Kullanılmış baskı sonrası makineleri satın al (1.885)
Sonuçları sırala
- En düşük fiyat En yüksek fiyat
- En son ilanlar En eski ilanlar
- En kısa mesafe Maksimum mesafe
- En yeni üretim yılı En eski üretim yılı
- En son güncelleme En eski güncelleme
- Üreticiler A'dan Z'ye Üretici Z'den A'ya
- Uygunluk
- En düşük fiyat
- Fiyat
- En yüksek fiyat
- Fiyat
- En son ilanlar
- Yayınlanma tarihi
- En eski ilanlar
- Yayınlanma tarihi
- En kısa mesafe
- Mesafe
- Maksimum mesafe
- Mesafe
- En yeni üretim yılı
- Üretim yılı
- En eski üretim yılı
- Üretim yılı
- En son güncelleme
- Son güncelleme tarihi
- En eski güncelleme
- Son güncelleme tarihi
- Üreticiler A'dan Z'ye
- Makine üreticisi
- Üretici Z'den A'ya
- Makine üreticisi
- A'dan Z'ye adlandırma
- Tanım
- Z'den A'ya adlandırma
- Tanım
- A'dan Z'ye model
- Model
- Modelden Z'den A'ya
- Model
- En düşük referans
- Referans
- En yüksek referans
- Referans
- En kısa çalışma süresi
- Çalışma süresi
- En uzun çalışma süresi
- Çalışma süresi
- Uygunluk
- Uygunluk
küçük ilan
Volkach
2.313 km
Duplo System 5000 | 2014 | 1,36 milyon
DuploSystem 5000
Ara
Durumu: kullanılmış, Üretim yılı: 2014, Duplo Brochure Production System 5000
Offer includes:
- 1x DC-10/60 Collating Tower
- LUL-HM Handover Unit
- DBM-500 Stitching and Folding Unit
- DBM-500T Front Trimmer
- DBM-K Batch Counter
- DBM-400LS Long Stacker
Duplo System 5000
Brochure Production
1x DC-10/60: 10 Stations
- Paper size: min. 120 x 148 mm; max. 350 x 500 mm
- Paper weight: 40 - 300 g/m²
- Pile height: 60 mm per station
- Feed system: Suction/blower air
- Controls: Double sheet, missing sheet, paper jam, empty station detection
- Power supply: 230 V, 50 Hz, 4.5 A, 1035 W
- Dimensions: 630 mm x 750 mm x 1972 mm
Chsdpfxsxyhlrj Acwef
- Weight: 290 kg
DBM 500: Folding and Stitching Unit
- Paper size: min. 120 x 170 mm; max. 350 x 500 mm
- Speed:
> 5,000 sets/h (A5)
> 4,600 sets/h (A4)
> 4,000 sets/h (A3)
- Stitching capacity: 5 mm (50 sheets, 80 g/m²)
- Folding capacity: 25 sheets
- Number of stitching heads: 2
- Controls: Paper jam control, paper position indicator, wire end detection
- Memory capacity: 12 programs
- Folding and stitching modes: Fold without stitching; saddle stitching/folding; corner stitching/folding; corner stitching; block/side stitching
- Power supply: 230 V, 50 Hz, 5 A, 1150 W
- Dimensions: 1610 mm x 770 mm x 1020 mm
- Weight: 412 kg
DBM 500T: Front Trimmer
- Booklet size: min. 85 x 120 mm; max. 250 x 356 mm
- Trimmed final size: min. 75 x 120 mm
- Speed: >5,000 sets/h
- Processing thickness: 50 sheets (80 g/m²)
- Power supply: 230 V, 50 Hz, 3.3 A, 759 W
- Dimensions: 700 mm x 635 mm x 1094 mm
- Weight: 241 kg
On request, we can arrange the following services for you:
Packaging, loading, and transport (by ship or air) including customs clearance
Obtaining a leasing offer
küçük ilan
Volkach
2.313 km
Quadient DS1200G4i | 2022 | 12,21 mio
QuadientDS1200G4i
Ara
Durumu: kullanılmış, Üretim yılı: 2022, Quadient zarf makineleri:
-Makine tipi: DS1200G4i
-Seri numarası: YBJ8822
-Makine tipi: DS1200G4i
-Seri numarası: YBJ8823
-Sayaç durumu: 12.202.925 / 11.878.105
Csdpfjxyf T Hex Acwshf
-Üretim yılı: 2022
-Full servis sonu: 26.10.2023
Ek bilgiler:
-Yüklü yazılım versiyonu: IOMS V9.0.2.1 r92321
-Katlama ünitesi mevcut
-EZB besleyicisinden otomatik kağıt yükleyici mevcut
-Bir ekleme istasyonu mevcut
Tüm Hizmet Paketi
Her şeyi biz hallediyoruz: güvenli ambalajlamadan nakliyeye, gümrük işlemlerine kadar.
