Kullanılmış Heller H 6000 satın al (2)

Koşul: iyi (kullanılmış), Üretim yılı: 2019, çalışma saatleri: 19.000 h, Fonksiyonellik: tamamen fonksiyonel, 2019 HELLER H6000 CNC Twin Pallet Horizontal Machining Center CNC Horizontal Machining Center with Twin Pallet System Low operating hours, single-shift machine, excellent condition Manufacturer: HELLER Model: H6000 Year of manufacture: 2019 Machine type: CNC Horizontal Machining Center Pallet system: Twin pallet / 2-pallet system Serial number: MXXXXX (upon request) Pallet size: 630 x 630 mm Maximum pallet load: 1,000 kg Maximum workpiece height: 1,200 mm Travel axes: X-axis: 1,000 mm Y-axis: 1,000 mm Z-axis: 1,000 mm B-axis: 360° / 0.001° indexing Rapid traverse speeds: X-axis: 50,000 mm/min Y-axis: 50,000 mm/min Redpfxoy S S Hye Ahlocb Z-axis: 75,000 mm/min B-axis: 25 rpm Feed forces: X- / Y-axis: 15,000 N at 40% duty cycle Z-axis: 20,000 N at 40% duty cycle Spindle speed range: 5 – 6,000 rpm Spindle drive power: 60 kW at S6 / 40% duty cycle Maximum spindle torque: 2,292 Nm at S6 / 40% duty cycle Spindle taper: HSK 100A Automatic tool changer: 50 positions Maximum tool diameter: 280 mm Maximum tool length: 600 mm Maximum tool weight: 25 kg Condition: The machine is in excellent condition, has low operating hours, and is available for immediate inspection. The machine is available at short notice.

Koşul: mükemmel (kullanılmış), Üretim yılı: 2015, çalışma saatleri: 32.000 h, Fonksiyonellik: tamamen fonksiyonel, X ekseni hareket mesafesi: 1.000 mm, Y ekseni hareket mesafesi: 1.000 mm, Z ekseni hareket mesafesi: 1.000 mm, hızlı travers X ekseni: 50 m/dak, hızlı tablası Y ekseni: 50 m/dak, hızlı ilerleme Z ekseni: 50 m/dak, kontrolör modeli: Sinumerik 840Dsl, giriş voltajı: 400 V, giriş akımı türü: Klima, Donanım: devir hızı sonsuz değişken, talaş konveyörü, 2x Heller H6000 + Fastems Pallet Automation System Horizontal Machining Centres with Flexible Pallet Container Heller H6000 2 machines with identical specifications Travel ranges Feed force X 1000 mm 15 kN Y 1000 mm 15 kN Z 1000 mm 20 kN B 360°, 0.001° increments Direct position measuring system in all axes Rapid traverse: Axis dynamics Power X/Y/Z 50 m/min, 5 m/s² B 25 rpm Spindle – Power Cutting Interface: HSK100 Speed: 5–8000 rpm Power: 43 kW (40% duty cycle) Torque: 822 Nm (40% duty cycle) Last spindle replacement: 2020 Tool magazine Type: Shelf magazine Magazine slots: 265 Max. tool length: 600 mm Max. diameter: 280 mm Tool coding: Balluff chip Second control panel at loading station Loading station with 7 handover positions Pallet changing device Pallets: 630 × 630 mm Max. interference circle: 1000 mm Max. height: 1200 mm Max. weight: 1000 kg Coolant system: Scraper belt chip conveyor Knoll coolant unit Paper band filter Thru-spindle coolant (IKZ) 50 bar, frequency-controlled Rjdpfx Asxxx Dcjhlocb Work area rinse Emulsion mist extraction Door glass air nozzle Additional equipment: Facing slide device (compensating/U-axis) 4 facing slides per machine Tangential control incl. NC cycles Wireless probe (Renishaw) Required space:– 7100 × 3750 × 4300 mm (L×W×H) Machine weight:– 15,600 kg Total power requirement:– 44 kVA Control: Sinumerik 840D sl Fast drill breakage detection Process-integrated tool monitoring Status indicator lights 3D models for work area simulation Operating data acquisition (OPC/UA) Year of manufacture: 2015 Operating hours: Approx. 32,000 h (Machines still in operation) Fastems Pallet Automation FPC1500 Base container with 2 loading stations Extension container Total of 20 pallet stations on 2 levels Control: MMS Space requirement: approx. 18 × 2.4 × 4.2 m Total footprint of system (2× Heller + Fastems): Approx. 18 × 10 × 4.5 m The machines are still in current production. Inspection by appointment. Machine relocation can be organised.
