Kullanılmış Emco Hyperturn 65 satın al (1)

Durumu: mükemmel (kullanılmış), Üretim yılı: 2019, HYPERTURN 65-1300 (SM2Y2) DUOTURN with 2 turrets incl. milling drive and 2 Y-axes High-productivity CNC turning/milling center for complete machining of turned- milled parts with 1300 mm spindle distance; Integrated spindle motors (ISM) on the main and sub-spindle (liquid-cooled), preloaded roller guides. Drive power: Main spindle – 29 kW Sub-spindle – 29 kW Speed range: Main spindle: 0 – 5000 rpm Sub-spindle: 0 – 5000 rpm Spindle connection (DIN 55026): Main spindle: KK 6 (max. bar capacity ø 65 mm) Sub-spindle: KK 6 Y-axis on both turret slides: • Travel range: +/- 50 mm Includes: • Hollow clamping cylinder incl. draw tube • Parts ejector and flushing through the sub-spindle • Sinumerik 840D-sl/OPERATE control o emcoNNECT/APP-based user interface Lsdpfx Aew T Apgsameai o 22" multi-touch display o IPC with 240 GB o SHOPTURN conversational programming o USB interface o Network drive / Ethernet o 3D simulation o much more • 2x 12-station tool turrets VDI 30 radial with directional logic for up to 2x 12 driven tool stations! Swivel speed adjustable via feed switch. o Performance data: o Max. 6.7 kW at 2650 rpm o Constant torque 25 Nm o Speed range 0–5000 rpm o C-axis for main and sub-spindle o TRANSMIT software for simple C-axis programming • Chip conveyor with programmable ejection height of 1200 mm ("hinged belt" type) • Coolant system integrated into the chip conveyor 2x process pumps 14 bar (turrets) 1x rinse pump 4.8 bar (main spindle/ working area) 1x rinse pump 3.7 bar (sub-spindle) • Control cabinet air conditioning • Hydraulic unit • Machine light • 230 V socket on the control panel • 5 leveling elements • Documentation including: Bürener Maschinenfabrik: chip conveyor various accessories Year of manufacture: 2019