Sürdürülebilir ve ekonomik
İkinci el bir makineyi tercih ederek iki kat avantaj elde edin: Hem çevreyi koruyun hem de bütçenize katkı sağlayın. Olası kullanım izlerine rağmen, cazip fiyatla kaliteli bir ürün alırsınız.
küçük ilan
Volkach
2.313 km
Theisen & Bonitz B314 SP | 2021
Theisen & BonitzB314 SP
Ara
Durumu: kullanılmış, Üretim yılı: 2021, - Sensor stack up to 55 cm
- 14 stations
- Minimum format 10.5 x 15 cm
- Maximum format 35 x 50 cm
- Paper weights from 20 to 1000 g/m²
- Throughput 1:1 up to 3,300 sets/hour
- Throughput 1:2 up to 5,000 sets/hour
Csdpfx Aoxyf D Sscwehf
Standard features:
- Individual adjustable single suction and blowing nozzles
- Controlled blowing and separation air
- Sensor-controlled stack height
- Miss- and double-sheet detection per station, self-adjusting ultrasonic system
- Cross transport system with axial and radial adjustment via toothed belt technology
- Paper jam detection for the transport table
- Manual feed station on the right; usable if the set diverter option is out of service
- Electrical connection for delivery jogger and stitch-fold-trim machine 303/304
- Vacuum connection for 303/304
All-in-One Service Package
We take care of everything: from secure packaging to transport and customs clearance.
Sustainable and economical
Opt for a used machine and enjoy double benefits: protect the environment and your budget. Despite possible signs of use, you will receive a quality product at an attractive price.

Şimdi bilgi alın
+49 201 857 86 180
+49 201 857 86 180
Şimdi ilan ver
*ilan başına/ay
küçük ilan
Volkach
2.313 km
Horizon SP-10 | 1992
HorizonSPF models
Ara
Durumu: kullanılmış, Üretim yılı: 1992, Teklif şunlardan oluşmaktadır:
Hohner zımbalama kafası
kağıt zımbalama için manuel ayar
Aşağıdaki makine tiplerine bağlanabilir:
- AC 1200-4800
- HAC
- MC
- AC 8000S/ 8300S
- MAC
- TAC
Teknik veriler:
- Format: min. 148x115mm, maks. 320x330mm
- İşleme kalınlığı: min. 2 yaprak, maks. 4mm
- Hız/devir sayısı: maks. 2350/sa
Cjdpfsu Srvasx Acwshf
- Boyutlar genişlik 100cm, derinlik 62cm, yükseklik 85cm
- Ağırlık: 130kg
- Güç kaynağı: 220-240V, 300W
Talep üzerine aşağıdaki öğeleri sizin için organize edebiliriz:
Paketleme, yükleme, gümrükleme dahil nakliye (gemi veya uçakla)
küçük ilan
Volkach
2.313 km
Horizon HCB-2
HorizonAll models
Ara
Durumu: kullanılmış, Üretim yılı: 2008, Teklif şunlardan oluşmaktadır:
Horizon HCB-2
Chodpfxeu Srvge Acwof
Ciltli ciltleme sistemi
- Teknoloji: Dokunma ve Çalışma
- Kağıt boyutu: maks: 304,8 x 304,8 mm; min: 136,7 x 133,7 mm
- Kitap kalınlığı: min. 3mm; maks. 25mm
- Kapak formatı: maks. 680,6 x 340,8 mm; min. 322,4 x 169,7 mm
- Kapak kalınlığı: 105 - 160 g/metrekare
- Çıkış: maks. 130 devir/saat
- Boyutlar: 1.800 x 1.050 x 1.536mm
- Ağırlık: 456kg
Talep üzerine aşağıdaki öğeleri sizin için organize edebiliriz:
Paketleme, yükleme, gümrükleme dahil nakliye (gemi veya uçakla)
Kiralama teklifi alma
