mm Spindle flange diameter: 170.5 mm Spindle bore: 87 mm Spindle diameter at front bearing: 130 mm Drive power (100% duty cycle): 25 kW Drive power (40% duty cycle): 32 kW Torque (100% duty cycle): 280 Nm Torque (40% duty cycle): 360 Nm Speed range: 2,000 rpm // Slide 1: Longitudinal travel: 1,200 mm Cross travel: 490 mm Vertical travel Y: ±100 mm // Slide 2: Longitudinal travel: 1,200 mm Cross travel: 195 mm Ndsdpfxjxpizgo Afzoc // Slide 3: Longitudinal travel: 1,200 mm // Turn-mill spindle: Tool interface: Capto C6 Spindle speed: 12,000 rpm Drive power (100% duty cycle): 20 kW Drive power (40% duty cycle): 22 kW Torque (100% duty cycle): 79 Nm Holding torque, locked: 1,000 Nm Swivel range: ±110 degrees // Tool magazine: Number of tools: 120 Max. tool length: 300 mm Max. tool diameter: 80 mm Max. tool weight: 7 kg // Tool turret 2: Number of tool stations: 12 Shank diameter according to DIN 69880: 40 mm Number of driven tool stations: 12 Max. speed: 4,000 rpm Max. power: 11.3 kW

Durumu: kullanılmış, Üretim yılı: 2013, kontrolör üreticisi: Siemens, kontrolör modeli: 840 Dsl, Description: General: Year of manufacture: 2013 Control: Siemens 840 Dsl Turning length: 1,185 mm Swing diameter: 540 mm Bar capacity: 75 mm Main spindle: Technology: motor spindle Speed: 5,000 rpm Max. power: 32 kW Max. torque: 360 Nm Chuck: SMW KNCS-N 260-78 C-axis: 0.001° Flush: Chuck flushing Counter spindle: Technology: motor spindle Speed: 5,000 rpm Max. power: 32 kW Max. torque: 360 Nm Chuck: SMW KNCS-N 260-78 C-axis: 0.001° Flush: Chuck flushing + spindle flushing Tool carrier I (X/Y/Z/B): Technology: milling spindle on traveling column Milling spindle speed: 12,000 rpm Max. power: 22 kW Tool interface: Capto C6 X-axis: 450 mm Y-axis: 200 mm Z-axis: 1,200 mm B-axis: +/- 110° Position feedback: Direct (glass scales) Tool carrier II (/X/Y/Z): Technology: turret on cross slide Drive: direct drive Speed: 10,000 rpm Power: 14 kW Torque: 34 Nm X-axis: 195 mm Y-axis: 80 mm Z-axis: 1,200 mm Tool interface: VDI 40 Number of tool stations: 12 positions Automation: Technology: gantry loader with stack magazine Workpiece diameter: 50 - 200 mm Max. workpiece height: 230 mm Nodpoxl Nfqefx Afzsdc Max. workpiece weight: 15 kg Number of stack pallets: 20 units Load per stack pallet max.: 40 kg Equipment / Accessories: Chip removal: chip conveyor Coolant supply: high-pressure coolant system (IKZ), 80 bar Tool magazine: chain magazine, 120 positions Workpiece measurement: Renishaw probe Tool breakage monitoring: swing wire Automation: gantry loader with stack magazine Emulsion mist extractor: mechanical Setup mode: electronic handwheel Working area door: automatic Chucks: 2x SMW KNCS 260 Tool holders: various Capto C6 adapters