Daha fazla ikinci el makine keşfedin
küçük ilan
Volkach
2.313 km
Horizon AFC-504 AKT | klasör | 4 | 2001 |
HorizonAFC-504/544/546 models
Ara
Durumu: kullanılmış, Üretim yılı: 2001, 3 AY GARANTI
Teklif şunlardan oluşmaktadır:
- Katlama makinesi Horizon AFC-504 AKT
- Düz kazık besleyici
- Teslimat
Horizon AFC-504 AKT
4 cepli katlama makinesi
- Silindirlerin durumu: %0
- Teknoloji: Dokunma ve Çalışma
- Hata önleme:
Eksik sayfa, çift sayfa ve sıkışma kontrolü
Chsdpfx Asu Sr Ehocwjf
- Standart katlama tipleri:
Önceden ayarlanmış 11 standart katlama tipi
- İş hafızası:
Tekrarlanan işler için 50 bellek konumu
- Merkez tahtası: tam otomatik
- Toka plakası sayısı:
1. katlama ünitesi: 4 toka plakası + bıçak
2. katlama ünitesi: 2 toka plakası
- Biçim:
maks. 490x650mm; min. 120x172mm
- İşleme kalınlığı: 40-250g/sqm
- İstifleme yüksekliği: 650mm
- Çıktı: maks. 27.000 yaprak/saat
- Güç: 400V / 50Hz - 2,5kW
- Boyutlar: 2,540x1,790x1,440mm
- Ağırlık: 870kg
Talep üzerine aşağıdaki öğeleri sizin için organize edebiliriz:
Paketleme, yükleme, gümrükleme dahil nakliye (gemi veya uçakla)
Kiralama teklifi alma
küçük ilan
Volkach
2.313 km
Triumph RP2
TriumphRP2
Ara
Durumu: kullanılmış, OLDUĞU GIBI DURUMDA - STOKTA MEVCUT
Teklif şunlardan oluşmaktadır:
Triumpf RP2
Vibratörün indirilmesi
- Ağırlık: 47kg
Talep üzerine aşağıdaki öğeleri sizin için organize edebiliriz:
Chedpfx Aceu Sr Rdswsf
Paketleme, yükleme, gümrükleme dahil nakliye (gemi veya uçakla)
küçük ilan
Volkach
2.313 km
MBO T 800 6 | 2001
MBOT 800
Ara
Durumu: kullanılmış, Üretim yılı: 2001, DOĞRUDAN MATBAADAN
Bu makineyi müşterimiz adına satıyoruz ve istediği fiyatı gerçekleştirmeye çalışıyoruz.
Ancak, sizden gelecek tekliflere de açığız.
Teklif şunlardan oluşur:
Emme kayışı besleyicili MBO katlama makinesi T800
- 1. ünite 6 toka + MBO kapı katlama toka plakası
- FA ofset tabaka dağıtımı 2001, presleme silindirleri ile
Talep üzerine aşağıdaki öğeleri sizin için organize edebiliriz:
Cjdpfx Asu Stdxjcwshf
Paketleme, yükleme, gümrükleme dahil nakliye (gemi veya uçakla)
Kiralama teklifi alma
küçük ilan
Volkach
2.313 km
Horizon SPF-200L FC-200L | 2013 | 18 milyon çıktı | Kolatörsüz
HorizonSPF models
Ara
Durumu: kullanılmış, Üretim yılı: 2013, Horizon Brochure Production Line SPF-200L, FC-200L, used
The Horizon brochure production line with models SPF-200L and FC-200L is a state-of-the-art, modular solution for the efficient production of saddle-stitched brochures – including A4 landscape format. This system is suitable for both offset and digital printing and is specifically designed for small to medium print runs. Thanks to the combination of the brochure stitcher (SPF-200L) and front trimmer (FC-200L), the line offers maximum flexibility and productivity in post-press operations.
Key Features
- Automated Settings: All format and production parameters are automatically set via a large, intuitive colour touchscreen – including fold roller gap.
- A4 Landscape Capability: The SPF-200L enables the production of brochures in A4 landscape format, making it particularly versatile.
- High Speed: Up to 4,000 brochures/hour when stitching (3,500 in landscape format).
- Flexible Configuration: Can be combined with other Horizon feeders and digital print feeders for hybrid production lines.
Codpfjxb Tn Iox Acwehf
- Versatile Formats: Processes formats from at least 148 x 120 mm up to a maximum of 610 x 350 mm (SPF-200L).
- Strong Wire Processing: Various stitching heads available for different wire thicknesses and loop stitching.
- Easy Operation: Large touchscreens on all main modules for quick setup and error diagnosis.
Technical Specifications
- SPF-200L Format Range (min-max): min. 180 x 105 mm, max. 610 x 350 mm
- SPF-200L Speed: up to 4,000 cycles/h (3,500 cycles/h landscape)
- SPF-200L Special Features: A4 landscape, fully automatic
- FC-200L Format Range (min-max): Front trimmer, integrated
- FC-200L Special Features: Final trim
- Brochure Thickness: up to 100 pages (depending on paper)
- Weight SPF-200L with FC-200L: approx. 831 kg
- Machine Dimensions SPF-200L with FC-200L: 4,271 x 810 x 1,250 mm (L x W x H)
- Power supply: 230 V, 5.3 A; 1.0 kW (SPF-200L)
All-Inclusive Package
We take care of everything: from secure packaging and transport to customs clearance. On request, we can also provide you with a tailor-made leasing offer.
Sustainable and Economical
Choose a used machine and benefit twice: protect the environment and your budget. Despite possible signs of use, you get a quality product at an attractive price.
küçük ilan
Volkach
2.313 km
Horizon HT-30 C | 2012 | 4,7 Mio
HorizonHT-30C
Ara
Durumu: kullanılmış, Üretim yılı: 2012, Horizon HT-30C üç taraflı kesici, ikinci el
Horizon HT-30C, kısa süreli ve talep üzerine baskı kitap pazarı için özel olarak tasarlanmış yenilikçi ve verimli bir üç bıçaklı düzelticidir.
Özel özellikler:
- Kolay kullanım ve otomatik ayarlar için renkli dokunmatik ekran
- Tam otomatik iş kurulumu ve hızlı değişim süreleri
- Servomotor kontrollü bıçak konumlandırma sayesinde hassas kesim kalitesi
- İzsiz kesim için hidrolik kontrollü sıkıştırma ve kesme basıncı
- Farklı kalınlıktaki kitapları sürekli işleme imkanı
- Eksiksiz kitap üretimi için Horizon BQ-270V gibi nearline ciltleme makineleri ile uyumludur
Csdjxbdazopfx Acwohf
Teknik özellikler:
- Kesilmemiş kitap formatı: 148 x 200 mm ila 320 x 320 mm
- Kesilmiş kitap formatı: 145 x 200 mm ila 303 x 303 mm
- Kesim kalınlığı: 1 - 51 mm
- Üretim hızı: Saatte 500 kitaba kadar
- Depolama kapasitesi: 200 adede kadar yinelenen iş
Çok yönlü kaygısız paket
Güvenli paketleme ve nakliyeden gümrük işlemlerine kadar her şeyle biz ilgileniyoruz. Talep üzerine, sizin için özelleştirilmiş bir kiralama teklifi de oluşturabiliriz.
Sürdürülebilir ve ekonomik
Kullanılmış bir makine tercih edin ve iki kat fayda sağlayın: çevreyi ve bütçenizi koruyun. Olası aşınma belirtilerine rağmen, kaliteli bir ürünü cazip bir fiyata alacaksınız.
küçük ilan
Volkach
2.313 km
Horizon DC-1000S | 2019
HorizonAll models
Ara
Durumu: kullanılmış, Üretim yılı: 2019, Horizon DC-1000S bağlama konveyörü, inline ciltleme hatlarında kitap bloklarının yön değiştirmesi ve doğru şekilde aktarılması için özel olarak geliştirilmiş bir konveyör modülüdür. Horizon DC-1000S, mükemmel ciltleyici ile üç bıçaklı kesici HT-1000V arasında ara konveyör olarak görev yapar. Kitap bloklarını ciltleyiciden tek tek alır, taşıma yönünü değiştirir ve onları doğru pozisyonda bir sonraki sisteme aktarır. Bu sağlam modül, modern Horizon ciltleme sistemleriyle sorunsuz ve verimli bir devam işlenişi için tasarlanmıştır.
Chodpfx Acoxmg Edowjf
küçük ilan
Volkach
2.313 km
Hohner halka delikli dikiş kafası 43/6 S
Hohner43/6 S
Ara
Durumu: kullanılmış, Teklif şunlardan oluşmaktadır:
1x Hohner 43/6 S delikli zımbalama kafası
Cjdpfx Acju S Af Newshf
her kitapçık hazırlayıcı / tel dikiş makinesi ile uyumlu
Talep üzerine aşağıdaki öğeleri sizin için organize edebiliriz:
Gümrük işlemleri dahil paketleme, yükleme, nakliye (gemi veya uçakla)
Kiralama teklifi alma
küçük ilan
Volkach
2.313 km
Horizon HT-70 | 2004
HorizonHT-70
Ara
Durumu: kullanılmış, Üretim yılı: 2004, Horizon HT-70 Three-Knife Trimmer, used
The Horizon HT-70 is a powerful and robust three-knife trimmer that can be operated both inline and offline. It is ideal for the precise finishing of books and brochures.
Special Features:
- High productivity with up to 1,000 cutting cycles per hour
- Clean and precise cuts without rough edges
- User-friendly LCD display for simple operation and status monitoring
- Flexible processing of various product sizes
- Quick changeover times of under 10 minutes
- Advanced safety lock system for operator protection
Technical Specifications:
- Cutting thickness: 2 - 50 mm
- Number of knives: 3
- Untrimmed dimensions: Maximum: 330 x 330 mm; Minimum: 148 x 105 mm
- Trimmed dimensions: Maximum: 300 x 300 mm; Minimum: 142 x 100 mm
- Dimensions (L x W x H): 2260 x 1160 x 1600 mm
- Weight: approx. 1530 kg
All-inclusive service package
We take care of everything: from secure packaging and transport to customs clearance. On request, we can also offer you a tailored leasing solution.
Sustainable and cost-effective
Chedpfju Tfuvsx Acwef
Choose a pre-owned machine and benefit in two ways: save both the environment and your budget. Despite possible signs of use, you will receive a quality product at an attractive price.
küçük ilan
Volkach
2.313 km
Horizon MC-8a
HorizonMC-8
Ara
Durumu: kullanılmış, Horizon MC-8a Collating Tower, used
The Horizon MC-8a is a proven collating tower that, when combined with other modules such as stitching, folding, and trimming units, also enables brochure production.
Key Features:
- Number of stations: 8
- Robust and cost-effective
- Modularity: Can be combined with additional Horizon modules to form a complete booklet production line.
Technical Specifications:
- Paper sizes: From A5 to A3 (5.8" x 8.3" to 12.5" x 18.5")
- Paper weight: 52 gsm to 260 gsm
- Collating speed: Up to 3,500 sets per hour (A4)
- Maximum sheet size: 317 mm x 470 mm
All-inclusive package
We handle everything: from secure packaging and transport to customs clearance. Upon request, we can also provide a tailored leasing offer.
Sustainable and economical
Opt for a used machine and benefit in two ways: conserve the environment and your budget. Despite possible signs of previous use, you will receive a quality product at an attractive price.
Codpfsw Eu Sxjx Acwjhf
küçük ilan
Volkach
2.313 km
Horizon SPF-10II FC-10II
HorizonSPF models
Ara
Durumu: kullanılmış, Used Horizon Bookletmaking System SPF-10II, FC-10II
This pre-owned machine, consisting of a combination of the Horizon SPF-10 II stitching and folding unit and the Horizon FC-10II front trimmer, offers a comprehensive solution for the production of booklets and brochures. Although the equipment is older, it continues to deliver efficient and precise processing of printed materials.
Key Features
- Stitching options: Saddle stitching, side stitching, corner stitching, and loop stitching
- Format adjustment: Manual settings for flexible format processing
- Precise trimming: Clean and professional finishing of products by means of the integrated front trimmer
Technical Specifications:
Chjdpfx Ajw Eu S Secwef
- Input format: Min. 148 x 148 mm, Max. 330 x 305 mm
- Processing thickness: Min. 2 sheets, Max. 4 mm
- Book size (trimmed): Min. 99 x 2 mm, Max. 225 x 20 mm
- Trimming capacity: Min. 4 pages, Max. 88 pages (80 gsm)
- Production speed: Up to 2,800 booklets per hour
All-in-one service package
We take care of everything: from secure packaging and transport to customs clearance. Upon request, we can also offer you a tailored leasing proposal.
Sustainable and cost-effective
Choose a used machine and benefit twice: protect the environment and your budget. Despite possible signs of use, you receive a quality product at an attractive price.
küçük ilan
Volkach
2.313 km
Horizon ST-20R
HorizonST-20R
Ara
Durumu: kullanılmış, HORIZON pile lowering table / right-hand delivery, ST-20R, used
The Horizon ST-20R pile lowering table is characterized by its special right-hand delivery and offers an efficient solution for stacking and sorting printed materials. With its versatile stacking options—either straight or offset to the side—it allows flexible handling of various print jobs.
Key features:
- Right-hand delivery:
The "R" in ST-20R denotes right-hand delivery, which distinguishes this model. The right-side output enables optimal adaptation to specific spatial configurations and workflows.
- Compatibility:
The ST-20 is compatible with a wide range of Horizon models, including MC-80a, VAC-100a, VAC-60Ha, VAC-1000, and VAC-600. This facilitates integration into existing production lines.
- Versatile stacking options:
The ST-20 allows for both flat and offset stacking, increasing adaptability to different print jobs.
Chjdpew Eu Umjfx Acwsf
- Large stacking height:
With a maximum stacking height of 320 mm, the ST-20 can accommodate a substantial volume of printed products, reducing the need for frequent unloading and increasing overall efficiency.
- Precise stacking:
The ST-20 ensures accurate and clean stacking, which maintains the quality of the finished products and minimizes rework.
Specifications:
- Maximum sheet size: 450 x 310 mm
- Minimum sheet size: 185 x 128 mm
- Maximum stacking height: 320 mm
- Dimensions: 652 x 550 mm
- Weight: 62 kg
Complete service package
We take care of everything: from secure packaging and transport to customs clearance. Upon request, we can also provide you with a tailored leasing offer.
Sustainable and cost-efficient
Opt for a used machine and enjoy double the benefits: Protect the environment and your budget. Despite possible signs of use, you will receive a quality product at an attractive price.
küçük ilan
Volkach
2.313 km
FC-10, FC-10II, FC-11 için Horizon yedek bıçak
Horizonextra knife for FC-10 FC-10II FC-11
Ara
Durumu: kullanılmış, Aşağıdan oluşan teklif:
Horizon için yedek bıçaklar, 2'li set
FC-10, FC-10II, FC-11
Cjdpew Eu Utsfx Acwjhf
Talep üzerine sizin için aşağıdaki hizmetleri organize edebiliriz:
Ambalajlama, yükleme, nakliye (gemi veya uçak ile) dahil gümrük işlemleri
Leasing teklifinin alınması
küçük ilan
Volkach
2.313 km
Horizon HMU-80
HorizonHMU models
Ara
Durumu: kullanılmış, Teklif şunlardan oluşur:
- Manuel ünite HMU-80
Horizon HMU-80
El ünitesi
- ile uyumludur:
Horizon MC-80a / MC-80m / MC-80c
Chsdpfx Ajw Evaqjcwjf
- Ağırlık: 8,8kg
Talep üzerine aşağıdaki öğeleri sizin için organize edebiliriz:
Paketleme, yükleme, gümrükleme dahil nakliye (gemi veya uçakla)
Kiralama teklifi alma
küçük ilan
Volkach
2.313 km
Horizon ST-20
HorizonST-20
Ara
Durumu: kullanılmış, HORIZON istifleme ve indirme masası, ST-20
Horizon ST-20 istif indirme masası, basılı ürünlerin istiflenmesi ve sıralanması için verimli bir çözüm sunar. Düz veya yanal ofset olmak üzere çok yönlü istifleme seçenekleriyle, farklı baskı işlerinin esnek bir şekilde ele alınmasını sağlar.
Özel özellikler:
- Uyumluluk:
ST-20, MC-80a, VAC-100a, VAC-60Ha, VAC-1000 ve VAC-600 dahil olmak üzere çeşitli Horizon modelleriyle uyumludur ve mevcut üretim hatlarına entegre edilmesini kolaylaştırır
- Çok yönlü istifleme seçenekleri:
ST-20 hem düz hem de ofset taraf istiflemeye izin vererek farklı baskı işlerine uyarlanabilirliği artırır
- Geniş istifleme yüksekliği:
ST-20, 320 mm'lik maksimum istif yüksekliğiyle önemli miktarda basılı malzeme tutabilir, sık sık boşaltma ihtiyacını azaltır ve verimliliği artırır.
- Hassas istifleme:
ST-20, hassas ve temiz istifleme sağlayarak son ürünlerin kalitesini garanti eder ve yeniden çalışmayı en aza indirir.
Özellikler:
- Maksimum tabaka boyutu: 450 x 310 mm
- Minimum sayfa boyutu: 185 x 128 mm
- Maksimum istif yüksekliği: 320 mm
- Boyutlar: 652 x 550 mm
- Ağırlık: 62 kg
3 AY GARANTI
Makinenin kusursuz çalışacağını garanti ediyoruz ve 3 ay boyunca bundan sorumluyuz. Ancak bundan sonra bile, her zaman yanınızdayız ve herhangi bir sorunu çözmenizde size destek oluyoruz.
Çok yönlü kaygısız paket
Güvenli paketleme ve nakliyeden gümrük işlemlerine kadar her şeyle biz ilgileniyoruz. Talep üzerine, sizin için özelleştirilmiş bir kiralama teklifi de oluşturabiliriz.
Cjdpew Eva Defx Acwjhf
Sürdürülebilir ve ekonomik
Kullanılmış bir makine tercih edin ve iki kat fayda sağlayın: Çevreyi ve bütçenizi koruyun. Olası kullanım izlerine rağmen, kaliteli bir ürünü cazip bir fiyata alacaksınız.
küçük ilan
Volkach
2.313 km
Duplo Sistem 3500 | DC-445 | 2016
DuploSystem 3500
Ara
Durumu: kullanılmış, Üretim yılı: 2016, DUPLO SYSTEM 3500 Booklet Production, used
Booklet system with integrated spine press
The FKS/Duplo System 3500 is a booklet production system equipped with an integrated spine press for flat-laying booklets. The system is suitable for finishing both offset and digital prints.
Key features:
- Booklet production (stapling, folding, fore-edge trimming)
- Programmable job memory
- Machine parameter settings within seconds
- Suitable for processing both offset and digital prints
Technical data:
- Minimum open format: 148 × 210 mm
- Maximum open format: 320 × 460 mm
- Minimum finished format: 85 × 148 mm
- Maximum finished format: 230 × 320 mm
- Paper weight: 52–300 gsm
- Production speed: 3,000 booklets/hour
- Power supply: 230 V, 50 Hz, 3.5 A, 350 W
All-inclusive Service Package
We take care of everything: from safe packaging and transport to customs clearance.
Chodpsw Evc Sjfx Acwof
Sustainable and cost-effective
Choose a pre-owned machine and enjoy double the benefit: save the environment and your budget. Despite possible signs of use, you receive a quality product at an attractive price.
küçük ilan
Volkach
2.313 km
Horizon VAC-60Ha | 2010
HorizonVAC-60
Ara
Durumu: kullanılmış, Üretim yılı: 2010, Horizon VAC-60Ha Collating Tower, used
The Horizon VAC-60Ha is a high-performance collating tower designed as an expansion module or as a standalone unit for existing Horizon collating systems. This machine offers a range of features that make it a valuable asset in the printing and publishing industry.
Key features:
- The VAC-60Ha can be used either as a single tower or as an add-on to increase the capacity of existing systems
- Number of stations: 6 modules
- Paper handling: Processes sheets from 120 x 148 mm up to 350 x 500 mm, with paper weights from 40 to 300 gsm
- Processing speed: Supports system speeds of up to 10,000 sets per hour
- Integration: Seamlessly integrates with existing VAC systems
Technical specifications:
- Dimensions: 842 x 652 x 1,962 mm
- Weight: approx. 315 kg
- Power supply: 230V, 50/60Hz
Chsdpfx Acjw Evfmowjf
- Loading height: 130 mm per station
All-round carefree package
We take care of everything: from secure packaging and transport to customs clearance. Upon request, we can also provide you with a tailor-made leasing offer.
Güven mührü
Werktuigen tarafından sertifikalandırılmış bayiler

küçük ilan
Volkach
2.313 km
Horizon SPF-CV
HorizonMisc
Ara
Durumu: kullanılmış, Horizon SPF-CV Transfer Bridge, used
The Horizon SPF-CV is a small yet essential connection component, specifically designed to link collating machines of the VAC series (e.g., VAC-100a or VAC-600) with stitchers of the SPF series (e.g., SPF-20 or SPF-20A). It enables seamless transfer of paper stacks between machines, ensuring a smooth production process.
Key Features:
Csdpfjw Ewpyox Acwehf
- Efficient transfer: Connects the collating machine and the stitcher for continuous production
- Compact design: Space-saving construction for easy integration into existing production lines
- Robust construction: Durable and reliable for continuous operation
- Compatibility: Designed for use with Horizon VAC collators and SPF stitchers
Technical Specifications:
- Compatible models: VAC series (e.g., VAC-100a, VAC-600), SPF series (e.g., SPF-20, SPF-20A)
All-in-One Package
We take care of everything: from secure packaging and transport to customs clearance. Upon request, we can also create a tailored leasing offer for you.
Sustainable and economical
Opt for a used machine and enjoy double benefits: protect the environment and your budget. Despite possible signs of use, you receive a quality product at an attractive price.
küçük ilan
Volkach
2.313 km
Alko Mobil-100
AL-KOMisc
Ara
Durumu: kullanılmış, teklif aşağıdakilerden oluşmaktadır:\n\nAlko Mobil-100\ntalaş üfleme cihazı\n\nperfect binder için\n\n- emiş çapı: 100mm\n- maks. hava miktarı: 865 m³/h\n- basınç farkı: 1780 Pa\n\n- motor gücü: 0,75 kW\n- filtre yüzeyi: 1,08 m²\n- dolum kapasitesi: 90 lt.\n- filtre kategorisi: G\n- maks. ses seviyesi: 81 dB(A)\n\nAyrıca sizin için aşağıdakileri de organize edebiliriz:\n\nambalaj, yükleme, taşıma (gemi veya uçak ile) ve gümrük işlemleri.
Chjdew Ewzpopfx Acwsf
küçük ilan
Volkach
2.313 km
Horizon LC-20
HorizonMisc
Ara
Durumu: kullanılmış, 3 AY LA-POSTPRESS GARANTİSİ
Elektronik hariç
Teklif şunları içerir:
uzun teslimat ünitesi LC-20
Chodpfew Ewz Aex Acwjf
küçük ilan
Volkach
2.313 km
Horizon PJ-77
HorizonPJ-77
Ara
Durumu: kullanılmış, Horizon PJ-77 Jogger, used
The Horizon PJ-77 Jogger aligns paper stacks through vibration to ensure precise further processing in printing and binding workflows.
- Compatible with the following Horizon collator towers: MC-80a, VAC-100a, VAC-60Ha, VAC-1000, VAC-600
- Formats: max. 470x318mm; min. 210x148mm
- Stack height: max. 90mm
- Lowering: max. 30mm
- Dimensions: 490x400x460mm
- Weight: 40kg
All-Inclusive Service Package
Chjdpfxew Hxu To Acwef
We take care of everything: from secure packaging and transport to customs clearance.
Sustainable and cost-effective
Choose a pre-owned machine and enjoy double the benefits: protect the environment and your budget. Despite possible signs of previous use, you will receive a quality product at an attractive price.
Aramanızı sizin için kolaylaştırıyoruz
Yeni teklifleri hemen ve ücretsiz olarak e-posta ile alırsınız.
Arama görevini istediğiniz zaman kolayca sonlandırabilirsiniz.
Kullanılmış baskı sonrası makineleri (1.885)
Artık Werktuigen genelinde, 200.000’den fazla kullanılmış makineyle arama yapın.En popüler makine adlarını inceleyin:

Şimdi bilgi alın
+49 201 857 86 180
+49 201 857 86 180
Şimdi ilan ver
*ilan başına/ay
